Zkye 55 G2 PendantTrack
Zkye is a family of efficient, compact spotlights in a minimalist design for atmospheric lighting in shops and offices. Available with multiple colour temperatures and control options. The pendant is track-mounted.
Zkye 55 G2 PendantTrack
Zkye is a family of efficient, compact spotlights in a minimalist design for atmospheric lighting in shops and offices. Available with multiple colour temperatures and control options. The pendant is track-mounted.
Installation
Supplied with track adapter for Control Track or 3-phase track. For detailed information, see the installation instructions.
Connection
Adapter for 3-phase track or Control Track (DALI). Integrated driver in luminaire.
Design
Luminaire housing made of aluminium. White (RAL 9016) or black (RAL 9005) structured lacquer.
Light Distribution
Narrow, medium or wide beam.
Light data
Optics
Spun reflector.
Minimised design
The luminaire’s minimised design, with its high luminous efficacy, means that less material is used in manufacturing. This contributes to a low climate impact and more efficient use of resources compared to traditional, larger luminaires, without compromising on function or light quality.
Flexible installation & longer working life
The luminaire is mounted on a track and designed to be easily moved, adapted and reused to meet changing needs – rather than being replaced with a new one. Disconnecting and reinstalling the luminaire in a new location extends its working life and reduces resource use.
Optimised packaging
Multiple products can be packaged together, reducing the amount of packaging material and cutting resource use and climate impact in both production and transportation. This makes the logistics more efficient and simplifies the handling and recycling of the packaging, as fewer types of material are used.
DALI/Phase pulse control
Combines digital DALI control with traditional phase control – a flexible solution that allows both precise dimming and easy installation.
e-Sense StagePIR sensor
Dynamic system for e.g. retail and showrooms, which uses Casambi technology to easily create and control various lighting scenarios via an app.
Read moreTrailing Edge
Also known as rear edge control, it provides quiet and stable dimming, particularly suitable for environments such as offices, residences and hotels.
On/Off
Simple control method where the lighting is turned on or off without dimming. For environments with basic lighting needs and clear control.
Articles
| Art.no. | System Wattage | Lumen output | CCT, K | CRI | Colour | Diameter, mm | Dimensions, mm | Light distribution | Installation | Light control | Miscellaneous | Light data files | Article PDF |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 65166-504 | 14 | 963 | 2700 | 90 | White | 55 | 246 | Wide Beam, 35° | Control Track | DALI | Dim to warm |
|
|
| 65166-522 | 14 | 963 | 2700 | 90 | White | 55 | 246 | Wide Beam, 35° | 3-phase track | e-Sense Stage integrated | Dim to warm |
|
|
| 65166-527 | 14 | 963 | 2700 | 90 | White | 55 | 246 | Wide Beam, 35° | 3-phase track | Trailing Edge | Dim to warm |
|
|
| 65167-504 | 14 | 963 | 2700 | 90 | Black | 55 | 246 | Wide Beam, 35° | Control Track | DALI | Dim to warm |
