Zone Evo I Recessed G2

Zone Evo has a clean conical design and an efficient segmented reflector ensuring excellent visual performance.

Installation

Recessed.

Connection

Connection in remote LED driver. Luminaire connects to driver with supplied cable.

Design

Housing in aluminium, powder coated black (RAL 9017) or white (RAL 9016) structured. Front ring in thermo plastic.

Reflector

Segmented reflector. In spot, medium and flood beam angle.

Dimming

DALI, phase pulse control. 100-1 %.

LED-information

3000 K: CRI 80 or 90, L80 B50 75 000 h, MacAdam 3 SDCM.
4000 K: CRI 80, L80 B50 75 000 h, MacAdam 3 SDCM.
Driver life-time up to 50 000 h/10 % (max failure).

Miscellaneous

Passived cooled in all versions.

Zone Evo G2

Evolution changes the way things look, and the Zone family has evolved into new models. Yet an evolution of the Zone Family has been made. The new G2 family is equipped with a highly efficient LED module that is up to 50 % as...

More about the family Zone Evo G2

Document

Specification

Filter

Art.no. Lumen output CCT, K CRI Installation Light distribution Colour Light control Miscellaneous
Art.no. Lumen output CCT, K CRI Installation Light distribution Colour Light control Miscellaneous
58120 1126 3000 80 Recessed Spot, 14° White DALI Including mounted standard/DALI driver
58120-3 1126 3000 80 Recessed Spot, 14° White DALI Including mounted standard/DALi driver
58121 1457 3000 80 Recessed Medium, 18° White DALI Including mounted standard/DALi driver
58122 1347 3000 80 Recessed Flood, 31° White DALI Including mounted standard/DALi driver
58123 1126 3000 80 Recessed Spot, 14° Black DALI Including mounted standard/DALi driver
58123-3 1126 3000 80 Recessed Spot, 14° Black DALI including mounted standard/DALi driver
58124 1457 3000 80 Recessed Medium, 18° Black DALI including mounted standard/DALi driver
58125 1347 3000 80 Recessed Flood, 31° Black DALI including mounted standard/DALi driver
58126-3 1147 3000 90 Recessed Spot, 13° White DALI including mounted standard/DALi driver
58127 1109 3000 90 Recessed Medium, 16° White DALI including mounted standard/DALi driver
58127-3 1109 3000 90 Recessed Medium, 16° White DALI including mounted standard/DALi driver
58128 1067 3000 90 Recessed Flood, 31° White DALI including mounted standard/DALi driver
58128-3 1067 3000 90 Recessed Flood, 31° White DALI including mounted standard/DALi driver
58129 1147 3000 90 Recessed Spot, 13° Black DALI including mounted standard/DALi driver
58129-3 1147 3000 90 Recessed Spot, 13° Black DALI including mounted standard/DALi driver
58130 1109 3000 90 Recessed Medium, 16° Black DALI including mounted standard/DALi driver
58130-3 1109 3000 90 Recessed Medium, 16° Black DALI including mounted standard/DALi driver
58131 1067 3000 90 Recessed Flood, 31° Black DALI including mounted standard/DALi driver
58131-3 1067 3000 90 Recessed Flood, 31° Black DALI including mounted standard/DALi driver
58132 1219 4000 80 Recessed Spot, 14° White DALI including mounted standard/DALi driver
58132-3 1219 4000 80 Recessed Spot, 14° White DALI including mounted standard/DALi driver
58133 1274 4000 80 Recessed Medium, 16° White DALI including mounted standard/DALi driver
58133-3 1274 4000 80 Recessed Medium, 16° White DALI including mounted standard/DALi driver
58134 1217 4000 80 Recessed Flood, 30° White DALI including mounted standard/DALi driver
58134-3 1217 4000 80 Recessed Flood, 30° White DALI including mounted standard/DALi driver
58135 1219 4000 80 Recessed Spot, 14° Black DALI including mounted standard/DALi driver
