305039 Vivita

Light distribution

Symmetrical

Colour

Alu grey

RAL

9006

Lumen output

2034

CLO function active

Yes

CLO time, h

100000

lm/W

117

Light source colour

740

CCT, K

4000

CRI

70

SDCM

5

Lumen maintenance 100 000 h

L100

Lumen maintenance L100 B50, h

100000

LED driver, h/max failure %

100000/10

Energy class, LED module

D

Driver brand

Philips

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

50, 60

Protective class

1

IP rating

66

IK rating

10

Start W

17

End W

19

Average W

18

Stand by W

0.4

Min. ambient temperature, °C

-40

Max. ambient temperature, °C

25

MCB B10A, pcs

11

MCB B16A

18

MCB C10A

18

MCB C16A

30

THD, %

9

Surge protection CM, kV/kA

10

Surge protection DM, kV/kA

6

Power factor, 100 %

0.95

Projected wind area, m2

0.100

Height, mm

543

Diameter, mm

720

Weight, kg

8.6
