Notor 65 Beta Opti

Suspended or ceiling-mounted workplace luminaire with direct or direct/indirect light. Beta Opti louvres provide high efficiency and optimal lighting comfort. Single or continuous installation.

Installation

Single or continuous installation via wire suspension or surface mounted. Installation via wire suspension requires wire brackets which provide flexible c/c, see accessories. Can also be wall mounted with special brackets, see Accessories.

Connection

The luminaire is equipped with an access hole for cabling on the top. A special short end with cable entry is used for a surface mounted mains cable, see Accessories. The luminaire unit is equipped with a through-wiring cable (5x1.5 mm²) and a snap-in connection in each end-cap. In a continuous installation, the luminaire row should always begin with a start luminaire.

Design

Luminaire body enameled in white (RAL 9016) or natural anodised, extruded aluminium finish. The indirect light is covered by an opal film which generates a wide beam and acts as a dust cover. End caps are included in the Start/Single-luminaire.

Louvre

Beta Opti – double parabolic reflector louvre with satin matt metallised aluminium side and cross-blades with an integrated opal film that minimises the risk of uncomfortable glare from the diodes

Emergency lighting

There is a unit with integrated emLED available for Notor 65, see Accessories.

Dimming

CLO (Constant Light Output) and DALI/Phase-pulse control as standard. Suffix number -442 och -449 only refer to single luminaires.
e-Sense Active – PIR sensor with presence and daylight control via DALI.
e-Sense Organic G3 – PIR sensor with presence and daylight control. All luminaires have master/slave functionality with IR communications.

Unit for e-Sense Organic G3 lighting control ordered separately, see accessories.
The e-Sense Organic G3 unit is connected as a start luminaire, with a maximum of 2 luminaires connected to each side. To include end-caps, one of the luminaires should be a start luminaire and the other continuous. See assembly instructions for more information.

Accessories

Assembly fittings and supplementary components, see Accessories.

Miscellaneous

CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

The LEDs are protected against contact.
Ra (CRI) 90 on request.

To calculate how many luminaires and accessories you will need to complete a run, please use our configurator.

Media

Notor

Fagerhult’s classic interior luminaire Notor is available in several versions for suspended, surface mounted or recessed installation. Notor is an obvious choice in circumstances when there is a desire to create long, unbroken...

More about the family Notor

Document

Specification

LL=Low Lumen
HL=High Lumen

For exact lengths, please refer to the dimension drawing.

