Opalume Post
131797 Opalume 131797
Post luminaire with high performance and light comfort and CLO for an even output. Available in two different designs, conical and spherical, with the possibility of RBGW. Optimised light pattern with AGC lenses developed for road lighting.
Installation
Luminaire for mounting on arm, Ø48 mm and Ø60 mm. For mounting top of the post, see Accessories
Connection
Connecting cable is selectable in Configure.
Design
Diffuser of opal acrylic or spun aluminium in standard colors. Any color on request. Steel post bracket. Hardened flat glass. Fastener of A4 quality with zinc coating. Other details in die-cast aluminium.
Optics
AGC lenses (Advanced Glare Control). The E-lenses are designed with a focus on illuminance. L lenses are the choice if the luminance from the roadway is in focus.
Dimming
DALI and Night-time dimming are selectable in Configure. e-Sense Motion on request.
LED-information
Driver with integrated surge protection, CM 8kV, DM 6kV. Extra surge protection of 10 kV on request.
Miscellaneous
Available in class I and II. Zhaga and NEMA adapter on request. CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.
Media
Opalume
Opalume is a range of weatherproof luminaires for streets and roads, combining high performance with excellent light comfort. The luminaire is available in conical and spherical designs, the carefully balanced proportions and...
More about the family OpalumeOther products
Document
Dostosuj za Pomocą Konfiguracji Fagerhult
Dostosuj i zoptymalizuj oprawę w konfiguratorze Fagerhult. Na przykład można łatwo wybrać CRI, temperaturę barwową, optykę, przepływ światła, sterowanie i różne opcje połączeń. Wszystkie Twoje wybory są zapisywane w arkuszu danych produktu, który można pobrać wraz z unikalnymi plikami danych świetlnych.
- Adapt and optimise the luminaire
- Download unique data sheet and light data files
- To order, contact your sales representative
Specification
