34774-402 Ligne

Installation

Continuous

Module

2400

Light distribution

Wide Beam

Louvre

Opal

Colour

Anodised

Lumen output

3844

CLO function active

Yes

CLO time, h

50000

lm/W

131

CCT, K

3500

CRI

80

SDCM

3

Lumen maintenance 50 000 h

L100

Lumen maintenance 75 000 h

L83

Lumen maintenance 100 000 h

L78

Lumen maintenance L100 B50, h

50000

LED driver, h/max failure %

100000/10

Energy class, LED module

C

Light control

DALI/Phase-pulse

Driver brand

Tridonic

Power on last level

Yes

Corridor function

Yes

Switch control, max no.

25

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

20

Start W

29

End W

33

Average W

31

Stand by W

0.15

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

13

MCB B16A

21

MCB C10A

21

MCB C16A

35

THD, %

18

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Power factor, 100 %

0.93

Length, mm

2240

Width, mm

36

Height, mm

45

Weight, kg

2.8
