Touch Midi

Touch is a stylish and timeless luminaire that will fit smoothly into any retail environment. The integrated driver gives clean feeling and the shop ceiling will not be cluttered with drivers aimed in different directions.

Installation

Track mounted 3-phase track, Control track or iTrack.

Design

Housing in powder coated aluminium, white (RAL 9016), black (RAL 9017) or grey (RAL 7038). Integrated driver.

Dimming

DALI/phase pulse control

Miscellaneous

930 LED is Below Black Body Locus (BBBL), other colour temperature on Black Body Locus.

Media

Touch

Touch is a stylish and timeless luminaire that will fit smoothly into any retail environment. As versatile as a “little black dress” or a fitted suit, always ready to put on a great performance no matter the application. The...

More about the family Touch

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K CRI Colour Installation Light distribution Light control Miscellaneous
Art.no. Effect, W Lumen output CCT, K CRI Colour Installation Light distribution Light control Miscellaneous
51735 31 3185 3000 90 White 3-phase track Narrow Beam, 14° BBBL
51735-472 31 3185 3000 90 White iTrack Narrow Beam, 14° DALI BBBL
51735-504 31 3185 3000 90 White Control Track Narrow Beam, 14° DALI BBBL
51735-523 31 3185 3000 90 White 3-phase track Narrow Beam, 14° Casambi BBBL
51736 31 3185 3000 90 Black 3-phase track Narrow Beam, 14° BBBL
51736-472 31 3185 3000 90 Black iTrack Narrow Beam, 14° DALI BBBL
51736-504 31 3185 3000 90 Black Control Track Narrow Beam, 14° DALI BBBL
51736-523 31 3185 3000 90 Black 3-phase track Narrow Beam, 14° Casambi BBBL
51737 31 3191 3000 90 Grey 3-phase track Narrow Beam, 14° BBBL
51737-472 31 3191 3000 90 Grey iTrack Narrow Beam, 14° DALI BBBL
51737-504 31 3191 3000 90 Grey Control Track Narrow Beam, 14° DALI BBBL
51737-523 31 3191 3000 90 Grey 3-phase track Narrow Beam, 14° Casambi BBBL
51738 31 3191 3000 90 White 3-phase track Medium Beam, 20° BBBL
51738-472 31 3191 3000 90 White iTrack Medium Beam, 20° DALI BBBL
51738-504 31 3191 3000 90 White Control Track Medium Beam, 20° DALI BBBL
51738-523 31 3191 3000 90 White 3-phase track Medium Beam, 20° Casambi BBBL
51739 31 3191 3000 90 Black 3-phase track Medium Beam, 20° BBBL
51739-472 31 3191 3000 90 Black iTrack Medium Beam, 20° DALI BBBL
51739-504 31 3191 3000 90 Black Control Track Medium Beam, 20° DALI BBBL
51739-523 31 3191 3000 90 Black 3-phase track Medium Beam, 20° Casambi BBBL
51740 31 3191 3000 90 Grey 3-phase track Medium Beam, 20° BBBL
51740-472 31 3191 3000 90 Grey iTrack Medium Beam, 20° DALI BBBL
51740-504 31 3191 3000 90 Grey Control Track Medium Beam, 20° DALI BBBL
51740-523 31 3191 3000 90 Grey 3-phase track Medium Beam, 20° Casambi BBBL
51741 31 3158 3000 90 White 3-phase track Wide Beam, 40° BBBL
51741-472 31 3158 3000 90 White iTrack Wide Beam, 40° DALI BBBL
51741-504 31 3158 3000 90 White Control Track Wide Beam, 40° DALI BBBL
51741-523 31 3158 3000 90 White 3-phase track Wide Beam, 40° Casambi BBBL
51742 31 3158 3000 90 Black 3-phase track Wide Beam, 40° BBBL
