A recessed luminaire for suspended ceilings with visible T-bars. The tempered glass cover is easy to clean and withstands disinfecting cleaning products. Delta louvres provide efficiency and optimal lighting comfort. Recessed depth 23 mm.
Recessed mounting in ventilated or unventilated suspended ceilings.
VTB – for suspended ceilings with visible T-bars 15 or 24 mm.
Connection in separate ballast box. The driver box can be positioned next to the luminaire. Snap-in terminal block 3x1,5mm2 (x2), through-wiring possible. 5x1,5mm2 (x2) when dimming. Can also be supplied with earthed mains cable and plug.
Luminaire body of white enamelled sheet steel (RAL 9016).
Delta – microprismatic louvre above hardened 4 mm glass cover.
Enclosure class IP 44 under suspended ceilings and IP 20 above suspended ceilings.
Class III applies to the luminaire body only. The supplied driver should be connected to protective earth.
CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.
Multilume is Fagerhult’s extensive family of LED luminaires for recessed mounting. Multilume’s balanced work and general lighting delivers excellent light ergonomics, constantly updated with the latest in LED technology....More about the family Multilume
Accessories Notor G2 Ripustettava suora/epäsuora Lamell
|Frame for surface mounting||Frame for surface mounting, H=60 (600x600), only standard and DALI.||41028|
|Décor plate, circular||Multilume Flat/Multilume Slim décor plate, circular (only VTB)||41793|
|WAGO connection cables, 3-way||Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free.||91244|
|WAGO connection cables, 5-way||Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free.||91243|
|Wieland connection cables, 3-way||Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free.||92793|
|WAGO T-connector||WAGO T-Connector, 3-way, white||91067|
|WAGO T-connector||WAGO T-connector, 5-way, 2 locking levers, blue||88228|
|Wieland connection cables, 5-way||Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free.||92799|