|
|
| 65167-522 | 14 | 963 | 2700 | 90 | Black | 55 | 246 | Wide Beam, 35° | 3-phase track | e-Sense Stage integrated | Dim to warm |
|
|
| 65167-527 | 14 | 963 | 2700 | 90 | Black | 55 | 246 | Wide Beam, 35° | 3-phase track | Trailing Edge | Dim to warm |
|
|
| 65204 | 14 | 1501 | 2700 | 90 | White | 55 | 246 | Narrow Beam, 15° | 3-phase track | On/off |
|
||
| 65204-504 | 14 | 1501 | 2700 | 90 | White | 55 | 246 | Narrow Beam, 15° | Control Track | DALI |
|
||
| 65204-522 | 14 | 1501 | 2700 | 90 | White | 55 | 246 | Narrow Beam, 15° | 3-phase track | e-Sense Stage integrated |
|
||
| 65204-527 | 14 | 1501 | 2700 | 90 | White | 55 | 246 | Narrow Beam, 15° | 3-phase track | Trailing Edge |
|
||
| 65205 | 14 | 1501 | 2700 | 90 | Black | 55 | 246 | Narrow Beam, 15° | 3-phase track | On/off |
|
||
| 65205-504 | 14 | 1501 | 2700 | 90 | Black | 55 | 246 | Narrow Beam, 15° | Control Track | DALI |
|
||
| 65205-522 | 14 | 1501 | 2700 | 90 | Black | 55 | 246 | Narrow Beam, 15° | 3-phase track | e-Sense Stage integrated |
|
||
| 65205-527 | 14 | 1501 | 2700 | 90 | Black | 55 | 246 | Narrow Beam, 15° | 3-phase track | Trailing Edge |
|
||
| 65206 | 14 | 1498 | 2700 | 90 | White | 55 | 246 | Medium Beam, 24° | 3-phase track | On/off |
|
||
| 65206-504 | 14 | 1498 | 2700 | 90 | White | 55 | 246 | Medium Beam, 24° | Control Track | DALI |
|
||
| 65206-522 | 14 | 1498 | 2700 | 90 | White | 55 | 246 | Medium Beam, 24° | 3-phase track | e-Sense Stage integrated |
|
||
| 65206-527 | 14 | 1498 | 2700 | 90 | White | 55 | 246 | Medium Beam, 24° | 3-phase track | Trailing Edge |
|
||
| 65207 | 14 | 1498 | 2700 | 90 | Black | 55 | 246 | Medium Beam, 24° | 3-phase track | On/off |
|
||
| 65207-504 | 14 | 1498 | 2700 | 90 | Black | 55 | 246 | Medium Beam, 24° | Control Track | DALI |
|
||
| 65207-522 | 14 | 1498 | 2700 | 90 | Black | 55 | 246 | Medium Beam, 24° | 3-phase track | e-Sense Stage integrated |
|
||
| 65207-527 | 14 | 1498 | 2700 | 90 | Black | 55 | 246 | Medium Beam, 24° | 3-phase track | Trailing Edge |
|
||
| 65208 | 14 | 1542 | 2700 | 90 | White | 55 | 246 | Wide Beam, 37° | 3-phase track | On/off |
|
||
| 65208-504 | 14 | 1542 | 2700 | 90 | White | 55 | 246 | Wide Beam, 37° | Control Track | DALI |
|
||
| 65208-522 | 14 | 1542 | 2700 | 90 | White | 55 | 246 | Wide Beam, 37° | 3-phase track | e-Sense Stage integrated |
|
||
| 65208-527 | 14 | 1542 | 2700 | 90 | White | 55 | 246 | Wide Beam, 37° | 3-phase track | Trailing Edge |
|
||
| 65209 | 14 | 1542 | 2700 | 90 | Black | 55 | 246 | Wide Beam, 37° | 3-phase track | On/off |
|
||
| 65209-504 | 14 | 1542 | 2700 | 90 | Black | 55 | 246 | Wide Beam, 37° | Control Track | DALI |
|
||
| 65209-522 | 14 | 1542 | 2700 | 90 | Black | 55 | 246 | Wide Beam, 37° | 3-phase track | e-Sense Stage integrated |
|
||
| 65209-527 | 14 | 1542 | 2700 | 90 | Black | 55 | 246 | Wide Beam, 37° | 3-phase track | Trailing Edge |
|
||
| 65210 | 14 | 1516 | 3000 BBBL | 90 | White | 55 | 246 | Narrow Beam, 15° | 3-phase track | On/off |
|
||
| 65210-504 | 14 | 1516 | 3000 BBBL | 90 | White | 55 | 246 | Narrow Beam, 15° | Control Track | DALI |
|
||
