Hero SPASurface
Hero SPA is a high-bay luminaire developed for indoor swimming pool facilities. The luminaire offers good glare control and is also available with asymmetric light distribution, enabling service-friendly installation along the side of the pool.
Installation
Luminaire for surface-mounted ceiling bracket, surface-mounted tandem bracket, tube bracket, cable bracket, wire bracket, adjustable ceiling/wall bracket, bracket and recess frame are ordered separately, see Accessories. For detailed information, see the installation instructions.
Connection
The luminaire is supplied with a 2 m, 5x1.5 mm², mains cable (H07RN-F) with free ends. CLO (Constant Light Output).
Design
Cast aluminium luminaire body, made from post-consumer recycled material. Lacquered in white (RAL 9016). Louvre frame in lacquered aluzinc. Corrosion class C4. Hardened protective glass.
Light Distribution
Direct wide beam. Asymmetrical.
Light data
Optics
Reflectors made of semi-gloss metallised aluminium.
Made of recycled aluminium
The product contains die-cast aluminium, a material that in our products consists of approximately 85% recycled content. By using recycled aluminium, energy consumption is reduced by up to 95% compared to virgin aluminium (Source: European Aluminium). This entails a significantly lower carbon footprint.
Resilient over time
The aluminium alloy that is used is of high quality, ensuring good corrosion protection. Together with other material choices that counteract galvanic corrosion, the design can withstand exposed conditions over time.
Made in Sweden
The product is manufactured in Fagerhult’s factory in Habo, Sweden. The production process has a low climate impact, using energy from 100% renewable sources. Local manufacturing ensures clean production, high quality, reduced transportation and good working conditions.
DALI/Phase pulse control
Combines digital DALI control with traditional phase control – a flexible solution that allows both precise dimming and easy installation.
Articles
| Art.no. | System Wattage | Lumen output | CCT, K | Dimensions, mm | Light distribution | Light control | Protective glass | CLO time, h | Light data files | Article PDF |
|---|---|---|---|---|---|---|---|---|---|---|
| 31610-402 | 80 | 11465 | 4000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Frosted glass | 100000 |
|
|
| 31611-402 | 105 | 15232 | 4000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Frosted glass | 100000 |
|
|
| 31612-402 | 131 | 18737 | 4000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Frosted glass | 100000 |
|
|
| 31613-402 | 87 | 11465 | 3000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Frosted glass | 100000 |
|
|
| 31614-402 | 113 | 15232 | 3000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Frosted glass | 100000 |
|
|
| 31615-402 | 142 | 18737 | 3000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Frosted glass | 100000 |
|
|
| 31620-402 | 77 | 12068 | 4000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Flat glass | 100000 |
|
|
| 31621-402 | 99 | 16034 | 4000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Flat glass | 100000 |
|
|
| 31622-402 | 129 | 19723 | 4000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Flat glass | 100000 |
|
|
| 31623-402 | 75 | 12497 | 4000 | 498x307x87 | Asymmetrical | DALI/Phase-pulse | Flat glass | 100000 |
|
|
| 31624-402 | 98 | 16027 | 4000 | 498x307x87 | Asymmetrical | DALI/Phase-pulse | Flat glass | 100000 |
|
|
| 31625-402 | 83 | 12068 | 3000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Flat glass | 100000 |
|
|
| 31626-402 | 107 | 16034 | 3000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Flat glass | 100000 |
|
|
| 31627-402 | 139 | 19723 | 3000 | 498x307x87 | Wide Beam | DALI/Phase-pulse | Flat glass | 100000 |
|
|
| 31628-402 | 81 | 12497 | 3000 | 498x307x87 | Asymmetrical | DALI/Phase-pulse | Flat glass | 100000 |
|
|
| 31629-402 | 106 | 16027 | 3000 | 498x307x87 | Asymmetrical | DALI/Phase-pulse | Flat glass | 100000 |
|
| Name | Description | Art.no. | Article PDF | |
|---|---|---|---|---|
|
Conduit bracket/pair | Conduit bracket/pair. Corrosion protection class C4. | 31911 | |
|
Wire Suspension kit | Wire Suspension kit/pair incl. 2 m wire with eye/. Corrosion protection class C4. | 31912 | |
|
Ceiling bracket tandem | Ceiling bracket tandem. Corrosion protection class C4. | 31919 | |
|
Recessed frame | Recessed frame. Corrosion protection class C4. | 31914 | |
|
Ceiling bracket | Ceiling bracket. Corrosion protection class C4. | 31920 | |
|
Wire catenary bracket | Wire catenary bracket/pair. Corrosion protection class C4. | 31910 | |
|
Adjustable wall/ceiling bracket | Adjustable wall/ceiling bracket. Corrosion protection class C4. | 31921 | |
|
Support bars 600 mm | Support bars for recessed frame. Corrosion protection class C4. | 31922 | |
|
|
Support bars 1200 mm | Support bars for recessed frame. Corrosion protection class C4. | 31923 |
