Multilume Slim Delta

BIMobject See items

A recessed workplace luminaire in various sizes for most types of suspended ceilings. Delta louvres provide efficiency and optimal lighting comfort. Recessed depth 23 mm.

Installation

Recessed mounting in ventilated or unventilated suspended ceilings. Two optional designs.
VTB – for suspended ceilings with visible T-bars 15 or 24 mm.

HB – for suspended ceiling with concealed T-bars/D-edge, symmetrical attachment of ceiling boards (20–22 mm thick).

Connection

Connection in separate ballast box. Snap-in terminal block 3x1,5 mm² (x2), through-wiring possible. 5x1,5 mm² (x2) when dimming. Can also be supplied with mains cable and earthed plug or chassis mounted snap-in connector. The luminaire housing and driver are connected via a Quick Connection System.

Design

Luminaire body of white enamelled sheet steel (RAL 9016).

Louvre

Delta – microprism louvre in UV stabil polystyrene.

Dimming

Organic Response – PIR sensor with presence and daylight control. All luminaires have master/slave functionality with IR communications.

Miscellaneous

Enclosure class IP 44 under suspended ceilings and IP 20 above suspended ceilings.
Class III applies to the luminaire body only. The supplied driver should be connected to protective earth.

Luminaires with Tunable White (2700-6500 K) are equipped with DALI device Type 8 driver.
CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

Media

Sky Frame - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Sky Frame - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Décor plate for a circular luminous surface is available as an accessory.

Décor plate for a circular luminous surface is available as an accessory.

Fence - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Fence - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Compago - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Compago - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Fence - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Fence - decorative accessory for recessed 600x600 luminaires. See more versions under Accessories.

Organic Response – How it works

Multilume

Multilume is Fagerhult’s extensive family of LED luminaires for recessed mounting. Multilume’s balanced work and general lighting delivers excellent light ergonomics, constantly updated with the latest in LED technology....

More about the family Multilume

Other products

Document

Environmental Product Declaration (EPD)

Instruction for use

Connection DALI resp. phase pulse dimming

Manual Organic Response

Cleaning instruction

DWG

FBX

3Ds

MAX

Revit

FBX

Specification

Loading...

Filter

Name Description Art.no.
Name Description Art.no.
Frame for surface mountingFrame for surface mounting, H=60 (600x600). Fits Multilume Slim & Multilume Re:Think. Also with Organic Response (only with a fixed connection or cord and plug).41028
Wieland T-connectorWieland 5-way T-connector91026
Wieland T-connectorWieland 3-way T-connector91025
IR dongle for Organic ResponseIR dongle for Organic Response equipped luminaire.86279
Frame for surface mountingFrame for surface mounting (600x600 VTB). Fits Multilume Flat (only standard and DALI), Dwide as well as Multilume Slim, Multilume Slim Hygiene & Multilume Re:Think with Organic Response.41026
Frame for surface mountingFrame for surface mounting, H=60 (300x1200 VTB). Fits Multilume Slim. 41029
WAGO connection cables, 3-wayLength 3.0 m with female and male connectors, 3x1,5 mm². Halogen free.91244
WAGO connection cables, 5-wayLength 3.0 m with female and male connectors, 5x1,5 mm². Halogen free.91243
Wieland connection cables, 3-wayLength 3.0 m with female and male connectors, 3x1,5 mm². Halogen free.92793
WAGO T-connectorWAGO T-Connector, 3-way, white91067
WAGO T-connectorWAGO T-connector, 5-way, 2 locking levers, blue88228
Wieland connection cables, 5-wayLength 3.0 m with female and male connectors, 5x1,5 mm². Halogen free.92799
Organic Response I/O boxI/O box with potential-free 16A relay for controlling external units.86413
External Organic Response sensor incl. DALI PSUExternal sensor incl. DALI PSU, recessed, 1 m cable86407
Organic Response IoT GatewayGateway for connection to Organic Response Portal. Incl. power adapter and wall bracket. Controls a maximum of 150 sensors.86296
External Organic Response sensor incl. DALI PSUExternal sensor incl. DALI PSU, surface mounted, 1 m cable86408
External Organic Response sensor incl. DALI PSUExternal sensor incl. DALI PSU, suspended pipe conduit installation, 1 m cable. pipe not included.86409
External Organic Response sensor incl. DALI PSUExtern sensor incl. DALI PSU, suspended pipe conduit installation, 3.2 m cable. Pipe not included.86412
External Organic Response sensor incl. DALI PSUExternal sensor incl. DALI PSU, surface mounted, 3.2 m cable86411
External Organic Response sensor incl. DALI PSUExternal sensor incl. DALI PSU, recessed, 3.2 m cable86410
Organic Response EnOcean Wireless Push button panelEnOcean 2 function push button panel, white86416
Organic Response EnOcean Wireless Push button panelEnOcean 4 function push button panel, white86417
Organic Response EnOcean Wireless Push button panelEnOcean 4 function push button panel, labeled, white86437
Organic Response EnOcean Wireless Push button panelEnOcean 2 function push button panel, labeled, white86436
Cover plate for flat upper surfaceCover plate for flat upper surface, white (RAL 9016).41039
Frame for surface mountingDwide Multilume Re:Think & Multilume Slim, Surface mounted frame, 600x600.41033
Frame for pendant installation H=60 mmDwide & Multilume Slim pendant frame 600x600 incl. wires41034
no-image placeholder Ensto connection cables, 5-wayLength 3.0 m with female and male connectors, 5x1,5 mm². Halogen free.92786
no-image placeholder Ensto connection cables, 3-wayLength 3.0 m with female and male connectors, 3x1,5 mm². Halogen free.92785
no-image placeholder Ensto power cableLength 2.0 m with female (without hooks) and male connectors, 5x1,5 mm². Halogen free.92788
Ensto T-connectorEnsto T-connector 3-way, white92783
Ensto T-connectorEnsto T-connector 5-way, grey92784
no-image placeholder Ensto power cableLength 2.0 m with female (without hooks) and male connectors, 3x1,5 mm². Halogen free.92787
FenceFence 600x600 white.41252
FenceFence 600x600 champagne.41254
FenceFence 600x600 black.41253
Sky frameSky frame for ceiling window effect 600x600, White.41245
Circle IceCircle Ice 600x600 White.41248
Circle EdgeCircle with bevelled edge 600x600, White.41246
CircleCircle with straight edge 600x600, White.41247
CompagoCompago framework 600x600, Grey.41250
CompagoCompago framework 600x600, White.41249
Organic Response I/O boxI/O box with potential-free 8A relay for controlling external units.86433
Recessed frame solid ceilingRecessed frame for VTB frame 600x600 in solid ceiling (ceiling thickness 5 – 50 mm) Max. weight 4,5kg41051
Recessed frame solid ceilingRecessed frame for VTB frame 300x600 in solid ceiling (ceiling thickness 5 – 50 mm) Max. weight 3kg41048
Recessed frame solid ceilingRecessed frame for VTB frame 300x1200 in solid ceiling (ceiling thickness 5 – 50 mm) Max. weight 4kg41049
