Multilume Re:Think Opal

A recessed general luminaire with a strong focus on sustainability. Body in Solid Board. Installation in ceiling with visible T-bars – VTB. Opal louvre provides efficient and optimal light comfort.

Installation

Recessed in suspended ceilings with visible T-bars, VTB 24 mm. Unventilated or ventilated building elements.

Connection

Connection in separate ballast box. Snap-in terminal block 3x1,5 mm² (x2), through-wiring possible. 5x1,5 mm² (x2) when dimming. Can also be supplied with mains cable and earthed plug or chassis mounted snap-in connector. The luminaire housing and driver are connected via a Quick Connection System.

Design

Solid Board luminaire body, hard recycled paper material. White visible surface. (RAL 9016).

Louvre

Opal plate in frosted UV stabil polystyrene.

Dimming

Organic Response – PIR sensor with presence and daylight control. All luminaires have master/slave functionality with IR communications.

Miscellaneous

IP 20. Luminaire body Class III. The supplied driver must be connected to protective earth. Fagerhult Plus luminaires are supplied with halogen-free mains cables. CLO (Constant Light Output) entails that the luminaire provides the same amount of light for the duration of its specified burn time.

Media

Fence - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Fence - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Compago - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Compago - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Multilume Re:Think

Multilume is our large family of recessed luminaires, which now have a new addition: Multilume Re:Think. With a body made entirely of hard cardboard, this lightweight luminaire is a step forward towards our sustainability promise ...

More about the family Multilume Re:Think

Document

Customise with Fagerhult Configure

Adapt and optimise the luminaire in Fagerhult’s configurator. You can easily select the CRI, colour temperature, optics, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.

  • Adapt and optimise the luminaire
  • Download unique data sheet and light data files
  • To order, contact your sales representative
Start configuration

Specification

Loading...

Filter

Name Description Art.no.
Name Description Art.no.
Frame for surface mounting Frame for surface mounting, H=60 (600x600). Fits Multilume Slim & Multilume Re:Think. Also with Organic Response (only with a fixed connection or cord and plug). 41028
Wieland T-connector Wieland 5-way T-connector 91026
Wieland T-connector Wieland 3-way T-connector 91025
IR dongle for Organic Response IR dongle for Organic Response equipped luminaire. 86279
Frame for surface mounting Frame for surface mounting (600x600 VTB). Fits Multilume Flat (only standard and DALI), Dwide as well as Multilume Slim, Multilume Slim Hygiene & Multilume Re:Think with Organic Response. 41026
Frame for surface mounting Frame for surface mounting, H=60 (300x1200 VTB). Fits Multilume Re:Think. Also with Organic Response (only with a fixed connection or cord and plug). 41029
WAGO connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 91244
WAGO connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 91243
Wieland connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 92793
WAGO T-connector WAGO T-Connector, 3-way, white 91067
WAGO T-connector WAGO T-connector, 5-way, 2 locking levers, blue 88228
Wieland connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 92799
Organic Response I/O box I/O box with potential-free 16A relay for controlling external units. 86413
External Organic Response sensor incl. DALI PSU External sensor incl. DALI PSU, recessed, 1 m cable 86407
Organic Response IoT Gateway Gateway for connection to Organic Response Portal. Incl. power adapter and wall bracket. Controls a maximum of 150 sensors. 86296
External Organic Response sensor incl. DALI PSU External sensor incl. DALI PSU, surface mounted, 1 m cable 86408
External Organic Response sensor incl. DALI PSU External sensor incl. DALI PSU, suspended pipe conduit installation, 1 m cable. pipe not included. 86409
External Organic Response sensor incl. DALI PSU Extern sensor incl. DALI PSU, suspended pipe conduit installation, 3.2 m cable. Pipe not included. 86412
External Organic Response sensor incl. DALI PSU External sensor incl. DALI PSU, surface mounted, 3.2 m cable 86411
External Organic Response sensor incl. DALI PSU External sensor incl. DALI PSU, recessed, 3.2 m cable 86410
Organic Response EnOcean Wireless Push button panel EnOcean 2 function push button panel, white 86416
Organic Response EnOcean Wireless Push button panel EnOcean 4 function push button panel, white 86417
Organic Response EnOcean Wireless Push button panel EnOcean 4 function push button panel, labeled, white 86437
Organic Response EnOcean Wireless Push button panel EnOcean 2 function push button panel, labeled, white 86436
Frame for surface mounting Dwide Multilume Re:Think & Multilume Slim, Surface mounted frame, 600x600. 41033
Frame for pendant installation H=60 mm Dwide & Multilume Slim pendant frame 600x600 incl. wires 41034
no-image placeholder Ensto connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 92786
no-image placeholder Ensto connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 92785
no-image placeholder Ensto power cable Length 2.0 m with female (without hooks) and male connectors, 5x1,5 mm². Halogen free. 92788
Ensto T-connector Ensto T-connector 3-way, white 92783
Ensto T-connector Ensto T-connector 5-way, grey 92784
no-image placeholder Ensto power cable Length 2.0 m with female (without hooks) and male connectors, 3x1,5 mm². Halogen free. 92787
Fence Fence 600x600 white. Only for T-bars T24. 41252
Fence Fence 600x600 champagne. Only for T-bars T24. 41254
Fence Fence 600x600 black. Only for T-bars T24. 41253
Sky frame Sky frame for ceiling window effect 600x600, white. Only for T-bars T24. 41245
Circle Ice Circle Ice 600x600 White. 41248
Circle Edge Circle with bevelled edge 600x600, White. 41246
Circle Circle with straight edge 600x600, White. 41247
Compago Compago framework 600x600, Grey. Only for T-bars T24. 41250
Compago Compago framework 600x600, white. Only for T-bars T24. 41249
Organic Response I/O box I/O box with potential-free 8A relay for controlling external units. 86433
Recessed frame solid ceiling Recessed frame for VTB frame 600x600 in solid ceiling (ceiling thickness 5 – 50 mm) Max. weight 4,5kg 41051
Recessed frame solid ceiling Recessed frame for VTB frame 300x600 in solid ceiling (ceiling thickness 5 – 50 mm) Max. weight 3kg 41048
Recessed frame solid ceiling Recessed frame for VTB frame 300x1200 in solid ceiling (ceiling thickness 5 – 50 mm) Max. weight 4kg 41049