51742-472 31 3158 3000 90 Black iTrack Wide Beam, 40° DALI BBBL
51742-504 31 3158 3000 90 Black Control Track Wide Beam, 40° DALI BBBL
51742-523 31 3158 3000 90 Black 3-phase track Wide Beam, 40° Casambi BBBL
51743 31 3158 3000 90 Grey 3-phase track Wide Beam, 40° BBBL
51743-472 31 3158 3000 90 Grey iTrack Wide Beam, 40° DALI BBBL
51743-504 31 3158 3000 90 Grey Control Track Wide Beam, 40° DALI BBBL
51743-523 31 3158 3000 90 Grey 3-phase track Wide Beam, 40° Casambi BBBL
52735 31 3408 4000 90 White 3-phase track Narrow Beam, 14°
52735-472 31 3408 4000 90 White iTrack Narrow Beam, 14° DALI
52735-504 31 3408 4000 90 White Control Track Narrow Beam, 14° DALI
52735-523 31 3408 4000 90 White 3-phase track Narrow Beam, 14° Casambi
52736 31 3408 4000 90 Black 3-phase track Narrow Beam, 14°
52736-472 31 3408 4000 90 Black iTrack Narrow Beam, 14° DALI
52736-504 31 3408 4000 90 Black Control Track Narrow Beam, 14° DALI
52736-523 31 3408 4000 90 Black 3-phase track Narrow Beam, 14° Casambi
52737 31 3408 4000 90 Grey 3-phase track Narrow Beam, 14°
52737-472 31 3408 4000 90 Grey iTrack Narrow Beam, 14° DALI
52737-504 31 3408 4000 90 Grey Control Track Narrow Beam, 14° DALI
52737-523 31 3408 4000 90 Grey 3-phase track Narrow Beam, 14° Casambi
52738 31 3414 4000 90 White 3-phase track Medium Beam, 20°
52738-472 31 3414 4000 90 White iTrack Medium Beam, 20° DALI
52738-504 31 3414 4000 90 White Control Track Medium Beam, 20° DALI
52738-523 31 3414 4000 90 White 3-phase track Medium Beam, 20° Casambi
52739 31 3414 4000 90 Black 3-phase track Medium Beam, 20°
52739-472 31 3414 4000 90 Black iTrack Medium Beam, 20° DALI
52739-504 31 3414 4000 90 Black Control Track Medium Beam, 20° DALI
52739-523 31 3414 4000 90 Black 3-phase track Medium Beam, 20° Casambi
52740 31 3414 4000 90 Grey 3-phase track Medium Beam, 20°
52740-472 31 3414 4000 90 Grey iTrack Medium Beam, 20° DALI
52740-504 31 3414 4000 90 Grey Control Track Medium Beam, 20° DALI
52740-523 31 3414 4000 90 Grey 3-phase track Medium Beam, 20° Casambi
52741 31 3379 4000 90 White 3-phase track Wide Beam, 40°
52741-472 31 3379 4000 90 White iTrack Wide Beam, 40° DALI
52741-504 31 3379 4000 90 White Control Track Wide Beam, 40° DALI
52741-523 31 3379 4000 90 White 3-phase track Wide Beam, 40° Casambi
52742 31 3379 4000 90 Black 3-phase track Wide Beam, 40°
52742-472 31 3379 4000 90 Black iTrack Wide Beam, 40° DALI
52742-504 31 3379 4000 90 Black Control Track Wide Beam, 40° DALI
52742-523 31 3379 4000 90 Black 3-phase track Wide Beam, 40° Casambi
52743 31 3379 4000 90 Grey 3-phase track Wide Beam, 40°
52743-472 31 3379 4000 90 Grey iTrack Wide Beam, 40° DALI
52743-504 31 3379 4000 90 Grey Control Track Wide Beam, 40° DALI
52743-523 31 3379 4000 90 Grey 3-phase track Wide Beam, 40° Casambi

Filter

Name Description Art.no.
Name Description Art.no.
BarndoorsBarndoors51764
BarndoorsBarndoors51765
BarndoorsBarndoors51763
Elliptic filterElliptic filter51769
Cap coneCap cone51762
Cap coneCap cone51761
Cap coneCap cone51760
Honeycomb louvreHoneycomb louvre51768
Honeycomb louvreHoneycomb louvre51767
Honeycomb louvreHoneycomb louvre51766
