21914 Notor recessed LED Opal flush
Documents
Specification
643Design
Installation
Corner
Module
600x600
Light distribution
Direct
Louvre
Opal
Colour
White
RAL
9016
Light data & performance
Lumen output
2716
lm/W
112
CCT, K
3000
CRI
80
SDCM
3
Lumen maintenance 50 000 h
L93
Lumen maintenance 75 000 h
L89
Lumen maintenance 100 000 h
L86
Lumen maintenance L80 B50, h
100000
Lumen maintenance L90 B50, h
70000
LED driver, h/max failure %
100000/10
Energy class, LED module
C
Controls & connectivity
Driver brand
Tridonic
Electricity & enclosure
Rated supply voltage, V
220-240
Mains frequency, Hz
0, 50, 60
Protective class
1
IP rating
20
System Wattage
24
Min. ambient temperature, °C
-25
Max. ambient temperature, °C
25
MCB B10A, pcs
10
MCB B16A
16
MCB C10A
16
MCB C16A
26
THD, %
22
Surge protection CM, kV/kA
2
Surge protection DM, kV/kA
1
Power factor, 100 %
0.9
Dimensions
Length, mm
647
Width, mm
90
Height, mm
102
Weight, kg
2.3
Dimensions
Light distribution
Notor recessed
Fagerhult’s classic interior luminaire Notor is available in several versions for suspended, surface mounted or recessed installation. Notor is an obvious choice in contexts when there is a desire to create long, unbroken lines...
More about the family Notor recessed
