CirrusPost
Cirrus is a post-top luminaire designed for parks and green spaces. The luminaire offers high light comfort and a generous light pattern that aids orientation.
CirrusPost
Cirrus is a post-top luminaire designed for parks and green spaces. The luminaire offers high light comfort and a generous light pattern that aids orientation.
Installation
Luminaire for mounting on a post with post top Ø60 mm.
Connection
The luminaire is supplied with a mains cable; select the type and length in Fagerhult Configure. Driver with integrated surge protection: 6 kV between phase and neutral conductor (DM), 8 kV between phase/neutral conductor and protective earth (CM). Available in Class I and II. CLO (Constant Light Output).
Design
Post bracket, heat sink and cover made of cast aluminium, made from recycled material. Lacquered in anthracite grey (Gris 900 Sablé), alu-grey (RAL 9006 G70), graphite grey (RAL 7024 G70), traffic grey (RAL 7042 G70), black (RAL 9005 G70), black (RAL 9005 texture) or green (RAL 6009 G70).
Light Distribution
Symmetrical omnidirectional.
Light data
Optics
The inside of the aluminium cover is lacquered in white and serves as a reflector.
High efficiency
The product provides indirect light distribution, specifically adapted for urban environments and without compromising on energy efficiency. This creates a safe and comfortable atmosphere, while keeping energy consumption to a minimum.
Made of recycled aluminium
The product contains die-cast aluminium, a material that in our products consists of approximately 85% recycled content. By using recycled aluminium, energy consumption is reduced by up to 95% compared to virgin aluminium (Source: European Aluminium). This entails a significantly lower carbon footprint.
Resilient over time
The aluminium alloy that is used is of high quality, ensuring good corrosion protection. Together with other material choices that counteract galvanic corrosion, the design can withstand exposed conditions over time. A pressure equalisation valve regulates the air pressure and ensures that moisture cannot enter the luminaire – only escape.
Night-time dimming
Simple dimming where the light level is automatically reduced at preset times during the night, without the need for sensors or more advanced control technology.
Read moreZhaga Book 18Socket
Enables easy integration of sensors and communication modules via Zhaga socket.
Read more
Articles
Configure your Cirrus
Adapt and optimise the luminaire in Fagerhult's configurator.
Need more information?
Download a collection of light data files to guide you in your decision.
| Name | Description | Art.no. | Article PDF | |
|---|---|---|---|---|
|
Anti-glare shield | Cirrus Shield 125°, lacquered in alu-grey (RAL 9006 G70). | 301651-236 | |
|
Anti-glare shield | Cirrus Shield 165°, lacquered in alu-grey (RAL 9006 G70). | 301652-236 | |
|
Citygrid On Pole | The Citygrid On Pole unit enables all luminaires to be integrated into a Citygrid network. The unit is mounted on a pole and connects to the luminaire via cabling behind the pole cover plate. | 86492 | |
|
Citygrid dongle | Citygrid Dongle is the commissioning tool that in combination with the Citygrid Configuration app, enables the configuration of a Citygrid installation. | 86490 | |
|
Citygrid Zhaga Controller MKII | The Citygrid Zhaga Controller MKII is the intelligent device that transforms a luminaire into a smart luminaire. | 86505 |
