Touch Midi Recessed Round

Touch is a stylish and timeless luminaire that will fit smoothly into any retail environment. Touch Midi Recessed Round is available in a single black and white version.

Design

Housing in powder coated aluminium, white (RAL 9016), black (RAL 9017).

Dimming

DALI with suffix -402 Casambi wireless control with suffix -524

Miscellaneous

Class III applies to the luminaire body only. The supplied driver is Class II. Rotate in 360°, tilted 60°. 930 LED is Below Black Body Locus (BBBL), other colour temperature on Black Body Locus.

Touch

Touch is a stylish and timeless luminaire that will fit smoothly into any retail environment. As versatile as a “little black dress” or a fitted suit, always ready to put on a great performance no matter the application. The...

More about the family Touch

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K CRI Colour Installation Light distribution Light control Connection Miscellaneous
Art.no. Effect, W Lumen output CCT, K CRI Colour Installation Light distribution Light control Connection Miscellaneous
51840 32 3201 3000 90 White Recessed Narrow Beam, 14° BBBL
51840-3 32 3201 3000 90 White Recessed Narrow Beam, 14° Connection cable with plug, L=2.5 m BBBL
51840-303 32 3201 3000 90 White Recessed Narrow Beam, 14° Wieland GST18i3 male, L=3.0 m BBBL
51840-402 32 3201 3000 90 White Recessed Narrow Beam, 14° DALI/Phase-pulse BBBL
51841 32 3201 3000 90 Black Recessed Narrow Beam, 14° BBBL
51841-3 32 3201 3000 90 Black Recessed Narrow Beam, 14° Connection cable with plug, L=2.5 m BBBL
51841-303 32 3201 3000 90 Black Recessed Narrow Beam, 14° Wieland GST18i3 male, L=3.0 m BBBL
51841-402 32 3201 3000 90 Black Recessed Narrow Beam, 14° DALI/Phase-pulse BBBL
51842 32 3179 3000 90 White Recessed Medium Beam, 20° BBBL
51842-3 32 3179 3000 90 White Recessed Medium Beam, 20° Connection cable with plug, L=2.5 m BBBL
51842-303 32 3179 3000 90 White Recessed Medium Beam, 20° Wieland GST18i3 male, L=3.0 m BBBL
51842-402 32 3179 3000 90 White Recessed Medium Beam, 20° DALI/Phase-pulse BBBL
51843 32 3179 3000 90 Black Recessed Medium Beam, 20° BBBL
51843-3 32 3179 3000 90 Black Recessed Medium Beam, 20° Connection cable with plug, L=2.5 m BBBL
51843-303 32 3179 3000 90 Black Recessed Medium Beam, 20° Wieland GST18i3 male, L=3.0 m BBBL
51843-402 32 3179 3000 90 Black Recessed Medium Beam, 20° DALI/Phase-pulse BBBL
51844 32 3130 3000 90 White Recessed Wide Beam, 40° BBBL
51844-3 32 3130 3000 90 White Recessed Wide Beam, 40° Connection cable with plug, L=2.5 m BBBL
51844-303 32 3130 3000 90 White Recessed Wide Beam, 40° Wieland GST18i3 male, L=3.0 m BBBL
51844-402 32 3130 3000 90 White Recessed Wide Beam, 40° DALI/Phase-pulse BBBL
51845 32 3130 3000 90 Black Recessed Wide Beam, 40° BBBL
51845-3 32 3130 3000 90 Black Recessed Wide Beam, 40° Connection cable with plug, L=2.5 m BBBL
51845-303 32 3130 3000 90 Black Recessed Wide Beam, 40° Wieland GST18i3 male, L=3.0 m BBBL
51845-402 32 3130 3000 90 Black Recessed Wide Beam, 40° DALI/Phase-pulse BBBL
51846 32 2843 3000 90 White Recessed Extra wide, 54° BBBL
51846-3 32 2843 3000 90 White Recessed Extra wide, 54° Connection cable with plug, L=2.5 m BBBL
