Pleiad G4 128 Surface mounted

Surface mounted downlights with integrated option for surface-mounted cable. Available with several reflector and light distribution options.

Installation

Surface mounted installation. Installation section with two securing holes.

Connection

3-way snap-in terminal block 2.5 mm², onward connection possible. With dimming, 5-way snap-in terminal block, onward connection possible. Luminaire housing and installation section are connected with the internal snap-in connector. Cable entry from the top of the luminaire or from the side. Bayonet attachment of luminaire housing in two heights permits entry of the surface mounted cable from 3 directions.

Design

Aluminium luminaire body in white (RAL 9016). Installation section of white plastic (PA).

Reflector

Reflector of matt anodised aluminium, white (RAL 9003) or black (RAL 9005) finish. Lens of clear acrylic.

Media

Pleiad G4

Pleiad G4 is the latest evolution of Fagerhult's classic downlight series. Even more efficient. Even better visual comfort. Even quicker to install. Pleiad G4 simplifies and streamlines advanced lighting planning for entire...

More about the family Pleiad G4

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K CRI Diameter, mm Reflector Light distribution Light control
Art.no. Effect, W Lumen output CCT, K CRI Diameter, mm Reflector Light distribution Light control
72421 8 899 3000 80 129 Black Medium Beam
72421-402 8 899 3000 80 129 Black Medium Beam DALI/Phase-pulse
72422 8 783 3000 90 129 Black Medium Beam
72422-402 8 783 3000 90 129 Black Medium Beam DALI/Phase-pulse
72423 8 967 4000 80 129 Black Medium Beam
72423-402 8 967 4000 80 129 Black Medium Beam DALI/Phase-pulse
72424 8 841 4000 90 129 Black Medium Beam
72424-402 8 841 4000 90 129 Black Medium Beam DALI/Phase-pulse
72425 11 1259 3000 80 129 Black Medium Beam
72425-402 11 1259 3000 80 129 Black Medium Beam DALI/Phase-pulse
72426 11 1096 3000 90 129 Black Medium Beam
72426-402 11 1096 3000 90 129 Black Medium Beam DALI/Phase-pulse
72427 11 1353 4000 80 129 Black Medium Beam
72427-402 11 1353 4000 80 129 Black Medium Beam DALI/Phase-pulse
72428 11 1177 4000 90 129 Black Medium Beam
72428-402 11 1177 4000 90 129 Black Medium Beam DALI/Phase-pulse
72429 8 867 3000 80 129 Black Wide Beam
72429-402 8 867 3000 80 129 Black Wide Beam DALI/Phase-pulse
72430 8 755 3000 90 129 Black Wide Beam
72430-402 8 755 3000 90 129 Black Wide Beam DALI/Phase-pulse
72431 8 932 4000 80 129 Black Wide Beam
72431-402 8 932 4000 80 129 Black Wide Beam DALI/Phase-pulse
72432 8 811 4000 90 129 Black Wide Beam
72432-402 8 811 4000 90 129 Black Wide Beam DALI/Phase-pulse
72433 11 1214 3000 80 129 Black Wide Beam
72433-402 11 1214 3000 80 129 Black Wide Beam DALI/Phase-pulse
72434 11 1057 3000 90 129 Black Wide Beam
72434-402 11 1057 3000 90 129 Black Wide Beam DALI/Phase-pulse
72435 11 1305 4000 80 129 Black Wide Beam
72435-402 11 1305 4000 80 129 Black Wide Beam DALI/Phase-pulse
72436 11 1136 4000 90 129 Black Wide Beam
72436-402 11 1136 4000 90 129 Black Wide Beam DALI/Phase-pulse
72437 8 996 3000 80 129 Matt Medium Beam
72437-402 8 996 3000 80 129 Matt Medium Beam DALI/Phase-pulse