Filter

Art.no. Effect, W Lumen output CCT, K Colour Module Length, mm Width, mm Height, mm Installation Light distribution Light control CLO function on Miscellaneous
Art.no. Effect, W Lumen output CCT, K Colour Module Length, mm Width, mm Height, mm Installation Light distribution Light control CLO function on Miscellaneous
13300-402 19 2090 3000 Anodised 1200 1267 65 65 Start/Single Direct DALI/Phase-pulse Yes LL
13300-449 19 2090 3000 Anodised 1200 1328 65 65 Single Direct Phase-pulse Yes LL, 1 pull dim
13301-402 29 3334 3000 Anodised 1200 1267 65 65 Start/Single Direct DALI/Phase-pulse Yes HL
13301-449 29 3334 3000 Anodised 1200 1328 65 65 Single Direct Phase-pulse Yes HL, 1 pull dim
13302-402 19 2200 4000 Anodised 1200 1267 65 65 Start/Single Direct DALI/Phase-pulse Yes LL
13302-449 19 2200 4000 Anodised 1200 1328 65 65 Single Direct Phase-pulse Yes LL, 1 pull dim
13303-402 29 3509 4000 Anodised 1200 1267 65 65 Start/Single Direct DALI/Phase-pulse Yes HL
13303-449 29 3509 4000 Anodised 1200 1328 65 65 Single Direct Phase-pulse Yes HL, 1 pull dim
13304-402 19 2090 3000 White 1200 1267 65 65 Start/Single Direct DALI/Phase-pulse Yes LL
13304-449 19 2090 3000 White 1200 1328 65 65 Single Direct Phase-pulse Yes LL, 1 pull dim
13305-402 29 3334 3000 White 1200 1267 65 65 Start/Single Direct DALI/Phase-pulse Yes HL
13305-449 29 3334 3000 White 1200 1328 65 65 Single Direct Phase-pulse Yes HL, 1 pull dim
13306-402 19 2200 4000 White 1200 1267 65 65 Start/Single Direct DALI/Phase-pulse Yes LL
13306-449 19 2200 4000 White 1200 1328 65 65 Single Direct Phase-pulse Yes LL, 1 pull dim
13307-402 29 3509 4000 White 1200 1267 65 65 Start/Single Direct DALI/Phase-pulse Yes HL
13307-449 29 3509 4000 White 1200 1328 65 65 Single Direct Phase-pulse Yes HL, 1 pull dim
13308-402 37 4560 3000 Anodised 1200 1267 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes LL
13308-449 37 4560 3000 Anodised 1200 1328 65 65 Single Direct/indirect Phase-pulse Yes LL, 1 pull dim
13308-533 37 4560 3000 Anodised 1200 1267 65 65 Start/Single Direct/indirect e-Sense Organic Yes
13309-402 46 5746 3000 Anodised 1200 1267 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes HL
13309-449 46 5746 3000 Anodised 1200 1328 65 65 Single Direct/indirect Phase-pulse Yes HL, 1 pull dim
13310-402 37 4800 4000 Anodised 1200 1267 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes LL
13310-449 37 4800 4000 Anodised 1200 1328 65 65 Single Direct/indirect Phase-pulse Yes LL, 1 pull dim
13310-533 37 4800 4000 Anodised 1200 1267 65 65 Start/Single Direct/indirect e-Sense Organic Yes
13311-402 46 6084 4000 Anodised 1200 1267 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes HL
13311-449 46 6084 4000 Anodised 1200 1328 65 65 Single Direct/indirect Phase-pulse Yes HL, 1 pull dim
13312-402 37 4560 3000 White 1200 1267 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes LL
13312-449 37 4560 3000 White 1200 1328 65 65 Single Direct/indirect Phase-pulse Yes LL, 1 pull dim
13312-533 37 4560 3000 White 1200 1267 65 65 Start/Single Direct/indirect e-Sense Organic Yes
13312-539 37 4560 3000 White 1200 1328 65 65 Single Direct/indirect e-Sense Active Yes LL
13313-402 46 5746 3000 White 1200 1267 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes HL
13313-449 46 5746 3000 White 1200 1328 65 65 Single Direct/indirect Phase-pulse Yes HL, 1 pull dim
13314-402 37 4800 4000 White 1200 1267 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes LL
13314-449 37 4800 4000 White 1200 1328 65 65 Single Direct/indirect Phase-pulse Yes LL, 1 pull dim
13314-533 37 4800 4000 White 1200 1267 65 65 Start/Single Direct/indirect e-Sense Organic Yes
13315-402 46 6084 4000 White 1200 1267 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes HL
13315-449 46 6084 4000 White 1200 1328 65 65 Single Direct/indirect Phase-pulse Yes HL, 1 pull dim
13316-402 34 4180 3000 Anodised 2400 2528 65 65 Start/Single Direct DALI/Phase-pulse Yes LL
13317-402 54 6667 3000 Anodised 2400 2528 65 65 Start/Single Direct DALI/Phase-pulse Yes HL
13318-402 34 4400 4000 Anodised 2400 2528 65 65 Start/Single Direct DALI/Phase-pulse Yes LL
13319-402 54 7018 4000 Anodised 2400 2528 65 65 Start/Single Direct DALI/Phase-pulse Yes HL
