A recessed luminaire with two light distribution patterns. A separate hidden spotlight module in the centre that can be turned on and off as required, e.g. for illuminating a patient bed and a wide-beam opal diffuser for general lighting. A bevelled outer edge that provides a soft luminance transition to the ceiling.
Recessed installation in suspended ceilings. Unventilated or ventilated ceilings. Stable assembly springs included. When installing in soft tile ceilings, mounting plates must be used, see accessories. The ballast housing is separate for flexible and quick installation.
Do not cover with insulation. For detailed information, see the installation instructions.
Connection in separate ballast housing. Quick release terminal block 5x1.5 mm² (x2), onward connection possible. 5x1.5 mm² (x2) when dimming. Can also be supplied with a frame-mounted snap-in connector in the ballast where there is the possibility for a T-splitter. Luminaire body and driver are delivered interconnected.
Luminaire in white (RAL 9016) structured finish. Luminaire housing of enamelled deep drawn aluminium.
Opal - opal louvre shutters made from PMMA.
All models come with 2 drivers. Separate driver for spot module. Luminaires with Tunable White (2700 – 6500 K) are equipped with the DALI Device type 8 driver. Luminaire with Tunable White in combination with Amber comes with two separate drivers, one 2-channel for spot module/amber.
CLO (Constant Light Output) means that the luminaire provides the same amount of light for the duration of its specified burn time.
The supplied driver must be connected to protective earth.
Pozzo is like a small piece of sky, a lightwell effect that brings a daylight feel into all types of rooms. Drawing inspiration from natural light, a pleasant daylight feel is created, and the classic round shape and bevelled...More about the family Pozzo
Customise with Fagerhult Configure
Adapt and optimise the luminaire in Fagerhult’s configurator. You can easily select the CRI, colour temperature, optics, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.
- Adapt and optimise the luminaire
- Download unique data sheet and light data files
- To order, contact your sales representative