72438 8 868 3000 90 129 Matt Medium Beam
72438-402 8 868 3000 90 129 Matt Medium Beam DALI/Phase-pulse
72439 8 1071 4000 80 129 Matt Medium Beam
72439-402 8 1071 4000 80 129 Matt Medium Beam DALI/Phase-pulse
72440 8 932 4000 90 129 Matt Medium Beam
72440-402 8 932 4000 90 129 Matt Medium Beam DALI/Phase-pulse
72441 11 1394 3000 80 129 Matt Medium Beam
72441-402 11 1394 3000 80 129 Matt Medium Beam DALI/Phase-pulse
72442 11 1215 3000 90 129 Matt Medium Beam
72442-402 11 1215 3000 90 129 Matt Medium Beam DALI/Phase-pulse
72443 11 1499 4000 80 129 Matt Medium Beam
72443-402 11 1499 4000 80 129 Matt Medium Beam DALI/Phase-pulse
72444 11 1304 4000 90 129 Matt Medium Beam
72444-402 11 1304 4000 90 129 Matt Medium Beam DALI/Phase-pulse
72452 8 1000 3000 80 129 Matt Wide Beam
72452-402 8 1000 3000 80 129 Matt Wide Beam DALI/Phase-pulse
72453 8 871 3000 90 129 Matt Wide Beam
72453-402 8 871 3000 90 129 Matt Wide Beam DALI/Phase-pulse
72454 8 1075 4000 80 129 Matt Wide Beam
72454-402 8 1075 4000 80 129 Matt Wide Beam DALI/Phase-pulse
72455 8 935 4000 90 129 Matt Wide Beam
72455-402 8 935 4000 90 129 Matt Wide Beam DALI/Phase-pulse
72456 11 1400 3000 80 129 Matt Wide Beam
72456-402 11 1400 3000 80 129 Matt Wide Beam DALI/Phase-pulse
72457 11 1219 3000 90 129 Matt Wide Beam
72457-402 11 1219 3000 90 129 Matt Wide Beam DALI/Phase-pulse
72458 11 1505 4000 80 129 Matt Wide Beam
72458-402 11 1505 4000 80 129 Matt Wide Beam DALI/Phase-pulse
72459 11 1309 4000 90 129 Matt Wide Beam
72459-402 11 1309 4000 90 129 Matt Wide Beam DALI/Phase-pulse
72572 8 994 3000 80 129 White Medium Beam
72572-402 8 994 3000 80 129 White Medium Beam DALI/Phase-pulse
72573 8 865 3000 90 129 White Medium Beam
72573-402 8 865 3000 90 129 White Medium Beam DALI/Phase-pulse
72574 8 1068 4000 80 129 White Medium Beam
72574-402 8 1068 4000 80 129 White Medium Beam DALI/Phase-pulse
72575 8 929 4000 90 129 White Medium Beam
72575-402 8 929 4000 90 129 White Medium Beam DALI/Phase-pulse
72576 11 1391 3000 80 129 White Medium Beam
72576-402 11 1391 3000 80 129 White Medium Beam DALI/Phase-pulse
72577 11 1211 3000 90 129 White Medium Beam
72577-402 11 1211 3000 90 129 White Medium Beam DALI/Phase-pulse
72578 11 1496 4000 80 129 White Medium Beam
72578-402 11 1496 4000 80 129 White Medium Beam DALI/Phase-pulse
72579 11 1301 4000 90 129 White Medium Beam
72579-402 11 1301 4000 90 129 White Medium Beam DALI/Phase-pulse
72581 8 987 3000 80 129 White Wide Beam
72581-402 8 987 3000 80 129 White Wide Beam DALI/Phase-pulse
72582 8 860 3000 90 129 White Wide Beam
72582-402 8 860 3000 90 129 White Wide Beam DALI/Phase-pulse
72583 8 1062 4000 80 129 White Wide Beam
72583-402 8 1062 4000 80 129 White Wide Beam DALI/Phase-pulse
72584 8 924 4000 90 129 White Wide Beam
72584-402 8 924 4000 90 129 White Wide Beam DALI/Phase-pulse
72585 11 1382 3000 80 129 White Wide Beam
72585-402 11 1382 3000 80 129 White Wide Beam DALI/Phase-pulse
72586 11 1204 3000 90 129 White Wide Beam
72586-402 11 1204 3000 90 129 White Wide Beam DALI/Phase-pulse
72587 11 1486 4000 80 129 White Wide Beam
72587-402 11 1486 4000 80 129 White Wide Beam DALI/Phase-pulse
72588 11 1293 4000 90 129 White Wide Beam
