Vialume 1

A post top luminaire with AGC lenses for excellent lighting properties and visual comfort, ideal for streets, footpaths, bicycle paths and smaller car parks. CLO for output consistency as standard.

Installation

Post top luminaire which in its standard design is mounted on a Ø 48 mm post arm bracket. For other mounting types and other options, see Accessories which are ordered separately. Variable tilting function ± 15º for perfect installation. Post height 5–8 m.

Connection

Connection cable 3x1.5 mm² type H07RN-F. 8 m up to 4300 lm. 10 m between 4301–7300 lm. 12 m between 7301–10300 lm. DALI version available on request, delivered with a 5-pin cable. Other cable versions on request.

Design

Body and post bracket in cast aluminium. Aluminium-zinc coated stainless screws. Driver is integrated in the luminaire. Hardened flat glass IK09. PMMA diffuser with IK10 on request.

Optics

AGC-lenses (Advanced Glare Control). The E-lens are designed to focus on illuminance. L lenses are ideal if the luminance from the ground is the main priority.

Dimming

Citygrid – PIR sensors with presence detection. Wireless communication via radio protocol.
Citygrid Linked – a wireless system for one or more luminaires. Can be up-graded to Citygrid Connected.
Citygrid Connected – a web-based solution with the ability to remotely control and review the lighting via a cloud hosted gateway which interacts with the installation. An additional subscription is required.
Citygrid-products, see accessories.
Night-time dimming 1 – dims down for six hours.
Night-time dimming 2 – dims down for eight hours.
DALI version are available on request.

Designed by

ÅF Lighting and Tuxen Design.

Standard colour

Alu-grey (RAL 9006, semi-gloss).
Anthracite grey (Gris 900 Sablé), black (RAL 9005) or white (RAL 9010, semi-gloss) on request.

LED-information

Driver with integrated surge protection (6 kV).
Extra surge protection (10 kV) available on request.

Miscellaneous

Available in Classes 1 and 2.
Luminaire with Zhaga D4i-certified driver on request. NEMA socket on request.

CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

Media

Variable tilting function

Lenses.

Vialume

A Nordic expression – several areas of applicationTaking inspiration from the beautiful Nordic light, we created Vialume 1 – Fagerhult’s first self-manufactured post top luminaire for city streets, smaller roads and car parks....

More about the family Vialume

Document

Customise with Fagerhult Configure

Adapt and optimise the luminaire in Fagerhult’s configurator. You can easily select the CRI, colour temperature, optics, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.

  • Adapt and optimise the luminaire
  • Download unique data sheet and light data files
  • To order, contact your sales representative
Start configuration

Specification

Loading...

Filter

Name Description Art.no.
Name Description Art.no.
Bracket for Vialume 1Bracket for Ø 76 mm post top. Alu-grey.309902
Bracket for Vialume 1Bracket for Ø 60 mm post top. Alu-grey.309901
Double post-top bracket for Vialume 1Double post-top bracket for Ø 76 mm post top. Alu-grey.309904
Double post-top bracket for Vialume 1Double post-top bracket for Ø 60 mm post top. Alu-grey.309903
no-image placeholder Spigot for post arm Ø 60 mmAnthracite grey (Gris 900 Sablé).301050-329
no-image placeholder Spigot for post arm Ø 60 mmAlu-grey (RAL 9006, gloss 70).301050-235
no-image placeholder Spigot for post arm Ø 60 mmBlack (RAL 9005)301050-230
no-image placeholder Spigot for post arm Ø 60 mmWhite (RAL 9010, gloss 50)301050-311
Spigot for post arm Ø 60 mmUntreated301050
Bracket for Vialume 1Bracket for Ø 60 mm post top. Alu-grey (RAL 9006).309900
Glare ShieldGlare Shield 4 LED303541
Glare ShieldGlare Shield 7 LED303543
Glare ShieldGlare Shield 9 LED303545
Wall bracket for Vialume and OpalumeWall bracket arm Ø 48 (standard).303677-235
Citygrid dongleCitygrid Dongle is the commissioning tool that in combination with the Citygrid Configuration app, enables the configuration of a Citygrid installation.86490
Citygrid On PoleThe Citygrid On Pole unit enables all luminaires to be integrated into a Citygrid network. The unit is mounted on a pole and connects to the luminaire via cabling behind the pole cover plate.86492
Citygrid GatewayCitygrid Gateway is the bridge between the luminaire's Citygrid controllers and the cloud, which enables data to be displayed on the Citygrid Dashboard. Comes with the Citygrid Gateway Cabinet Kit with 2-wire 1.5 m cable for mounting in electrical cabinets.86495
Citygrid On Pole mounting kit for gatewayCitygrid Gateway Pole Kit with 2-wire 8 m cable. Enables mounting on poles.86496
