Ligne

Ligne is a minimalistic linear luminaire that fits perfectly in context where you want to create long, unbroken light lines. Suspended or ceiling mounted with direct light only via Opal louvres. Single or continuous installation.

Connection

The luminaire is equipped with an access hole for cabling on the top. Knock-out at start luminaires short end for surface mounted mains cable. The luminaire unit is equipped with a through-wiring cable (5x2.5 mm²) and a snap-in connection in each end-cap.

Design

Luminaire body in natural anodised extruded aluminium finish.

Dimming

Possible on special request.

LED-information

CRI 80 3500K MacAdam 3 SDCM

Ligne

Ligne is a minimalistic linear luminaire that fits perfectly in context where you want to create long, unbroken light lines.

More about the family Ligne

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K Colour Module Length, mm Width, mm Height, mm Installation Light distribution Light control
Art.no. Effect, W Lumen output CCT, K Colour Module Length, mm Width, mm Height, mm Installation Light distribution Light control
34770 17 2138 3500 Anodised 1200 1125 36,4 45 Start/Single Wide Beam
34770-402 17 2138 3500 Anodised 1200 1125 36,4 45 Start/Single Wide Beam DALI/Phase-pulse
34771 34 4264 3500 Anodised 2400 2244 36,4 45 Start/Single Wide Beam
34771-402 34 4264 3500 Anodised 2400 2244 36,4 45 Start/Single Wide Beam DALI/Phase-pulse
34772 8 1068 3500 Anodised 600 562 36,4 45 Continuous Wide Beam
34772-402 8 1068 3500 Anodised 600 562 36,4 45 Continuous Wide Beam DALI/Phase-pulse
34773 17 2138 3500 Anodised 1200 1121 36,4 45 Continuous Wide Beam
34773-402 17 2138 3500 Anodised 1200 1121 36,4 45 Continuous Wide Beam DALI/Phase-pulse
34774 34 4264 3500 Anodised 2400 2240 36,4 45 Continuous Wide Beam
34774-402 34 4264 3500 Anodised 2400 2240 36,4 45 Continuous Wide Beam DALI/Phase-pulse

Filter

Name Description Art.no.
Name Description Art.no.
Pendant package for track 4 m incl. bracketPendant package for track 4 m incl. bracket97904
Wire bracket "snap on"Wire bracket "snap on"97912
