22255-402 Dwide ceiling

Documents

Specification

Technical data

Protective class

1

IP rating

20

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

Light control

DALI/Phase-pulse

Brand of driver

Tridonic

Design

Louvre

Delta

Colour

White

Weight, kg

5.9

Length, mm

609

Width, mm

609

Height, mm

59

Module

600x600

Electrical data

MCB B10A

13

MCB B16A

22

MCB C10A

21

MCB C16A

36

Switch control, max no.

25

AM

True

Power on last level

True

Corridor function

True

Stand by W

0.15

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Start W

33

Average W

37

End W

41

Power factor, 100 %

0.95

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

THD, %

6

No of Dali Addresses

1

Lighting data

Light distribution

Direct

Lumen output

4367

lm/W

132

Lumen maintenance L100 B50, h

100 000

Lumen maintenance 100 000 h

L100

Lumen maintencance at 50 000 h

1

LED driver, h/max failure %

100000/10

CLO function on

True

CLO time, h

100 000

SDCM

3

CRI

80

CCT, K

3000

Dimensions

Light distribution

Dwide

Dwide is a complete, versatile product family that meets all lighting requirements – whether for office, school or hospital projects. Recessed, ceiling-mounted and pendant luminaires with different light distributions are...

More about the family Dwide
