An encapsulated industrial luminaire for exposed and cold environments. With protection class IP 67, Kaptur is an excellent choice for garages or culverts.
Surface-mounted, wall, cord and cable with ceiling bracket. Bracket, see accessories.
Two cable-entry equipped with insertion holes Ø 22 mm – one in each end cap. Snap-in terminal block 5 x 2.5 mm²; option of through-wiring.
Luminaire body of PS plastic. Mounting plate in white enamelled steel sheet.
Opal diffuser made of plastic, acrylic (PMMA, IK03) or polycarbonate (PC, IK08) with stainless steel shade catch. The shade has internal, lengthways grooves.
e-Sense Detect – microwave sensors with lux threshold. Presence control on/off via relay or high/low, alternatively high/low/off via DALI.
e-Sense Move – microwave sensors with lux threshold. Presence control high/low/off. All luminaires have master/slave functionality with RF communications.
Luminaire satisfies the requirements for D-marking, i.e. limited surface temperature (90 °C) as set out in the Electrical installation regulations EN 436 40 00.
Kaptur is a durable and reliable encapsulated industrial luminaire, capable of doing those jobs that require a little extra. Its durable design is suitable for exposed and temperature-extreme environments, such as parking...More about the family Kaptur
Accessories Notor G2 Ripustettava suora/epäsuora Lamell
|Adjustable ceiling bracket||Adjustable ceiling bracket/pair||91374|
|Wall bracket||L=150 mm (apiece)||91508|
|Wall bracket||Length 250 mm||91509|
|Adjustable wall bracket||Adjustable wall bracket/pair||91375|
|Remote control e-Sense Move||Remote control e-Sense Move.||86305|
|Wall bracket||135 °, L=200 mm/st||91313|
|Spare shade||Spare shade acrylic 600 mm.||95420|
|Spare shade||Spare shade acrylic 1200 mm.||95421|
|Spare shade||Spare shade acrylic 1500 mm.||95422|
|Spare shade||Spare shade polycarbonate 600 mm.||95423|
|Spare shade||Spare shade polycarbonate 1200 mm.||95424|
|Spare shade||Spare shade polycarbonate 1500 mm.||95425|
