Notor 65 Opal

Suspended or ceiling mounted with direct light only via Opal louvres. Single or continuous installation.

Installation

Single or continuous installation via wire suspension or surface mounted. Installation via wire suspension requires wire brackets which provide flexible c/c, see accessories. Can also be wall mounted with special brackets, see Accessories.

Connection

The luminaire is equipped with an access hole for cabling on the top. A special short end with cable entry is used for a surface mounted mains cable, see Accessories. The luminaire unit is equipped with a through-wiring cable (5x1.5 mm²) and a snap-in connection in each end-cap. In a continuous installation, the luminaire row should always begin with a start luminaire. The illuminated corners can be used as a start luminaire and are equipped with through-wiring and quick connection in one end. The corners can only be used in closed systems.

Design

Luminaire body enameled in white (RAL 9016) alternatively black (RAL 9005) or natural anodised extruded aluminium finish.

Louvre

Opal – plate in frosted acrylic (PMMA).

Emergency lighting

There is a unit with integrated emLED available for Notor 65, see Accessories.

Dimming

CLO (Constant Light Output) and DALI/Phase-pulse control as standard.
e-Sense Organic G3 – PIR sensor with presence and daylight control. All luminaires have master/slave functionality with IR communications.

Unit for e-Sense Organic G3 lighting control ordered separately, see accessories. The e-Sense Organic G3 unit is connected as a start luminaire, with a maximum of 2 luminaires connected to each side. To include end-caps, one of the luminaires should be a start luminaire and the other continuous. See assembly instructions for more information.

Accessories

Assembly fittings and supplementary components, see Accessories.

Miscellaneous

CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

The LEDs are protected against contact.

To calculate how many luminaires and accessories you will need to complete a run, please use our configurator.

Media

Notor

Fagerhult’s classic interior luminaire Notor is available in several versions for suspended, surface mounted or recessed installation. Notor is an obvious choice in circumstances when there is a desire to create long, unbroken...

More about the family Notor

Document

Specification


For exact lengths, please refer to the dimension drawing.

Filter

Art.no. Effect, W Lumen output CCT, K Colour Module Length, mm Width, mm Height, mm Installation Light control Miscellaneous
Art.no. Effect, W Lumen output CCT, K Colour Module Length, mm Width, mm Height, mm Installation Light control Miscellaneous
13445-402 15 1582 3000 Anodised 800 840 65 65 Start/Single DALI/Phase-pulse
13447-402 15 1666 4000 Anodised 800 840 65 65 Start/Single DALI/Phase-pulse
13449-402 15 1582 3000 White 800 840 65 65 Start/Single DALI/Phase-pulse
13451-402 15 1666 4000 White 800 840 65 65 Start/Single DALI/Phase-pulse
13453-402 23 2375 3000 Anodised 1200 1256 65 65 Start/Single DALI/Phase-pulse
13455-402 23 2500 4000 Anodised 1200 1256 65 65 Start/Single DALI/Phase-pulse
13457-402 23 2375 3000 White 1200 1256 65 65 Start/Single DALI/Phase-pulse
13459-402 23 2500 4000 White 1200 1256 65 65 Start/Single DALI/Phase-pulse
13461-402 47 4750 3000 Anodised 2400 2506 65 65 Start/Single DALI/Phase-pulse
13463-402 47 5000 4000 Anodised 2400 2506 65 65 Start/Single DALI/Phase-pulse
13465-402 47 4750 3000 White 2400 2506 65 65 Start/Single DALI/Phase-pulse
13467-402 47 5000 4000 White 2400 2506 65 65 Start/Single DALI/Phase-pulse
13469-402 15 1582 3000 Anodised 800 836 65 65 Continuous DALI/Phase-pulse
13471-402 15 1666 4000 Anodised 800 836 65 65 Continuous DALI/Phase-pulse
13473-402 15 1582 3000 White 800 836 65 65 Continuous DALI/Phase-pulse
13475-402 15 1666 4000 White 800 836 65 65 Continuous DALI/Phase-pulse
13477-402 23 2375 3000 Anodised 1200 1252 65 65 Continuous DALI/Phase-pulse
13479-402 23 2500 4000 Anodised 1200 1252 65 65 Continuous DALI/Phase-pulse
13481-402 23 2375 3000 White 1200 1252 65 65 Continuous DALI/Phase-pulse
13483-402 23 2500 4000 White 1200 1252 65 65 Continuous DALI/Phase-pulse
13485-402 47 4750 3000 Anodised 2400 2502 65 65 Continuous DALI/Phase-pulse
13487-402 47 5000 4000 Anodised 2400 2502 65 65 Continuous DALI/Phase-pulse
13489-402 47 4750 3000 White 2400 2502 65 65 Continuous DALI/Phase-pulse
13491-402 47 5000 4000 White 2400 2502 65 65 Continuous DALI/Phase-pulse
13492-402 15 1582 3000 Anodised 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, left
13493-402 15 1582 3000 Anodised 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, right
13494-402 15 1666 4000 Anodised 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, left
13495-402 15 1666 4000 Anodised 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, right
13496-402 15 1582 3000 White 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, left
13497-402 15 1582 3000 White 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, right
13498-402 15 1666 4000 White 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, left
13499-402 15 1666 4000 White 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, right
13517-402 15 1582 3000 Black 800 840 65 65 Start/Single DALI/Phase-pulse
13519-402 15 1666 4000 Black 800 840 65 65 Start/Single DALI/Phase-pulse
13521-402 23 2375 3000 Black 1200 1256 65 65 Start/Single DALI/Phase-pulse
13523-402 23 2500 4000 Black 1200 1256 65 65 Start/Single DALI/Phase-pulse
13525-402 47 4750 3000 Black 2400 2506 65 65 Start/Single DALI/Phase-pulse
13527-402 47 5000 4000 Black 2400 2506 65 65 Start/Single DALI/Phase-pulse
13529-402 15 1582 3000 Black 800 836 65 65 Continuous DALI/Phase-pulse
13531-402 15 1666 4000 Black 800 836 65 65 Continuous DALI/Phase-pulse
13533-402 23 2375 3000 Black 1200 1252 65 65 Continuous DALI/Phase-pulse
13535-402 23 2500 4000 Black 1200 1252 65 65 Continuous DALI/Phase-pulse
13537-402 47 4750 3000 Black 2400 2502 65 65 Continuous DALI/Phase-pulse
13539-402 47 5000 4000 Black 2400 2502 65 65 Continuous DALI/Phase-pulse
13541-402 15 1582 3000 Anodised 400x400 470 65 65 Start/Single DALI/Phase-pulse Corner, right
13543-402 15 1666 4000 Anodised 400x400 470 65 65 Start/Single DALI/Phase-pulse Corner, right
13545-402 15 1582 3000 White 400x400 470 65 65 Start/Single DALI/Phase-pulse Corner, right
13547-402 15 1666 4000 White 400x400 470 65 65 Start/Single DALI/Phase-pulse Corner, right
13565-402 15 1582 3000 Black 400x400 470 65 65 Start/Single DALI/Phase-pulse Corner, right
13567-402 15 1666 4000 Black 400x400 470 65 65 Start/Single DALI/Phase-pulse Corner, right
13568-402 15 1582 3000 Black 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, left
13569-402 15 1582 3000 Black 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, right
13570-402 15 1666 4000 Black 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, left
13571-402 15 1666 4000 Black 400x400 470 65 65 Continuous DALI/Phase-pulse Corner, right

