Rondo G2 Power post

A post luminaire in single or twin configuration, with medium or wide beam. An efficient, minimalist solution for commercial areas, school playgrounds and parks. CLO for output consistency as standard.

Installation

Luminaire for assembly on a post, with post top Ø 60 mm.

Connection

Supplied with 5 m cable, 2x1.5 mm².

Design

Body of extruded aluminium. Glass of PMMA. Driver pre-connected to the terminal block.

Reflector

Reflector of anodised aluminium.

Light distribution

Wide and medium beam angle.

Designed by

Wilma Daemen.

Standard colour

Anthracite grey (Gris 900 Sablé). Alu-grey (RAL 9006) or black (RAL 9005) on request.

Miscellaneous

CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

Media

Rondo G2

A timeless design make Rondo a perfect choice for lighting around commercial buildings, school playgrounds, along park roads and adjacent to parks. Rondo G2 has been developed exclusively for LED, with a focus on energy and...

More about the family Rondo G2

Document

Specification

Filter

Art.no. Lumen output Light distribution Light control Light source colour CLO function on Protection class Miscellaneous
Art.no. Lumen output Light distribution Light control Light source colour CLO function on Protection class Miscellaneous
302146 2000 Wide Beam 840 Yes 2 Single
302146-461 2000 Wide Beam DALI 840 Yes 2 Single
302147 2000 Medium Beam 840 Yes 2 Single
302147-461 2000 Medium Beam DALI 840 Yes 2 Single
302148 2650 Wide Beam 840 Yes 2 Single
302148-461 2650 Wide Beam DALI 840 Yes 2 Single
302149 2650 Medium Beam 840 Yes 2 Single
302149-461 2650 Medium Beam DALI 840 Yes 2 Single
302150 4000 Wide Beam 840 Yes 2 Double
302150-461 4000 Wide Beam DALI 840 Yes 2 Double
302151 4000 Medium Beam 840 Yes 2 Double
302152 5300 Wide Beam 840 Yes 2 Double
302152-461 5300 Wide Beam DALI 840 Yes 2 Double
302153 5300 Medium Beam 840 Yes 2 Double
302153-461 5300 Medium Beam DALI 840 Yes 2 Double
302162 2000 Wide Beam 830 Yes 2 Single
302162-461 2000 Wide Beam DALI 830 Yes 2 Single
302163 2000 Medium Beam 830 Yes 2 Single
302163-461 2000 Medium Beam DALI 830 Yes 2 Single
302164 2650 Wide Beam 830 Yes 2 Single
302164-461 2650 Wide Beam DALI 830 Yes 2 Single
302165 2650 Medium Beam 830 Yes 2 Single
302165-461 2650 Medium Beam DALI 830 Yes 2 Single
302166 4000 Wide Beam 830 Yes 2 Double
302166-461 4000 Wide Beam DALI 830 Yes 2 Double
302167 4000 Medium Beam 830 Yes 2 Double
302167-461 4000 Medium Beam DALI 830 Yes 2 Double
302168 5300 Wide Beam 830 Yes 2 Double
302168-461 5300 Wide Beam DALI 830 Yes 2 Double
302169 5300 Medium Beam 830 Yes 2 Double
302169-461 5300 Medium Beam DALI 830 Yes 2 Double
