550500-20124 Temporary name

No. of LEDs

9

Flujo Luminoso

20200

CLO function on

True

CLO time, h

100000

lm/W

139

Light source colour

740

CCT, K

4000

CRI

70

SDCM

5

Lumen maintenance 100 000 h

L100

Lumen maintenance L100 B50, h

100000

LED driver, h/max failure %

100000/10

Energy class

D

Brand of driver

Philips

AM

False

PWM

False

PWM, min Hz

1

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

66

IK rating

08

Start W

145

End W

155

Average W

150

Min. ambient temperature, °C

-40

Max. ambient temperature, °C

25

MCB B10A

4

MCB B16A

7

MCB C10A

7

MCB C16A

11

THD, %

7

Surge protection CM, kV/kA

10

Surge protection DM, kV/kA

6

Power factor, 100 %

0.99

Power factor, 30 %

0.83

Projected wind area, m2

0.038

NTC function

True

Length, mm

538

Width, mm

350

Height, mm

88

Weight, kg

6.800