Filter

Name Description Art.no.
Name Description Art.no.
Ceiling bracket in chrome with wireWire suspension with ceiling bracket in chrome, L=1.5 m/pair91696
CuttersCutters, each94248
emLED-unitContinuous luminaire emLED-unit, 270 mm92678
emLED-unitContinuous luminaire emLED-unit, 270 mm92679
End-cap Notor 65End-cap with hole for surface mounted cable/each. Anodised.92676
End-cap Notor 65End-cap with hole for surface mounted cable/each. White.92677
End-cap Notor 65End-cap with hole for surface mounted cable/each. Black.92687
e-Sense Organic Ethernet Gateway Kite-Sense Organic Ethernet Gateway Kit86285
e-Sense Organic Sensor Node Link Kite-Sense Organic Sensor Node Link Kit. Cable length 6.0 m86286
e-Sense Organic wall switch 2e-Sense Organic Wall Switch 2 (6 button)86284
e-Sense Organic-unit400 mm92680
e-Sense Organic-unit400 mm92681
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, recessed, 1 m cable86361
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, recessed, 3.2 m cable86362
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, suspended, 1 m cable86363
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, suspended, 3.2 m cable86364
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, tube installation 1 m cable86365
External sensor incl. controller e-Sense OrganicExternal sensor incl. controller, tube installation 3.2 m cable86366
IR dongle for e-Sense OrganicIR dongle for e-Sense Organic equipped luminaire.86279
SpacersSpacers 200 mm92660
SpacersSpacers 200 mm92661
SpacersSpacers 400 mm92662
SpacersSpacers 400 mm92663
SpacersSpacers 600 mm92664
SpacersSpacers 600 mm92665
SpacersSpacers 800 mm92666
SpacersSpacers 800 mm92667
SpacersSpacers 1000 mm92668
SpacersSpacers 1000 mm92669
SpacersSpacers 1200 mm92670
SpacersSpacers 1200 mm92671
Support rail (cat. no./pairL=600 mm, T-bars: 25/15, max load: 75 N/pair90017
Support rail (cat. no./pair)L=600/650, section: 15, max. load: 75N/pair90015
Support rail (cat. no./pair)L=200/1250, section: 15, max. load: 120/30N/pair90016
Support rail (cat. no./pair)L=600/625, section: 25, max. load: 75N/pair94067
Support rail (cat. no./pair)L=1200/1250, section: 25, max. load: 120/30N/pair94068
Wall bracket Notor 65Wall bracket, 200 mm92674
Wall bracket Notor 65Wall bracket, 200 mm92675
Wall bracket Notor 65Wall bracket with terminal block, 200 mm92685
Wall bracket Notor 65Wall bracket with terminal block, 200 mm92686
Wall socketWall socket/pair92673
Wire bracket incl. friction locksWire bracket/pair92682
Wire bracket incl. friction locksWire bracket/pair92683
Wire bracket incl. friction locksWire bracket/pair92684
Wire suspension for continuous installation Small square ceiling cup/each96370
Wire suspension for continuous installation Large square ceiling cup/each96371
Wire suspension for continuous installation Small square ceiling cup for T-bars 25 mm/each96372
Wire suspension for continuous installation Large square ceiling cup for T-bars 25 mm/each96373
Wire suspension for continuous installation Small round ceiling cup/each96382
Wire suspension for continuous installation Large round ceiling cup/each96383
Wire suspension for continuous installation Small round ceiling cup for T-bars 25 mm/each96384
Wire suspension for continuous installation Large round ceiling cup for T-bars 25 mm/each96385
Wire suspension for continuous installation, 3x0.75 mm²Large square ceiling cup, white mains cable/each96374
Wire suspension for continuous installation, 3x0.75 mm²Large square ceiling cup for T-bars 25 mm, white mains cable/each96376
Wire suspension for continuous installation, 3x0.75 mm²Large square ceiling cup, transparent mains cable/each96378
Wire suspension for continuous installation, 3x0.75 mm²Large square ceiling cup for T-bars 25 mm, transparent mains cable/each96379
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup, white mains cable/each96386
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup for T-bars 25 mm, white mains cable/each96388
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup, transparent mains cable/each96390
Wire suspension for continuous installation, 3x0.75 mm²Large round ceiling cup for T-bars 25 mm, transparent mains cable/each96391
Wire suspension for continuous installation, 5x0.75 mm²Large square ceiling cup, white mains cable/each96375
Wire suspension for continuous installation, 5x0.75 mm²Large square ceiling cup for T-bars 25 mm, white mains cable/each96377
