Vialume 2 730 CLO

Installation

Post top luminaire which in its standard design can be mounted on a Ø 60 mm post arm bracket. Accessories for other mounting options are ordered separately, see Accessories. Variable tilting function ± 10º for perfect installation. Post height 8-15 m.

Connection

Halogen free connection cable 3x1.5 mm² type FQQ. Delivered with 15,5 m cable. DALI version available on request, delivered with a 5-pin cable. Other cable versions on request.

Design

Body and post bracket in cast aluminium. Aluminium-zinc coated stainless screws. Driver is integrated in the luminaire. Hardened flat glass.

Optics

AGC-lenses (Advanced Glare Control). The E-lens are designed to focus on illuminance. L lenses are ideal if the luminance from the ground is the main priority.

Dimming

Night dimming or DALI version available on request.

Designed by

ÅF Lighting och Tuxen Design.

Standard colour

Alu-grey (RAL 9006, semi-gloss).
Anthracite grey (Gris 900 Sablé), black (RAL 9005) or white (RAL 9010, semi-gloss) on request.

LED-information

DALI version is equipped with NTC, over-heat protection.
Driver with integrated surge protection (DM: 6 kV. CM: 8 kV).
Extra surge protection (DM and CM: 10 kV) available on request.

Miscellaneous

Zhaga and NEMA adapter on request.

CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

Media

Document

Specification

The luminaires can be supplied with an output up to 18 300lm upon request. In addition to the featured lens selection more optics are available on request.

Filter

Art.no. Start W Average W Lumen output Light source colour Lens No. of LEDs CLO function on Protection class
Art.no. Start W Average W Lumen output Light source colour Lens No. of LEDs CLO function on Protection class
303810-480 58 62 7300 730 E2 11 Yes 1
303810-484 55 59 7300 730 L2 11 Yes 1
303810-489 57 60 7300 730 L7 11 Yes 1
303811-480 67 71 8300 730 E2 11 Yes 1
303811-484 64 68 8300 730 L2 11 Yes 1
303811-489 65 69 8300 730 L7 11 Yes 1
303812-480 77 82 9300 730 E2 11 Yes 1
303812-484 73 77 9300 730 L2 11 Yes 1
303812-489 75 79 9300 730 L7 11 Yes 1
303813-480 81 86 10300 730 E2 15 Yes 1
303813-484 77 81 10300 730 L2 15 Yes 1
303813-489 79 83 10300 730 L7 15 Yes 1
303814-480 90 95 11300 730 E2 15 Yes 1
303814-484 85 90 11300 730 L2 15 Yes 1
303814-489 87 92 11300 730 L7 15 Yes 1
303815-480 100 106 12300 730 E2 15 Yes 1
303815-484 94 99 12300 730 L2 15 Yes 1
303815-489 96 102 12300 730 L7 15 Yes 1
303816-480 110 116 13300 730 E2 15 Yes 1
303816-484 103 109 13300 730 L2 15 Yes 1
303816-489 106 112 13300 730 L7 15 Yes 1
303817-480 118 125 14300 730 E2 17 Yes 1
303817-484 110 116 14300 730 L2 17 Yes 1
303817-489 113 119 14300 730 L7 17 Yes 1
303818-480 129 136 15300 730 E2 17 Yes 1
303818-484 120 126 15300 730 L2 17 Yes 1
303818-489 123 130 15300 730 L7 17 Yes 1
303819-480 135 142 16300 730 E2 21 Yes 1
303819-484 127 134 16300 730 L2 21 Yes 1
303819-489 130 137 16300 730 L7 21 Yes 1
303820-480 145 153 17300 730 E2 21 Yes 1
303820-484 136 143 17300 730 L2 21 Yes 1
303820-489 139 147 17300 730 L7 21 Yes 1
303821-480 155 164 18300 730 E2 21 Yes 1
303821-484 145 153 18300 730 L2 21 Yes 1
303821-489 149 157 18300 730 L7 21 Yes 1

Filter

Name Description Art.no.
Name Description Art.no.
Vialume 2 730 CLO303814-484
Bracket for Vialume 2Bracket for Ø 60 mm post top. Alu-grey.303858
Bracket for Vialume 2Bracket for Ø 76 mm post top. Alu-grey.303859
