Control Track is a controllable 3-phase track. It is easy to install and compatible with all luminaires with a Euro standard plus adaptor. The track is available in surface mounted and recessed versions. Now also as double track, Control Track Dual, for suspended installation. Control Track gives a smooth a clean impression in the ceiling.

Installation

Control Track can either be surface mounted, wire pendant or recessed into the ceiling. Control Track Dual is only suitable for suspended installation.

Connection

Control Track is a 6 circuit track with, 3 phases, 2 control wires, 1 neutral wire and with a protective earth, designed for 230V, 3x16A current max 3,68 kVA. It supports DALI on the 2 integrated control wires.

Design

The rail is in extruded aluminium and the accessories are in plastic, it comes in two different colours.

Anodized aluminium with grey accessories, black (RAL 9005) and white (RAL 9010). Recessed version is in our standard offer only available in white.

Dimming

DALI as standard.

Control Track

Control Track

Control Track is a stylish and minimalist single or double track that enables uplight and downlight in combination with freely mounted luminaires. The single and double tracks can be combined, and the many connection options...

More about the family Control Track

Document

Connection DALI resp. phase pulse dimming

Instruction for use Control Track

Instruction for use Control Track Dual

Customise with Fagerhult Configure

Create your optimal track system in Fagerhult’s configurator. You can easily select tracks, luminaires, CRI, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.

  • Create and draw your optimal track system
  • Download unique data sheet and light data files
  • To order, contact your sales representative
Configure track system

Specification

Loading...

