75202-20936 Pleiad G4 125

Installation

Recessed

Light distribution

Wide Beam

Beam angle, °

70

Reflector

White

Colour

White/white

Lumen output

2019

CLO function active

Yes

CLO time, h

100000

lm/W

72

CCT, K

3000

CRI

80

SDCM

3

Lumen maintenance 100 000 h

L100

LED driver, h/max failure %

100000/10

Energy class, LED module

D

PstLm

1.000

SVM

0.400

Light control

DALI/Phase-pulse

Driver brand

Helvar

DALI generation/adress type

Dali-2/1xDT6

Power on last level

Yes

Corridor function

Yes

Switch control, max no.

60

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

64

IP rating (above suspended ceilings)

20

System Wattage

28

Start W

28

End W

32

Average W

30

Stand by W

0.35

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

15

MCB B16A

24

MCB C10A

25

MCB C16A

41

THD, %

15

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Power factor, 100 %

0.91

NTC function

False

Height, mm

98

Diamater, mm

143

Weight, kg

0.3