13320-402 34 4180 3000 White 2400 2528 65 65 Start/Single Direct DALI/Phase-pulse Yes LL
13321-402 54 6667 3000 White 2400 2528 65 65 Start/Single Direct DALI/Phase-pulse Yes HL
13322-402 34 4400 4000 White 2400 2528 65 65 Start/Single Direct DALI/Phase-pulse Yes LL
13323-402 54 7018 4000 White 2400 2528 65 65 Start/Single Direct DALI/Phase-pulse Yes HL
13324-402 74 9120 3000 Anodised 2400 2528 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes LL
13325-402 91 11492 3000 Anodised 2400 2528 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes HL
13326-402 74 9600 4000 Anodised 2400 2528 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes LL
13327-402 91 12096 4000 Anodised 2400 2528 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes HL
13328-402 74 9120 3000 White 2400 2528 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes LL
13329-402 91 11492 3000 White 2400 2528 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes HL
13330-402 74 9600 4000 White 2400 2528 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes LL
13331-402 91 12096 4000 White 2400 2528 65 65 Start/Single Direct/indirect DALI/Phase-pulse Yes HL
13332-402 19 2090 3000 Anodised 1200 1261 65 65 Continuous Direct DALI/Phase-pulse Yes LL
13333-402 29 3334 3000 Anodised 1200 1261 65 65 Continuous Direct DALI/Phase-pulse Yes HL
13334-402 19 2200 4000 Anodised 1200 1261 65 65 Continuous Direct DALI/Phase-pulse Yes LL
13335-402 29 3509 4000 Anodised 1200 1261 65 65 Continuous Direct DALI/Phase-pulse Yes HL
13336-402 19 2090 3000 White 1200 1261 65 65 Continuous Direct DALI/Phase-pulse Yes LL
13337-402 29 3334 3000 White 1200 1261 65 65 Continuous Direct DALI/Phase-pulse Yes HL
13338-402 19 2200 4000 White 1200 1261 65 65 Continuous Direct DALI/Phase-pulse Yes LL
13339-402 29 3509 4000 White 1200 1261 65 65 Continuous Direct DALI/Phase-pulse Yes HL
13340-402 37 4560 3000 Anodised 1200 1261 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes LL
13341-402 46 5746 3000 Anodised 1200 1261 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes HL
13342-402 37 4800 4000 Anodised 1200 1261 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes LL
13343-402 46 6084 4000 Anodised 1200 1261 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes HL
13344-402 37 4560 3000 White 1200 1261 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes LL
13345-402 46 5746 3000 White 1200 1261 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes HL
13346-402 37 4800 4000 White 1200 1261 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes LL
13347-402 46 6084 4000 White 1200 1261 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes HL
13348-402 34 4180 3000 Anodised 2400 2522 65 65 Continuous Direct DALI/Phase-pulse Yes LL
13349-402 54 6667 3000 Anodised 2400 2522 65 65 Continuous Direct DALI/Phase-pulse Yes HL
13350-402 34 4400 4000 Anodised 2400 2522 65 65 Continuous Direct DALI/Phase-pulse Yes LL
13351-402 54 7018 4000 Anodised 2400 2522 65 65 Continuous Direct DALI/Phase-pulse Yes HL
13352-402 34 4180 3000 White 2400 2522 65 65 Continuous Direct DALI/Phase-pulse Yes LL
13353-402 54 6667 3000 White 2400 2522 65 65 Continuous Direct DALI/Phase-pulse Yes HL
13354-402 34 4400 4000 White 2400 2522 65 65 Continuous Direct DALI/Phase-pulse Yes LL
13355-402 54 7018 4000 White 2400 2522 65 65 Continuous Direct DALI/Phase-pulse Yes HL
13356-402 74 9120 3000 Anodised 2400 2522 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes LL
13357-402 91 11492 3000 Anodised 2400 2522 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes HL
13358-402 74 9600 4000 Anodised 2400 2522 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes LL
13359-402 91 12096 4000 Anodised 2400 2522 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes HL
13360-402 74 9120 3000 White 2400 2522 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes LL
13361-402 91 11492 3000 White 2400 2522 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes HL
13362-402 74 9600 4000 White 2400 2522 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes LL
13363-402 91 12096 4000 White 2400 2522 65 65 Continuous Direct/indirect DALI/Phase-pulse Yes HL

