Discovery Evo

See items

An effective all-round luminaire with IP 44 that satisfies needs in more demanding environments. An elegant design and a space-creating lighting pattern for stairwells, corridors, kitchens, bathrooms and cellars.

Installation

Four securing holes. For recess or surface mounting on ceilings or walls. Brackets for recessed installation ordered separately, please see accessories. There are holes for a surface mounted installation socket.
The luminaire must not be covered with insulation. For further details please refer to the assembly instructions.

Connection

230 V integrated LED driver. Snap-in terminal block 5x2.5 mm². 1-phase through-wiring possible. Cable entry at rear or via knockouts for surface mounting, through wiring 0° or 180°.

Design

Luminaire body of polycarbonate and diffuser of opal polycarbonate.

Emergency lighting

Decentralised emergency lighting luminaire, 3 h, with self-test AT4 and the possibility to connect a monitoring system based on communication via DALI. The system is not dependent on a DALI system being connected or in operation. Emergency lighting luminaires can be supplemented with sensor on request.

Dimming

e-Sense BrightSwitch – PIR sensors with lux threshold. Presence control on/off. Absence dimming high/low available on request.
e-Sense Detect – microwave sensors with lux threshold. Presence control on/off via relay or high/low, alternatively high/low/off via DALI.
e-Sense Move – microwave sensors with lux threshold. Presence control high/low/off. All luminaires have master/slave functionality with RF communications.

Accessories

Anti-ligature casing in white enamelled aluminium. Supplied with safety screws (tamper-proof torx) IK10, IP 55. Outdoor casing in lacquered aluminium, IK10, IP 55 with the possibility of a surface mounted mains cable.

Media

Outdoor accessory.

Discovery Evo wall mounted.

Discovery Evo

Discovery Evo is the new generation of Fagerhult’s classic multi-purpose luminaire. Developed to utilise all the benefits of LED technology, Discovery Evo is a versatile lighting concept that satisfies the requirements of...

More about the family Discovery Evo

Document

Instruction for use

Manual e-Sense Detect On/Off

Manual e-Sense Move DALI

Connection DALI resp. phase pulse dimming

Manual e-Sense Detect DALI

Manual e-Sense BrightSwitch

Product Brochure

Cleaning instruction

DWG

MAX

FBX

Revit

3Ds

Specification

Filter

Art.no. Effect, W Lumen output CCT, K Diameter, mm Light control Miscellaneous
Art.no. Effect, W Lumen output CCT, K Diameter, mm Light control Miscellaneous
57750 8 1120 3000 359
57750-469 8 1120 3000 359 e-Sense Detect on/off
57750-515 8 1120 3000 359 e-Sense BrightSwitch on/off
57751 8 1176 4000 359
57751-469 8 1176 4000 359 e-Sense Detect on/off
57751-515 8 1176 4000 359 e-Sense BrightSwitch on/off
57752 14 1808 3000 359
57752-402 14 1808 3000 359 DALI/Phase-pulse
57752-469 14 1808 3000 359 e-Sense Detect on/off
57752-495 14 1808 3000 359 e-Sense Detect DALI absence
57752-496 14 1808 3000 359 e-Sense Move DALI absence
57752-515 14 1808 3000 359 e-Sense BrightSwitch on/off
57754 14 1808 3000 359 Emergency lighting, 3 h
57755 14 1898 4000 359
57755-402 14 1898 4000 359 DALI/Phase-pulse
57755-469 14 1898 4000 359 e-Sense Detect on/off
57755-495 14 1898 4000 359 e-Sense Detect DALI absence
57755-496 14 1898 4000 359 e-Sense Move DALI absence
57755-515 14 1898 4000 359 e-Sense BrightSwitch on/off
57757 14 1898 4000 359 Emergency lighting, 3 h
57758 19 2438 3000 359
57758-402 19 2438 3000 359 DALI/Phase-pulse
57758-469 19 2438 3000 359 e-Sense Detect on/off
57758-495 19 2438 3000 359 e-Sense Detect DALI absence
57758-496 19 2438 3000 359 e-Sense Move DALI absence
57758-515 19 2438 3000 359 e-Sense BrightSwitch on/off
57759 19 2566 4000 359
57759-402 19 2566 4000 359 DALI/Phase-pulse
57759-469 19 2566 4000 359 e-Sense Detect on/off
57759-495 19 2566 4000 359 e-Sense Detect DALI absence
57759-496 19 2566 4000 359 e-Sense Move DALI absence
57759-515 19 2566 4000 359 e-Sense BrightSwitch on/off
57760 19 2438 3000 359 Emergency lighting, 3 h
57761 19 2566 4000 359 Emergency lighting, 3 h

Filter

Name Description Art.no.
Name Description Art.no.
Remote control e-Sense BrightSwitchRemote control86359
Remote control e-Sense Move DALIRemote control e-Sense Move DALI86305
Outdoor casing IK10Outdoor casing IK10, IP 55, white (RAL 9010)92653
Outdoor casing IK10Outdoor casing IK10, IP 55, anthracite grey (Gris 900 Sablé structured)92654
Outdoor casing IK10Outdoor casing IK10, IP 55, black (RAL 9005 structured)92655
Recess ringRecess rings including spring clips for recess mounting92650
Anti-ligature casing IK10Anti-ligature casing IK10, IP55, white92651
Mounting plate Discovery EvoMounting plate for recessed installation in soft tile suspended ceilings.92652
Recess ring IP44Recess rings including spring clips for recess mounting IP4492656