Wire suspension for continuous installation, 5x0.75 mm²Large square ceiling cup, transparent mains cable/each96380
Wire suspension for continuous installation, 5x0.75 mm²Large square ceiling cup for T-bars 25 mm, transparent mains cable/each96381
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup, white mains cable/each96387
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup for T-bars 25 mm, white mains cable/each96389
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup, transparent mains cable/each96392
Wire suspension for continuous installation, 5x0.75 mm²Large round ceiling cup for T-bars 25 mm, transparent mains cable/each96393
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – large, white mains cable (96383+96386)95350
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – large, transparent mains cable (96383+96390)95351
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – large, for T-bars 25 mm, white mains cable (96385+96388)95352
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – large, for T-bars 25 mm, transparent mains cable (96385+96391)95353
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – small + large, white mains cable (96382+96386)95354
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – small + large, transparent mains cable (96382+96390)95355
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – small + large, for T-bars 25 mm, white mains cable (96384+96388)95356
Wire suspension for single installation, 3x0.75 mm² Round ceiling cups – small + large, for T-bars 25 mm, transparent mains cable (96384+96391)95357
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – large, white mains cable (96371+96374)95358
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – large, transparent mains cable (96371+96378)95359
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – large, for T-bars 25 mm, white mains cable (96373+96376)95360
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – large, for T-bars 25 mm, transparent mains cable (96373+96379)95361
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – small + large, white mains cable (96370+96374)95362
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – small + large, transparent mains cable (96370+96378)95363
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – small + large for T-bars 25 mm, white mains cable (96372+96376)95364
Wire suspension for single installation, 3x0.75 mm² Square ceiling cups – small + large for T-bars 25 mm, transparent mains cable (96372+96379)95365
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – large, white mains cable (96383+96387)95366
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – large, transparent mains cable (96383+96392)95367
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – large, for T-bars 25 mm, white mains cable (96385+96389)95368
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – large, for T-bars 25 mm, transparent mains cable (96385+96393)95369
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – small + large, white mains cable (96382+96387)95370
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – small + large, transparent mains cable (96382+96392)95371
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – small + large, for T-bars 25 mm, white mains cable (96384+96389)95372
Wire suspension for single installation, 5x0.75 mm²Round ceiling cups – small + large, for T-bars 25 mm, transparent mains cable (96384+96393)95373
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – large, white mains cable (96371+96375)95374
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – large, transparent mains cable (96371+96380)95375
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – large, for T-bars 25 mm, white mains cable (96373+96377)95376
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – large, for T-bars 25 mm, transparent mains cable (96373+96381)95377
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – small + large, white mains cable (96370+96375)95378
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – small + large, transparent mains cable (96370+96380)95379
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – small + large for T-bars 25 mm, white mains cable (96372+96377)95380
Wire suspension for single installation, 5x0.75 mm²Square ceiling cups – small + large for T-bars 25 mm, transparent mains cable (96372+96381)95381
Wire suspension for support railsWire suspension for support rails 90015, 90016, 90017, 94052, 94067, 9406891426
