Notor G2 ReLight kit
100405 ReLight 100405
Complete LED kit for replacing conventional T5 light sources. Existing opal or lamell louver is reused.
Installation
For mounting in an existing luminaire body.
Connection
For fixed connection in a terminal block 5x2.5 mm² in single luminaires. The start and continuous luminaires in the system are equipped with through-wiring (5x1.5 mm²) and quick connections between luminaire units. Delivered with 230 V, built-in LED driver in the kit
Louvre
The existing opal or lamell louver is reused. For versions using lamell louver, an opal diffuser film is included with the LED kit.
Light distribution
Direct.
Dimming
Luminaire with DALI/phase pulse control and CLO (Constant Light Output) as standard.
Organic Response – PIR sensor with presence and daylight control. All luminaires act as master/slave with IR communication.
ReLight
ReLight is a circular initiative focusing on reuse by using end-of-life luminaires and materials. By adding new technology and extending the life of the luminaire – we can together take your lighting solutions into the future.
... More about the family ReLightOther products
Document
Customise with Fagerhult Configure
Adapt and optimise the luminaire in Fagerhult’s configurator. You can easily select the CRI, colour temperature, optics, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.
- Adapt and optimise the luminaire
- Download unique data sheet and light data files
- To order, contact your sales representative
Specification
Loading...
Accessories Notor G2 Ripustettava suora/epäsuora Lamell
Filter
| Name | Description | Art.no. | |
|---|---|---|---|
| Name | Description | Art.no. | |
|
Notor G2 ReLight Opal Shade | Notor G2 Relight Opal Shade 1200mm | 96500 |
|
|
Notor G2 ReLight Opal Shade | Notor G2 Relight Opal Shade 1500mm | 96501 |
|
Notor G2 ReLight cover plate | Notor G2 ReLight cover plate 100mm Anodized | 96509 |
|
Notor G2 Relight Connectors | Organic Response-unit, anodized. For connecting max. 4 Notor G2 Relight DALI luminaires in continuous installation. Connects DALI in both directions. 200 mm. | 96510 |
|
|
Notor G2 Relight Connectors | Organic Response-unit, Anodized. For connecting max. 4 Notor G2 Relight DALI luminaires in continuous installation. Connects DALI to the left and breaks DALI to the right. 200 mm. | 96511 |
|
|
Notor G2 Relight Connectors | Organic Response-unit, anodized. For connecting max. 4 Notor G2 Relight DALI luminaires in continuous installation. Connects DALI to the right and breaks DALI to the left. 200 mm. | 96512 |
|
Notor G2 Relight Connectors | Notor G2 ReLight L-Connector Right. | 96513 |
|
Notor G2 Relight Connectors | Notor G2 ReLight L-Connector Left. | 96514 |
|
Notor G2 Relight Connectors | Notor G2 ReLight X-Connector. | 96515 |
|
Notor G2 Relight Connectors | Notor G2 ReLight T-Connector Right. | 96517 |
|
Notor G2 Relight Connectors | Notor G2 ReLight T-Connector left. | 96518 |
|
Notor G2 Relight Connectors | Notor G2 ReLight T-Connector Middle. | 96519 |
