34774 Ligne

Installation

Continuous

Module

2400

Light distribution

Wide Beam

Louvre

Opal

Colour

Anodised

Lumen output

4270

lm/W

127

CCT, K

3500

CRI

80

SDCM

3

Lumen maintenance 50 000 h

L89

Lumen maintenance 75 000 h

L83

Lumen maintenance 100 000 h

L78

Lumen maintenance L90 B50, h

45 000

LED driver, h/max failure %

100000/10

Energy class, LED module

C

Driver brand

Tridonic

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

20

System Wattage

34

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

10

MCB B16A

16

MCB C10A

16

MCB C16A

26

THD, %

15

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Power factor, 100 %

0.95

Length, mm

2240

Width, mm

36

Height, mm

45

Weight, kg

2.8
