Pleiad Robust G3

A downlight with protection class IK10 that produces light and feeling of security. Ring protection secured with security screws to prevent access.

Installation

Recessed mounting in unventilated or ventilated ceilings. Assembly springs for quick, tool-free installation included. An assembly plate should be used when installing in soft tile ceilings. The driver box can be detached for flexible installation. The luminaire must not be covered with insulation. For further details please refer to the assembly instructions on our website.

Connection

Connection in separate ballast box. Snap-in terminal block 3x1,5 mm² (x2), through-wiring possible. 5x1,5 mm² (x2) when dimming. Can also be supplied with mains cable and earthed plug or chassis mounted snap-in connector. The luminaire housing and driver are connected via a Quick Connection System.

Design

Luminaire body in black cast aluminium. Two-part visible decor ring in aluminium. The luminaire has durable PETG plates in the light openings between the rings. The luminaire and the rings are locked using tamper-proof torx screws.

Reflector

Reflector in matt anodised aluminium. Specular metallised Advanced Anti-Glare Control ring above the LED module.

Miscellaneous

The luminaire provides the highest mechanical protection beneath international classification IK10. Enclosure class IP 64 beneath suspended ceilings and IP 20 above suspended ceilings. Class III applies to the luminaire body only. The supplied driver should be connected to protective earth.

For loads in the suspended ceiling system, follow the selected suspended ceiling supplier’s recommendation.

Luminaires with Tunable White (2700-6500 K) are equipped with DALI device Type 8 driver.

CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

Media

The light source is protected by a clear plastic PEGT plate which is held by an inner ring.

The ring is mounted using tamper-proof torx security screws.

Pleiad G3

Pleiad G3 is the third generation of Fagerhult's successful downlight range - now equipped with LED. In common with its predecessors, the focus was placed upon perfect light treatment, quick installation and efficiency. In G3...

More about the family Pleiad G3

Document

Specification

Luminaires with Tunable White are listed with values for 4000 K.