Filter

Name Description Art.no.
Name Description Art.no.
Control Track suspension hook Control Track suspension hook, white. 82464
Control Track cutting tool fort track conductors Control Track cutting tool fort track conductors. 82460
Control Track T-coupler white Control Track T-coupler Control Track T-coupler right / White. 82518
Control Track T-coupler black Control Track T-coupler Control Track T-coupler left / Black. 82517
Control Track T-coupler white Control Track T-coupler Control Track T-coupler left / White. 82515
Control Track X-coupler black Control Track X-coupler Control Track X-coupler / Black. 82523
Control Track X-coupler white Control Track X-coupler Control Track X-coupler / White. 82521
Ceiling Bracket T-bars white Control Track bracket Ceiling bracket, T-bars 25 mm / White. 82496
Control Track Middle Feed black Control Track middle feed Control Track middle feed / Black. 82508
Control Track Middle Feed white Control Track middle feed Control Track middle feed / White. 82506
Control Track L-coupler black Control Track L-coupler Control Track L-coupler right / Black. 82514
Control Track L-coupler white Control Track L-coupler Control Track L-coupler right / White. 82512
Control Track L-coupler black Control Track L-coupler Control Track L-coupler left / Black. 82511
Control Track T-coupler Rec white Control Track recessed T-coupler Control Track recessed T-coupler left / White. 82475
Control Track L-coupler Recessed white Control Track recessed L-coupler Control Track recessed L-coupler, right / White. 82474
Control Track Main End Feed black Control Track, main end feed Control Track main end feed right / Black. 82505
Control Track L-coupler Recessed white Control Track recessed L-coupler Control Track recessed L-coupler left / White. 82473
Control Track recessed middle feed Control Track recessed middle feed / White. 82472
Control Track Main End Feed Recessed white Control Track recessed main end feed Control Track recessed main end feed right / White. 82471
Control Track Main End Feed white Control Track, main end feed Control Track main end feed right / White. 82503
Control Track Main End Feed Recessed white Control Track recessed main end feed Control Track recessed main end feed left / White. 82470
Control Track End Cap black Control Track end cap Control Track end cap / Black. 82532
Control Track Main End Feed white Control Track, main end feed Control Track main end feed left / White. 82500
Control Track End Cap white Control Track end cap Control Track end cap / White. 82530
Control Track adjustable coupler Control Track flexible coupler / Black. 82529
Control Track adjustable coupler Control Track flexible coupler / White. 82527
Control Track Straight Coupler black Control Track straight coupler Control Track straight coupler / Black. 82526
Control Track Straight Coupler white Control Track straight coupler Control Track straight coupler / White. 82524
Control Track Main End Feed black Control Track, main end feed Control Track main end feed left / Black. 82502
Control Track wire bracket Control Track wire bracket / Black. 82482
Control Track X-coupler Rec white Control Track recessed X-coupler Control Track recessed X-coupler / White. 82477
Control Track T-coupler Rec white Control Track recessed T-coupler Control Track recessed T-coupler right / White. 82476
Control Track wire bracket Control Track wire bracket / White. 82480
Control Track L-coupler white Control Track L-coupler Control Track L-coupler, left / White. 82509
Control Track T-coupler black Control Track T-coupler Control Track T-coupler right / Black. 82520
Control Track cover white 1000 mm Control Track Cover Control track cover 1000 mm / White. 82584
Control Track cover black 1000 mm Control Track Cover Control track cover 1000 mm / Black. 82585
Wall bracket for Control Track. Distance from wall to track center: 80mm Control Track wall bracket / Black. 46784
Wall bracket for Control Track. Distance from wall to track center: 80mm Control Track wall bracket / White. 46783
Control Track Adapter white Control Track adapter incl strain relief and nipple Control Track adapter incl strain relief and nipple M13 white. 96646
Control Track Adapter black Control Track adapter incl strain relief and nipple Control Track adapter incl strain relief and nipple M13 black. 96648
Control Track wire bracket including 4 m wire Control Track wire bracket including 4 m wire 1,2 mm, white. 10 pieces. 97956
Control Track wire bracket including 4 m wire Control Track wire bracket including 4 m wire 1,2 mm, black. 10 pieces. 97958
Control Track Ceiling Bracket Ceiling bracket in zinc plated steel. 82461
Control Track fixpoint Track fixpoint / White. 82040
Control Track fixpoint Track fixpoint / Black. 82042
Control Track coupler support white Control Track coupler support Control Track coupler support, white. 97960
Control Track coupler support black Control Track coupler support Control Track coupler support, black. 97961
Control Track T-coupler white Control Track T-coupler Control Track T-coupler left / White. 82536
Control Track T-coupler black Control Track T-coupler Control Track T-coupler left / Black. 82538
Control Track T-coupler white Control Track T-coupler Control Track T-coupler right / White. 82540
Control Track T-coupler black Control Track T-coupler Control Track T-coupler right / Black. 82541
Control Track recessed frame fixpoint Control Track recessed frame fixpoint / White. 82043
Control Track frame fixpoint black Control Track recessed frame fixpoint Control Track recessed frame fixpoint / Black. 82044
Clip T-Bar white Control Track bracket Clip white for T-bar 25 mm for wire 97147
Clip T-Bar black Control Track bracket Clip for T-bar 25 mm for wire, black 97764
no-image placeholder Control Track bracket Control Track snap on track bracket for HTB 24mm ceilings, white 98978
no-image placeholder Control Track bracket Control Track snap on track bracket for HTB 24mm ceilings, black 98979
Clips T-bar, with hook, white Control Track bracket Clips for t-bar, 25 mm, with hook. 97137
Control Track Dual, bracket for joint support Control Track bracket Control Track Dual brackets for joint support. 97690
Control Track Dual, wire suspension kit, white Control Track Dual wire suspension kit Control Track Dual wire suspension kit 4m, white. 97599
Control Track Dual, wire suspension kit, black Control Track Dual wire suspension kit Control Track Dual wire suspension kit 4m, black. 97611
no-image placeholder Control Track suspension hook Control Track suspension hook, black. 82483
no-image placeholder Control Track straight coupler Control track, Straight coupler without control connection, white 98984
no-image placeholder Control Track straight coupler Control track, Straight coupler without control connection, black 98985
Control Track Dual all
