Twister

See items

A minimalist yet powerful spotlight in an attractive, timeless design with matching high light quality. Mounted on track and is compatible with standard 3-phase track (on/off), Control Track (DALI) and is adapted to Bluetooth wireless light control. Available with three light distributions, small, medium and flood.

Installation

Track installation via 3-phase track or Control Track.

Design

Luminaire housing in aluminium, powder coated in black (RAL 9017). The driver is Integrated in the luminaire housing.

Dimming

DALI and wireless Bluetooth.

Designed by

GUISE Arkitekter.

LED-information

930 LED is placed under the Planck curve (BBBL), other colour temperatures are placed on the Planck curve.

Media

Twister

Twister is a dynamic and creative solution based on a well-known cylindrical shape but with an elegant twist. The luminaire is the results of a collaboration between Guise architects, Stockholm and Fagerhult. The result is a...

More about the family Twister

Document

Environmental declaration

Instruction for use

Revit

3DS

DWG

FBX

Max

Specification

Filter

Art.no. Effect, W Lumen output CCT, K CRI Colour Installation Light distribution Light control Miscellaneous
Art.no. Effect, W Lumen output CCT, K CRI Colour Installation Light distribution Light control Miscellaneous
68315 26 1824 Black 3-phase track Narrow Beam
68315-504 26 1824 Black Control Track Narrow Beam DALI
68315-523 26 1824 Black Control Track Narrow Beam Casambi
68316 26 1774 Black 3-phase track Medium Beam
68316-504 26 1774 Black Control Track Medium Beam DALI
68316-523 26 1774 Black Control Track Medium Beam Casambi
68317 26 1782 Black 3-phase track Wide Beam
68317-504 26 1782 Black Control Track Wide Beam DALI
68317-523 26 1782 Black Control Track Wide Beam Casambi
68318 26 1824 Aluminium 3-phase track Narrow Beam
68318-504 26 1824 Aluminium Control Track Narrow Beam DALI
68318-523 26 1824 Aluminium Control Track Narrow Beam Casambi
68319 26 1774 Aluminium 3-phase track Medium Beam
68319-523 26 1774 Aluminium Control Track Medium Beam Casambi
68320 26 1782 Aluminium 3-phase track Wide Beam
68320-504 26 1782 Aluminium Control Track Wide Beam DALI
68320-523 26 1782 Aluminium Control Track Wide Beam Casambi
68321 26 1961 3000 90 Black 3-phase track Narrow Beam BBBL
68321-504 26 1961 3000 90 Black Control Track Narrow Beam DALI BBBL
68321-523 26 1961 3000 90 Black Control Track Narrow Beam Casambi BBBL
68322 26 1907 3000 90 Black 3-phase track Medium Beam BBBL
68322-504 26 1907 3000 90 Black Control Track Medium Beam DALI BBBL
68322-523 26 1907 3000 90 Black Control Track Medium Beam Casambi BBBL
68323 26 1916 3000 90 Black 3-phase track Wide Beam BBBL
68323-504 26 1916 3000 90 Black Control Track Wide Beam DALI BBBL
68323-523 26 1916 3000 90 Black Control Track Wide Beam Casambi BBBL
68324 26 1961 3000 90 Aluminium 3-phase track Narrow Beam BBBL
68324-504 26 1961 3000 90 Aluminium Control Track Narrow Beam DALI BBBL
68324-523 26 1961 3000 90 Aluminium Control Track Narrow Beam Casambi BBBL
68325 26 1907 3000 90 Aluminium 3-phase track Medium Beam BBBL
68325-504 26 1907 3000 90 Aluminium Control Track Medium Beam DALI BBBL
68325-523 26 1907 3000 90 Aluminium Control Track Medium Beam Casambi BBBL
68326 26 1916 3000 90 Aluminium 3-phase track Wide Beam BBBL
68326-504 26 1916 3000 90 Aluminium Control Track Wide Beam DALI BBBL
68326-523 26 1916 3000 90 Aluminium Control Track Wide Beam Casambi BBBL