| 65210-522 | 14 | 1516 | 3000 BBBL | 90 | White | 55 | 246 | Narrow Beam, 15° | 3-phase track | e-Sense Stage integrated |
|
||
| 65210-527 | 14 | 1516 | 3000 BBBL | 90 | White | 55 | 246 | Narrow Beam, 15° | 3-phase track | Trailing Edge |
|
||
| 65211 | 14 | 1516 | 3000 BBBL | 90 | Black | 55 | 246 | Narrow Beam, 15° | 3-phase track | On/off |
|
||
| 65211-504 | 14 | 1516 | 3000 BBBL | 90 | Black | 55 | 246 | Narrow Beam, 15° | Control Track | DALI |
|
||
| 65211-522 | 14 | 1516 | 3000 BBBL | 90 | Black | 55 | 246 | Narrow Beam, 15° | 3-phase track | e-Sense Stage integrated |
|
||
| 65211-527 | 14 | 1516 | 3000 BBBL | 90 | Black | 55 | 246 | Narrow Beam, 15° | 3-phase track | Trailing Edge |
|
||
| 65212 | 14 | 1513 | 3000 BBBL | 90 | White | 55 | 246 | Medium Beam, 24° | 3-phase track | On/off |
|
||
| 65212-504 | 14 | 1513 | 3000 BBBL | 90 | White | 55 | 246 | Medium Beam, 24° | Control Track | DALI |
|
||
| 65212-522 | 14 | 1513 | 3000 BBBL | 90 | White | 55 | 246 | Medium Beam, 24° | 3-phase track | e-Sense Stage integrated |
|
||
| 65212-527 | 14 | 1513 | 3000 BBBL | 90 | White | 55 | 246 | Medium Beam, 24° | 3-phase track | Trailing Edge |
|
||
| 65213 | 14 | 1513 | 3000 BBBL | 90 | Black | 55 | 246 | Medium Beam, 24° | 3-phase track | On/off |
|
||
| 65213-504 | 14 | 1513 | 3000 BBBL | 90 | Black | 55 | 246 | Medium Beam, 24° | Control Track | DALI |
|
||
| 65213-522 | 14 | 1513 | 3000 BBBL | 90 | Black | 55 | 246 | Medium Beam, 24° | 3-phase track | e-Sense Stage integrated |
|
||
| 65213-527 | 14 | 1513 | 3000 BBBL | 90 | Black | 55 | 246 | Medium Beam, 24° | 3-phase track | Trailing Edge |
|
||
| 65214 | 14 | 1558 | 3000 BBBL | 90 | White | 55 | 246 | Wide Beam, 37° | 3-phase track | On/off |
|
||
| 65214-504 | 14 | 1558 | 3000 BBBL | 90 | White | 55 | 246 | Wide Beam, 37° | Control Track | DALI |
|
||
| 65214-522 | 14 | 1558 | 3000 BBBL | 90 | White | 55 | 246 | Wide Beam, 37° | 3-phase track | e-Sense Stage integrated |
|
||
| 65214-527 | 14 | 1558 | 3000 BBBL | 90 | White | 55 | 246 | Wide Beam, 37° | 3-phase track | Trailing Edge |
|
||
| 65215 | 14 | 1558 | 3000 BBBL | 90 | Black | 55 | 246 | Wide Beam, 37° | 3-phase track | On/off |
|
||
| 65215-504 | 14 | 1558 | 3000 BBBL | 90 | Black | 55 | 246 | Wide Beam, 37° | Control Track | DALI |
|
||
| 65215-522 | 14 | 1558 | 3000 BBBL | 90 | Black | 55 | 246 | Wide Beam, 37° | 3-phase track | e-Sense Stage integrated |
|
||
| 65215-527 | 14 | 1558 | 3000 BBBL | 90 | Black | 55 | 246 | Wide Beam, 37° | 3-phase track | Trailing Edge |
|
| Name | Description | Art.no. | Article PDF | |
|---|---|---|---|---|
|
e-Sense Stage RTC Backup | e-Sense Stage Stand-Alone Control Box RTC Backup | 99816 | |
|
|
e-Sense Stage Relay | e-Sense Stage Stand-Alone Control Box Relay | 99814 | |
|
|
e-Sense Stage Trailing Edge | e-Sense Stage Stand-Alone Control Box Trailing Edge | 99813 | |
|
e-Sense Stage 4CH PWM | e-Sense Stage Stand-Alone Control Box 4 CH PWM | 99815 | |
|
|
e-Sense Stage Stand-alone DALI | e-Sense Stage Stand-Alone Control Box DALI | 99812 | |
|
Xpress push button panel | Xpress push button panel with long range, white. | 82178 | |
|
Xpress push button panel | Xpress push button panel with long range, black. | 82179 |
