13632-533 Notor 65 Asymmetrical

Documents

Specification

Technical data

Installation

Start/Single

Protective class

1

IP rating

20

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

Light control

Organic Response

Brand of driver

Philips

Design

Louvre

Opal

Colour

White

Weight, kg

4.8

Length, mm

2133

Width, mm

65

Height, mm

65

Module

2000

Miscellaneous

LL, Left

Electrical data

MCB B10A

13

MCB B16A

21

MCB C10A

21

MCB C16A

35

AM

True

Power on last level

True

Stand by W

0.3

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Start W

19

Average W

20

End W

21

Power factor, 100 %

1

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

THD, %

12

No of Dali Addresses

1

Lighting data

Light distribution

Asymmetrical

Lumen output

2469

lm/W

132

Lumen maintenance L100 B50, h

50 000

Lumen maintenance 50 000 h

L100

Lumen maintenance 75 000 h

L85

Lumen maintenance 100 000 h

L81

Lumen maintencance at 50 000 h

1

LED driver, h/max failure %

100000/10

CLO function on

True

CLO time, h

50 000

SDCM

3

CRI

80

CCT, K

3000

Dimensions

Light distribution

Notor

Fagerhult’s classic interior luminaire Notor is available in several versions for suspended, surface mounted or recessed installation. Notor is an obvious choice in circumstances when there is a desire to create long, unbroken...

More about the family Notor
