Pleiad G4 Robust
22891 Pleiad G4 22891Downlight with protection class IK 10 for increased security. The reflector ring is fastened with a safety screw to prevent access and dismantling.
Installation
Recessed mounting in unventilated or ventilated suspended ceilings. Separate driver and installation clip for easy and tool-free installation supplied as standard. An assembly plate must be used when mounting on soft tile ceilings, see accessories. For detailed information, see the installation instructions.
Connection
Connection in separate driver box. Snap-in terminal block 3x1.5 mmm² (x2), onward connection possible. 5x1.5 mm² (x2) when dimming. Can also be supplied with chassis mounted snap-in connector in the ballast where a T-splitter or mains cable and plug are possible. The luminaire body and driver are interconnected with a snap-in connector.
Design
Luminaire body in cast aluminium. Two-part visible edge ring in aluminium. The luminaire has durable PETG plates in the light openings between the rings. The luminaire and the edge rings are locked using tamper-proof torx screws.
Reflector
Reflector of metallised aluminium. Lens of clear acrylic.
Miscellaneous
IK 10. IP 64 under a suspended ceiling, IP 20 above a suspended ceiling. Luminaire body Class III. The supplied driver must be connected to the protective earth. Luminaires with Tunable White (2700 – 6500 K) are equipped with driver DALI Device type 8. For loads in the suspended ceiling system, follow the selected suspended ceiling supplier’s recommendation. CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.
Media
Pleiad G4 – Installation
Pleiad G4
Pleiad G4 is the latest evolution of Fagerhult's classic downlight series. Even more efficient. Even better visual comfort. Even quicker to install.
Pleiad G4 simplifies and streamlines advanced lighting planning for entire...
More about the family Pleiad G4Document
Customise with Fagerhult Configure
Adapt and optimise the luminaire in Fagerhult’s configurator. You can easily select the CRI, colour temperature, optics, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.
- Adapt and optimise the luminaire
- Download unique data sheet and light data files
- To order, contact your sales representative
Specification
Loading...
Accessories Notor G2 Ripustettava suora/epäsuora Lamell
Filter
Name | Description | Art.no. | |
---|---|---|---|
Name | Description | Art.no. | |
Wieland T-connector | Wieland 5-way T-connector | 91026 | |
Wieland T-connector | Wieland 3-way T-connector | 91025 | |
Mounting plate | Mounting plate | 41956 | |
WAGO connection cables, 3-way | Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. | 91244 | |
WAGO connection cables, 5-way | Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. | 91243 | |
Wieland connection cables, 3-way | Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. | 92793 | |
WAGO T-connector | WAGO T-Connector, 3-way, white | 91067 | |
WAGO T-connector | WAGO T-connector, 5-way, 2 locking levers, blue | 88228 | |
Wieland connection cables, 5-way | Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. | 92799 | |
Cover plate IP 21 | Cover plate IP 21, Ø165 | 41060 | |
Ensto connection cables, 5-way | Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. | 92786 | |
Ensto connection cables, 3-way | Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. | 92785 | |
Ensto power cable | Length 2.0 m with female (without hooks) and male connectors, 5x1,5 mm². Halogen free. | 92788 | |
Ensto T-connector | Ensto T-connector 3-way, white | 92783 | |
Ensto T-connector | Ensto T-connector 5-way, grey | 92784 | |
Ensto power cable | Length 2.0 m with female (without hooks) and male connectors, 3x1,5 mm². Halogen free. | 92787 |
