24189-533 Indigo Combo Beta Opti

Installation

VTB

Module

600x600

Light distribution

Direct

Louvre

Beta Opti

Colour

White

RAL

9016

Lumen output

4495

CLO function active

Yes

CLO time, h

50000

lm/W

121

CCT, K

4000

CRI

80

SDCM

3

Melanopic DER

0.600

Lumen maintenance 50 000 h

L100

Lumen maintenance 75 000 h

L84

Lumen maintenance 100 000 h

L80

Lumen maintenance L100 B50, h

50000

LED driver, h/max failure %

100000/10

Energy class, LED module

C

Light control

Organic Response

Driver brand

Philips

AM

Yes

ZD4i Certified

False

Detection technology

IR

Detection type

Presence/Absence

Daylight functionality

Yes

Organic Response, FW version

5.3

Organic Response IR, max. distance between units (m)

3

Radio communication, protocol/frequency

Wirepas/2.4 GHz

Radio communication, max. distance (m)

8

Radio communication, standard/security

/AES-128

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

20

Start W

37

End W

41

Average W

39

Stand by W

0.5

Min. ambient temperature, °C

0

Max. ambient temperature, °C

25

MCB B10A, pcs

15

MCB B16A

24

MCB C10A

24

MCB C16A

40

THD, %

5

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Power factor, 100 %

0.97

Length, mm

596

Width, mm

596

Height, mm

145

Weight, kg

5.4