Filter

Name Description Art.no.
Name Description Art.no.
emLED-unitContinuous luminaire emLED-unit, 270 mm92678
SpacersSpacers 600 mm92665
SpacersSpacers 200 mm92661
SpacersSpacers 600 mm92664
SpacersSpacers 200 mm92660
SpacersSpacers 1200 mm92671
SpacersSpacers 400 mm92663
End-cap Notor 65End-cap with hole for surface mounted cable/each. White.92677
SpacersSpacers 1200 mm92670
SpacersSpacers 800 mm92666
End-cap Notor 65End-cap with hole for surface mounted cable/each. Anodised.92676
emLED-unitContinuous luminaire emLED-unit, 270 mm92679
SpacersSpacers 1000 mm92669
Wall bracket Notor 65Wall bracket with terminal block, 200 mm92686
e-Sense Organic Ethernet Gateway Kite-Sense Organic Ethernet Gateway Kit86285
SpacersSpacers 1000 mm92668
Wall bracket Notor 65Wall bracket with terminal block, 200 mm92685
SpacersSpacers 800 mm92667
Wall bracket Notor 65Wall bracket, 200 mm92675
SpacersSpacers 400 mm92662
Wall bracket Notor 65Wall bracket, 200 mm92674
Support rail (cat. no./pair)L=600/650, section: 15, max. load: 75N/pair90015
Support rail (cat. no./pair)L=600/625, section: 25, max. load: 75N/pair94067
Wire suspension for support railsWire suspension for support rails 90015, 90016, 90017, 94052, 94067, 9406891426
Support rail (cat. no./pair)L=200/1250, section: 15, max. load: 120/30N/pair90016
Support rail (cat. no./pair)L=1200/1250, section: 25, max. load: 120/30N/pair94068
Support rail (cat. no./pairL=600 mm, T-bars: 25/15, max load: 75 N/pair90017
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – small + large, transparent mains cable (96382+96390)95355
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup for T-bars 25 mm, white mains cable/each96388
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – small + large, for T-bars 25 mm, white mains cable (96384+96388)95356
Wire suspension for continuous installation, 3x0.75 mm²Large square ceiling cup, white mains cable/each96374
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – small + large for T-bars 25 mm, white mains cable (96372+96376)95364
Wire suspension for continuous installation, 3x0.75 mm²Large square ceiling cup, transparent mains cable/each96378
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – small + large for T-bars 25 mm, transparent mains cable (96372+96379)95365
Wire suspension for continuous installation, 3x0.75 mm²Large square ceiling cup for T-bars 25 mm, transparent mains cable/each96379
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – small + large, white mains cable (96370+96374)95362
Wire suspension for continuous installation, 3x0.75 mm²Large square ceiling cup for T-bars 25 mm, white mains cable/each96376
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – large, for T-bars 25 mm, transparent mains cable (96385+96391)95353
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup, white mains cable/each96386
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – large, for T-bars 25 mm, transparent mains cable (96373+96379)95361
Wire suspension for continuous installation Large round ceiling cup for T-bars 25 mm/each96385
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – small + large, transparent mains cable (96370+96378)95363
Wire suspension for continuous installation Large square ceiling cup for T-bars 25 mm/each96373
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – large, for T-bars 25 mm, white mains cable (96373+96376)95360
Wire suspension for continuous installation Small round ceiling cup/each96382
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – large, transparent mains cable (96371+96378)95359
Wire suspension for continuous installation Large square ceiling cup/each96371
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – large, white mains cable (96371+96374)95358
Wire suspension for continuous installation Small round ceiling cup for T-bars 25 mm/each96384
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – small + large, for T-bars 25 mm, transparent mains cable (96384+96391)95357
Wire suspension for continuous installation Small square ceiling cup for T-bars 25 mm/each96372
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – large, for T-bars 25 mm, white mains cable (96385+96388)95352
Wire suspension for continuous installation Small square ceiling cup/each96370
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – large, white mains cable (96383+96386)95350
Wire suspension for continuous installation Large round ceiling cup/each96383
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup, transparent mains cable/each96390
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup for T-bars 25 mm, transparent mains cable/each96391
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – large, transparent mains cable (96383+96390)95351
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – small + large, white mains cable (96382+96386)95354
