Kaskad Wallwasher

A small, recessed downlight with asymmetric light distribution in three colour temperatures and two outputs for illuminating vertical surfaces.

Installation

Recessed mounting in unventilated or ventilated suspended ceilings. Assembly springs for quick assembly included. Separate ballast box for flexible installation. An assembly plate must be used when mounting on soft tile ceilings Do not cover with insulation. For detailed information, please refer to the installation instructions.

Connection

Connections are made to the independent LED driver. The luminaire is delivered with interconnecting cable.

Design

Luminaire body and visible edge ring of sheet steel in white (RAL 9016) structured enamel. Heatsink in black enamelled aluminium.

Louvre

Specular reflector in anodised aluminium. Diffusing frosted glass raised within the reflector above structured enamelled black baffle.

Miscellaneous

IP 44 under suspended ceiling, IP 20 above suspended ceilings.
Class III applies to the luminaire body only. The supplied driver should be connected to protective earth.
For loads in the suspended ceiling system, follow the selected suspended ceiling supplier’s recommendation.

Kaskad

Kaskad is an elegant lighting solution ideal for front-of-house environments such as lounges, hotel lobbies and entrance halls. The distinct trim ring, combined with the black baffle, creates an architecturally exciting solution...

More about the family Kaskad

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K Diameter, mm Colour Light distribution Light control Connection SDCM Miscellaneous
Art.no. Effect, W Lumen output CCT, K Diameter, mm Colour Light distribution Light control Connection SDCM Miscellaneous
76594 12 648 2700 110 White Asymmetrical 2 SDCM 2
76594-3 12 648 2700 110 White Asymmetrical Connection cable with plug, L=2.5 m 2 SDCM 2
76594-402 12 648 2700 110 White Asymmetrical DALI/Phase-pulse 2 SDCM 2
76595 20 1133 110 White Asymmetrical SDCM 2
76595-3 20 1133 110 White Asymmetrical Connection cable with plug, L=2.5 m SDCM 2
76595-402 20 1133 110 White Asymmetrical DALI/Phase-pulse SDCM 2
76596 12 772 3000 110 White Asymmetrical 3 SDCM 3
76596-3 12 772 3000 110 White Asymmetrical Connection cable with plug, L=2.5 m 3 SDCM 3
76596-402 12 772 3000 110 White Asymmetrical DALI/Phase-pulse 3 SDCM 3
76597 20 1349 3000 110 White Asymmetrical 3 SDCM 3
76597-3 20 1349 3000 110 White Asymmetrical Connection cable with plug, L=2.5 m 3 SDCM 3
76597-402 20 1349 3000 110 White Asymmetrical DALI/Phase-pulse 3 SDCM 3
76598 12 772 4000 110 White Asymmetrical 3 SDCM 3
76598-3 12 772 4000 110 White Asymmetrical Connection cable with plug, L=2.5 m 3 SDCM 3
76598-402 12 772 4000 110 White Asymmetrical DALI/Phase-pulse 3 SDCM 3
76599 20 1349 4000 110 White Asymmetrical 3 SDCM 3
76599-3 20 1349 4000 110 White Asymmetrical Connection cable with plug, L=2.5 m 3 SDCM 3
76599-402 20 1349 4000 110 White Asymmetrical DALI/Phase-pulse 3 SDCM 3

Filter

Name Description Art.no.
Name Description Art.no.
Mounting plateMounting plate for soft tile ceiling, Ø 11041964
