44087 Multilume Function LED

Documents

Specification

Technical data

Installation

Functional ceiling

Protection class

1

IP rating

20

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

Brand of driver

Osram

Design

Louvre

Beta

Colour

White

RAL

9016

Weight, kg

4.4

Length, mm

1935

Width, mm

126

Height, mm

69

Electrical data

MCB B10A

8

MCB B16A

13

MCB C10A

13

MCB C16A

22

Switch control, max no.

20

AM

Yes

Power on last level

Yes

Corridor function

Yes

Stand by W

0.25

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Effect, W

82

Power factor, 100 %

0.99

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

THD, %

10

Lighting data

Light distribution

Direct

Lumen output

9976

lm/W

122

Lumen maintenance L70 B10, h

75 000

Lumen maintenance L70 B50, h

100 000

Lumen maintenance L80 B10, h

45 000

Lumen maintenance L80 B50, h

70 000

Lumen maintenance L90 B10, h

25 000

Lumen maintenance L90 B50, h

35 000

Lumen maintenance 50 000 h

L86

Lumen maintenance 75 000 h

L79

Lumen maintenance 100 000 h

L73

Lumen maintenance at 50 000 h

0.86

LED driver, h/max failure %

100000/10

SDCM

3

CRI

80

CCT, K

3500

Light source

LED

Dimensions

Multilume Function LED

Illuminate the store in a comfortable way with reduced glare and decreased energy consumption with Multilume Function LED. Switching the luminaires in the store from T5 to efficient LED luminaires can save up to 50 % on energy...

Read more about the family Multilume Function LED