72588-402 11 1293 4000 90 129 White Wide Beam DALI/Phase-pulse
72640 20 2036 3000 80 129 Black Medium Beam
72640-402 20 2036 3000 80 129 Black Medium Beam DALI/Phase-pulse
72641 20 1773 3000 90 129 Black Medium Beam
72641-402 20 1773 3000 90 129 Black Medium Beam DALI/Phase-pulse
72642 20 2189 4000 80 129 Black Medium Beam
72642-402 20 2189 4000 80 129 Black Medium Beam DALI/Phase-pulse
72643 20 1904 4000 90 129 Black Medium Beam
72643-402 20 1904 4000 90 129 Black Medium Beam DALI/Phase-pulse
72644 20 1963 3000 80 129 Black Wide Beam
72644-402 20 1963 3000 80 129 Black Wide Beam DALI/Phase-pulse
72645 20 1710 3000 90 129 Black Wide Beam
72645-402 20 1710 3000 90 129 Black Wide Beam DALI/Phase-pulse
72646 20 2111 4000 80 129 Black Wide Beam
72646-402 20 2111 4000 80 129 Black Wide Beam DALI/Phase-pulse
72647 20 1837 4000 90 129 Black Wide Beam
72647-402 20 1837 4000 90 129 Black Wide Beam DALI/Phase-pulse
72648 20 2255 3000 80 129 Matt Medium Beam
72648-402 20 2255 3000 80 129 Matt Medium Beam DALI/Phase-pulse
72649 20 1964 3000 90 129 Matt Medium Beam
72649-402 20 1964 3000 90 129 Matt Medium Beam DALI/Phase-pulse
72650 20 2425 4000 80 129 Matt Medium Beam
72650-402 20 2425 4000 80 129 Matt Medium Beam DALI/Phase-pulse
72651 20 2110 4000 90 129 Matt Medium Beam
72651-402 20 2110 4000 90 129 Matt Medium Beam DALI/Phase-pulse
72652 20 2264 3000 80 129 Matt Wide Beam
72652-402 20 2264 3000 80 129 Matt Wide Beam DALI/Phase-pulse
72653 20 1972 3000 90 129 Matt Wide Beam
72653-402 20 1972 3000 90 129 Matt Wide Beam DALI/Phase-pulse
72654 20 2434 4000 80 129 Matt Wide Beam
72654-402 20 2434 4000 80 129 Matt Wide Beam DALI/Phase-pulse
72655 20 2118 4000 90 129 Matt Wide Beam
72655-402 20 2118 4000 90 129 Matt Wide Beam DALI/Phase-pulse
72656 20 2250 3000 80 129 White Medium Beam
72656-402 20 2250 3000 80 129 White Medium Beam DALI/Phase-pulse
72657 20 1959 3000 90 129 White Medium Beam
72657-402 20 1959 3000 90 129 White Medium Beam DALI/Phase-pulse
72658 20 2419 4000 80 129 White Medium Beam
72658-402 20 2419 4000 80 129 White Medium Beam DALI/Phase-pulse
72659 20 2104 4000 90 129 White Medium Beam
72659-402 20 2104 4000 90 129 White Medium Beam DALI/Phase-pulse
72660 20 2235 3000 80 129 White Wide Beam
72660-402 20 2235 3000 80 129 White Wide Beam DALI/Phase-pulse
72661 20 1947 3000 90 129 White Wide Beam
72661-402 20 1947 3000 90 129 White Wide Beam DALI/Phase-pulse
72662 20 2404 4000 80 129 White Wide Beam
72662-402 20 2404 4000 80 129 White Wide Beam DALI/Phase-pulse
72663 20 2091 4000 90 129 White Wide Beam
72663-402 20 2091 4000 90 129 White Wide Beam DALI/Phase-pulse

Filter

Name Description Art.no.
Name Description Art.no.
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup for T-bars 25 mm, white mains cable/each96388
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup, white mains cable/each96386
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup, white mains cable/each96387
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup for T-bars 25 mm, white mains cable/each96389
Cover plate IP 23Cover plate IP 23, Ø 28 41057
Cable pendantØ 128 Cable pendant. Supplemented with wire suspension, ordered separately. 41063