Filter

Art.no. Effect, W Lumen output CCT, K Diameter, mm Colour Light distribution Light control Connection SDCM CLO function on Miscellaneous
Art.no. Effect, W Lumen output CCT, K Diameter, mm Colour Light distribution Light control Connection SDCM CLO function on Miscellaneous
76550 23 1538 4000 3 Wallwasher, Tunable White
77425 10 785 3000 3 Comfort
77425-111 9 853 3000 230 Alu grey Wide Beam Wieland GST18i3 3-way male 3
77425-340 9 853 3000 230 Alu grey Wide Beam Wago Winsta 3-way male 3
77425-402 8.5 768 3000 230 Alu grey Wide Beam DALI/Phase-pulse 3 Yes Comfort
77425-519 9 853 3000 230 Alu grey Wide Beam Ensto 3-way male 3
77425-520 8.5 768 3000 230 Alu grey Wide Beam DALI/Phase-pulse Ensto 5-way male 3 Yes
77425-528 8.5 768 3000 230 Alu grey Wide Beam DALI/Phase-pulse Wieland GST18i5 5-way male 3 Yes
77425-529 8.5 768 3000 230 Alu grey Wide Beam DALI/Phase-pulse Wago Winsta 5-way male 3 Yes
77426 10 791 4000 3 Comfort
77426-111 9 911 4000 230 Alu grey Wide Beam Wieland GST18i3 3-way male 3
77426-340 9 911 4000 230 Alu grey Wide Beam Wago Winsta 3-way male 3
77426-402 8.5 820 4000 230 Alu grey Wide Beam DALI/Phase-pulse 3 Yes Comfort
77426-519 9 911 4000 230 Alu grey Wide Beam Ensto 3-way male 3
77426-520 8.5 820 4000 230 Alu grey Wide Beam DALI/Phase-pulse Ensto 5-way male 3 Yes
77426-528 8.5 820 4000 230 Alu grey Wide Beam DALI/Phase-pulse Wieland GST18i5 5-way male 3 Yes
77426-529 8.5 820 4000 230 Alu grey Wide Beam DALI/Phase-pulse Wago Winsta 5-way male 3 Yes
77427 21 1579 3000 3 Comfort
77427-111 18 1596 3000 230 Alu grey Wide Beam Wieland GST18i3 3-way male 3
77427-340 18 1596 3000 230 Alu grey Wide Beam Wago Winsta 3-way male 3
77427-402 17 1436 3000 230 Alu grey Wide Beam DALI/Phase-pulse 3 Yes Comfort
77427-519 18 1596 3000 230 Alu grey Wide Beam Ensto 3-way male 3
77427-520 17 1436 3000 230 Alu grey Wide Beam DALI/Phase-pulse Ensto 5-way male 3 Yes
77427-528 17 1436 3000 230 Alu grey Wide Beam DALI/Phase-pulse Wieland GST18i5 5-way male 3 Yes
77427-529 17 1436 3000 230 Alu grey Wide Beam DALI/Phase-pulse Wago Winsta 5-way male 3 Yes
77428 21 1498 4000 3 Comfort
77428-111 17 1571 4000 230 Alu grey Wide Beam Wieland GST18i3 3-way male 3
77428-340 17 1571 4000 230 Alu grey Wide Beam Wago Winsta 3-way male 3
77428-402 15 1414 4000 230 Alu grey Wide Beam DALI/Phase-pulse 3 Yes Comfort
77428-519 17 1571 4000 230 Alu grey Wide Beam Ensto 3-way male 3
77428-520 15 1414 4000 230 Alu grey Wide Beam DALI/Phase-pulse Ensto 5-way male 3 Yes
77428-528 15 1414 4000 230 Alu grey Wide Beam DALI/Phase-pulse Wieland GST18i5 5-way male 3 Yes
77428-529 15 1414 4000 230 Alu grey Wide Beam DALI/Phase-pulse Wago Winsta 5-way male 3 Yes
77429 9 914 3000 230 Alu grey Wide Beam 3 Compact
77429-111 9 914 3000 230 Alu grey Wide Beam Wieland GST18i3 3-way male 3
77429-340 9 914 3000 230 Alu grey Wide Beam Wago Winsta 3-way male 3
77429-402 8.5 823 3000 230 Alu grey Wide Beam DALI/Phase-pulse 3 Yes Compact
77429-519 9 914 3000 230 Alu grey Wide Beam Ensto 3-way male 3
77429-520 8.5 823 3000 230 Alu grey Wide Beam DALI/Phase-pulse Ensto 5-way male 3 Yes
77429-528 8.5 823 3000 230 Alu grey Wide Beam DALI/Phase-pulse Wieland GST18i5 5-way male 3 Yes
77429-529 8.5 823 3000 230 Alu grey Wide Beam DALI/Phase-pulse Wago Winsta 5-way male 3 Yes
77430 9 965 4000 230 Alu grey Wide Beam 3 Compact
77430-111 9 965 4000 230 Alu grey Wide Beam Wieland GST18i3 3-way male 3
77430-340 9 965 4000 230 Alu grey Wide Beam Wago Winsta 3-way male 3
77430-402 8.5 869 4000 230 Alu grey Wide Beam DALI/Phase-pulse 3 Yes Compact
77430-519 9 965 4000 230 Alu grey Wide Beam Ensto 3-way male 3
77430-520 8.5 869 4000 230 Alu grey Wide Beam DALI/Phase-pulse Ensto 5-way male 3 Yes
77430-528 8.5 869 4000 230 Alu grey Wide Beam DALI/Phase-pulse Wieland GST18i5 5-way male 3 Yes
77430-529 8.5 869 4000 230 Alu grey Wide Beam DALI/Phase-pulse Wago Winsta 5-way male 3 Yes
77431 18 1693 3000 230 Alu grey Wide Beam 3 Compact
77431-111 18 1693 3000 230 Alu grey Wide Beam Wieland GST18i3 3-way male 3
77431-340 18 1693 3000 230 Alu grey Wide Beam Wago Winsta 3-way male 3
77431-402 17 1524 3000 230 Alu grey Wide Beam DALI/Phase-pulse 3 Yes Compact
77431-519 18 1693 3000 230 Alu grey Wide Beam Ensto 3-way male 3
77431-520 17 1524 3000 230 Alu grey Wide Beam DALI/Phase-pulse Ensto 5-way male 3 Yes
77431-528 17 1524 3000 230 Alu grey Wide Beam DALI/Phase-pulse Wieland GST18i5 5-way male 3 Yes
77431-529 17 1524 3000 230 Alu grey Wide Beam DALI/Phase-pulse Wago Winsta 5-way male 3 Yes
77432 17 1666 4000 230 Alu grey Wide Beam 3 Compact
77432-111 17 1666 4000 230 Alu grey Wide Beam Wieland GST18i3 3-way male 3
77432-340 17 1666 4000 230 Alu grey Wide Beam Wago Winsta 3-way male 3
77432-402 15 1499 4000 230 Alu grey Wide Beam DALI/Phase-pulse 3 Yes Compact
77432-519 17 1666 4000 230 Alu grey Wide Beam Ensto 3-way male 3
77432-520 15 1499 4000 230 Alu grey Wide Beam DALI/Phase-pulse Ensto 5-way male 3 Yes
77432-528 15 1499 4000 230 Alu grey Wide Beam DALI/Phase-pulse Wieland GST18i5 5-way male 3 Yes
77432-529 15 1499 4000 230 Alu grey Wide Beam DALI/Phase-pulse Wago Winsta 5-way male 3 Yes

Filter

Name Description Art.no.
Name Description Art.no.
WAGO connection cables, 3-wayLength 3.0 m with female and male connectors, 3x1,5 mm². Halogen free.91244
WAGO connection cables, 5-wayLength 3.0 m with female and male connectors, 5x1,5 mm². Halogen free.91243
WAGO T-connectorWAGO T-connector, 5-way, 2 locking levers, blue88228
WAGO T-connectorWAGO T-Connector, 3-way, white91067
Wieland connection cables, 3-wayLength 3.0 m with female and male connectors, 3x1,5 mm². Halogen free.92793
Wieland connection cables, 5-wayLength 3.0 m with female and male connectors, 5x1,5 mm². Halogen free.92799
Wieland T-connectorWieland 3-way T-connector91025
Wieland T-connectorWieland 5-way T-connector91026
