23664 Multilume Hydro Anti-ligature LED

Documents

Specification

Technical data

Installation

Recessed

Protection class

1

IP rating

65

IP rating (above suspended ceilings)

50

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

Brand of driver

Tridonic

Design

Louvre

Delta

Colour

White

Weight, kg

7.7

Length, mm

1255

Width, mm

355

Height, mm

74

Module

300x1200

Electrical data

MCB B10A

11

MCB B16A

17

MCB C10A

18

MCB C16A

28

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Effect, W

33

Power factor, 100 %

0.95

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

THD, %

10

Lighting data

Light distribution

Direct

Lumen output

4415

lm/W

133

Lumen maintenance L80 B10, h

100 000

Lumen maintenance L90 B10, h

50 000

Lumen maintenance L90 B50, h

70 000

Lumen maintenance 50 000 h

L92

Lumen maintenance 75 000 h

L89

Lumen maintenance 100 000 h

L86

Lumen maintenance at 50 000 h

0.91

LED driver, h/max failure %

100000/10

SDCM

3

CRI

80

CCT, K

4000

Light source

LED

Dimensions

Light distribution

Multilume Hydro LED

Multilume Hydro LED is a new generation of energy-efficient luminaires for demanding environments. By combining a slender, tempered glass cover with a microprismatic Delta louvre, we have created an aesthetically pleasing...

Read more about the family Multilume Hydro LED