Wall socketWall socket/pair92673
IR dongle for e-Sense OrganicIR dongle for e-Sense Organic equipped luminaire.86279
e-Sense Organic wall switch 2e-Sense Organic Wall Switch 2 (6 button)86284
Wire bracket incl. friction locksWire bracket/pair92683
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – small + large, for T-bars 25 mm, white mains cable (96384+96389)95372
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup, white mains cable/each96387
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – small + large for T-bars 25 mm, transparent mains cable (96372+96381)95381
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup for T-bars 25 mm, transparent mains cable/each96393
Wire bracket incl. friction locksWire bracket/pair92682
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – small + large for T-bars 25 mm, white mains cable (96372+96377)95380
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup for T-bars 25 mm, white mains cable/each96389
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – small + large, transparent mains cable (96370+96380)95379
Wire suspension for continuous installation, 5x0.75 mm²Large square ceiling cup, white mains cable/each96375
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – small + large, white mains cable (96370+96375)95378
Wire suspension for continuous installation, 5x0.75 mm²Large square ceiling cup, transparent mains cable/each96380
Wire suspension for continuous installation, 5x0.75 mm²Large square ceiling cup for T-bars 25 mm, transparent mains cable/each96381
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – large, for T-bars 25 mm, transparent mains cable (96373+96381)95377
Wire suspension for continuous installation, 5x0.75 mm²Large square ceiling cup for T-bars 25 mm, white mains cable/each96377
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – large, for T-bars 25 mm, white mains cable (96373+96377)95376
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup, transparent mains cable/each96392
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – large, transparent mains cable (96371+96380)95375
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – large, white mains cable (96371+96375)95374
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – large, for T-bars 25 mm, white mains cable (96385+96389)95368
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – small + large, for T-bars 25 mm, transparent mains cable (96384+96393)95373
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – small + large, white mains cable (96382+96387)95370
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – large, transparent mains cable (96383+96392)95367
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – small + large, transparent mains cable (96382+96392)95371
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – large, white mains cable (96383+96387)95366
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – large, for T-bars 25 mm, transparent mains cable (96385+96393)95369
Ceiling bracket in chrome with wireWire suspension with ceiling bracket in chrome, L=1.5 m/pair91696
CuttersCutters, each94248
e-Sense Organic Sensor Node Link Kite-Sense Organic Sensor Node Link Kit. Cable length 6.0 m86286
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, recessed, 3.2 m cable86362
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, tube installation 3.2 m cable86366
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, tube installation 1 m cable86365
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, recessed, 1 m cable86361
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, suspended, 1 m cable86363
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, suspended, 3.2 m cable86364
e-Sense Organic-unit400 mm92681
e-Sense Organic-unit400 mm92680
Remote controlRemote control 86415
Programming remote control e-Sense ActiveProgramming remote control 86414
e-Sense Organic G3 I/O boxI/O box with potential-free relay for controlling external units.86413
External sensor incl. DALI PSU e-Sense Organic G3External sensor incl. DALI PSU, recessed, 1 m cable86407
e-Sense Organic G3 IoT GatewayGateway for connection to e-Sense Organic Portal. Incl. power adapter and wall bracket. Controls a maximum of 150 sensors.86296
External sensor incl. DALI PSU e-Sense Organic G3External sensor incl. DALI PSU, suspended, 1 m cable86408
External sensor incl. DALI PSU e-Sense Organic G3Extern sensor incl. DALI PSU, tube installation 1 m cable. Tube not included.86409
External sensor incl. DALI PSU e-Sense Organic G3Extern sensor incl. DALI PSU, tube installation 3.2 m cable. Tube not included.86412
External sensor incl. DALI PSU e-Sense Organic G3External sensor incl. DALI PSU, suspended, 3.2 m cable86411
External sensor incl. DALI PSU e-Sense Organic G3External sensor incl. DALI PSU, recessed, 3.2 m cable86410