51846-303 32 2843 3000 90 White Recessed Extra wide, 54° Wieland GST18i3 male, L=3.0 m BBBL
51846-402 32 2843 3000 90 White Recessed Extra wide, 54° DALI/Phase-pulse BBBL
51847 32 2843 3000 90 Black Recessed Extra wide, 54° BBBL
51847-3 32 2843 3000 90 Black Recessed Extra wide, 54° Connection cable with plug, L=2.5 m BBBL
51847-303 32 2843 3000 90 Black Recessed Extra wide, 54° Wieland GST18i3 male, L=3.0 m BBBL
51847-402 32 2843 3000 90 Black Recessed Extra wide, 54° DALI/Phase-pulse BBBL
52840 32 3681 4000 90 White Recessed Narrow Beam, 14°
52840-3 32 3681 4000 90 White Recessed Narrow Beam, 14° Connection cable with plug, L=2.5 m
52840-303 32 3681 4000 90 White Recessed Narrow Beam, 14° Wieland GST18i3 male, L=3.0 m
52840-402 32 3681 4000 90 White Recessed Narrow Beam, 14° DALI/Phase-pulse
52841 32 3681 4000 90 Black Recessed Narrow Beam, 14°
52841-3 32 3681 4000 90 Black Recessed Narrow Beam, 14° Connection cable with plug, L=2.5 m
52841-303 32 3681 4000 90 Black Recessed Narrow Beam, 14° Wieland GST18i3 male, L=3.0 m
52841-402 32 3681 4000 90 Black Recessed Narrow Beam, 14° DALI/Phase-pulse
52842 32 3656 4000 90 White Recessed Medium Beam, 20°
52842-3 32 3656 4000 90 White Recessed Medium Beam, 20° Connection cable with plug, L=2.5 m
52842-303 32 3656 4000 90 White Recessed Medium Beam, 20° Wieland GST18i3 male, L=3.0 m
52842-402 32 3656 4000 90 White Recessed Medium Beam, 20° DALI/Phase-pulse
52843 32 3656 4000 90 Black Recessed Medium Beam, 20°
52843-3 32 3656 4000 90 Black Recessed Medium Beam, 20° Connection cable with plug, L=2.5 m
52843-303 32 3656 4000 90 Black Recessed Medium Beam, 20° Wieland GST18i3 male, L=3.0 m
52843-402 32 3656 4000 90 Black Recessed Medium Beam, 20° DALI/Phase-pulse
52844 32 3600 4000 90 White Recessed Wide Beam, 40°
52844-3 32 3600 4000 90 White Recessed Wide Beam, 40° Connection cable with plug, L=2.5 m
52844-303 32 3600 4000 90 White Recessed Wide Beam, 40° Wieland GST18i3 male, L=3.0 m
52844-402 32 3600 4000 90 White Recessed Wide Beam, 40° DALI/Phase-pulse
52845 32 3600 4000 90 Black Recessed Wide Beam, 40°
52845-3 32 3600 4000 90 Black Recessed Wide Beam, 40° Connection cable with plug, L=2.5 m
52845-303 32 3600 4000 90 Black Recessed Wide Beam, 40° Wieland GST18i3 male, L=3.0 m
52845-402 32 3600 4000 90 Black Recessed Wide Beam, 40° DALI/Phase-pulse
52846 32 3269 4000 90 White Recessed Extra wide, 54°
52846-3 32 3269 4000 90 White Recessed Extra wide, 54° Connection cable with plug, L=2.5 m
52846-303 32 3269 4000 90 White Recessed Extra wide, 54° Wieland GST18i3 male, L=3.0 m
52846-402 32 3269 4000 90 White Recessed Extra wide, 54° DALI/Phase-pulse
52847 32 3269 4000 90 Black Recessed Extra wide, 54°
52847-3 32 3269 4000 90 Black Recessed Extra wide, 54° Connection cable with plug, L=2.5 m
52847-303 32 3269 4000 90 Black Recessed Extra wide, 54° Wieland GST18i3 male, L=3.0 m
52847-402 32 3269 4000 90 Black Recessed Extra wide, 54° DALI/Phase-pulse

Filter

Name Description Art.no.
Name Description Art.no.
BarndoorsBarndoors51763
BarndoorsBarndoors51764
Cap coneCap cone51760
Cap coneCap cone51761
Honeycomb louvreHoneycomb louvre51766
Honeycomb louvreHoneycomb louvre51767
Mounting plateMounting plate Ø 163, Ø 180, Ø 222 mm96700