58135-3 1219 4000 80 Recessed Spot, 14° Black DALI including mounted standard/DALi driver
58136 1274 4000 80 Recessed Medium, 16° Black DALI including mounted standard/DALi driver
58136-3 1274 4000 80 Recessed Medium, 16° Black DALI including mounted standard/DALi driver
58137 1217 4000 80 Recessed Flood, 30° Black DALI including mounted standard/DALi driver
58137-3 1217 4000 80 Recessed Flood, 30° Black DALI including mounted standard/DALi driver
58138 1900 3000 80 Recessed Spot, 14° White DALI including mounted DALI driver
58138-3 1900 3000 80 Recessed Spot, 14° White DALI including mounted DALI driver
58139 2324 3000 80 Recessed Medium, 29° White DALI including mounted DALI driver
58139-3 2324 3000 80 Recessed Medium, 29° White DALI including mounted DALI driver
58140 2269 3000 80 Recessed Flood, 55° White DALI including mounted DALI driver
58140-3 2269 3000 80 Recessed Flood, 55° White DALI including mounted DALI driver
58141 1900 3000 80 Recessed Spot, 14° Black DALI including mounted DALI driver
58141-3 1900 3000 80 Recessed Spot, 14° Black DALI including mounted DALI driver
58142 2324 3000 90 Recessed Medium, 29° Black DALI including mounted DALI driver
58142-3 2324 3000 90 Recessed Medium, 29° Black DALI including mounted DALI driver
58143 2269 3000 90 Recessed Flood, 55° Black DALI including mounted DALI driver
58143-3 2269 3000 90 Recessed Flood, 55° Black DALI including mounted DALI driver
58144 1834 3000 90 Recessed Spot, 18° White DALI including mounted DALI driver
58145 1820 3000 90 Recessed Medium, 28° White DALI including mounted DALI driver
58145-3 1820 3000 90 Recessed Medium, 28° White DALI including mounted DALI driver
58146 1755 3000 90 Recessed Flood, 55° White DALI including mounted DALI driver
58146-3 1755 3000 90 Recessed Flood, 55° White DALI including mounted DALI driver
58147 1834 3000 90 Recessed Spot, 18° Black DALI including mounted DALI driver
58148 1820 3000 90 Recessed Medium, 28° Black DALI including mounted DALI driver
58148-3 1820 3000 90 Recessed Medium, 28° Black DALI including mounted DALI driver
58149 1755 3000 90 Recessed Flood, 55° Black DALI including mounted DALI driver
58149-3 1755 3000 90 Recessed Flood, 55° Black DALI including mounted DALI driver
58150 2041 4000 80 Recessed Spot, 14° White DALI including mounted DALI driver
58150-3 2041 4000 80 Recessed Spot, 14° White DALI including mounted DALI driver
58151 1803 4000 80 Recessed Medium, 29° White DALI including mounted DALI driver
58151-3 1803 4000 80 Recessed Medium, 29° White DALI including mounted DALI driver
58152 1722 4000 80 Recessed Flood, 55° White DALI including mounted DALI driver
58152-3 1722 4000 80 Recessed Flood, 55° White DALI including mounted DALI driver
58153 2041 4000 80 Recessed Spot, 14° Black DALI including mounted DALI driver
58153-3 2041 4000 80 Recessed Spot, 14° Black DALI including mounted DALI driver
58154 1803 4000 80 Recessed Medium, 29° Black DALI including mounted DALI driver
58154-3 1803 4000 80 Recessed Medium, 29° Black DALI including mounted DALI driver
58155 1722 4000 80 Recessed Flood, 55° Black DALI including mounted DALI driver
58155-3 1722 4000 80 Recessed Flood, 55° Black DALI including mounted DALI driver
58198 1900 3000 90 Recessed Spot, 14° White DALI including mounted standard driver
58198-3 1900 3000 90 Recessed Spot, 14° White DALI including mounted standard driver
58199 2324 3000 90 Recessed Medium, 29° White DALI including mounted standard driver
58199-3 2324 3000 90 Recessed Medium, 29° White DALI including mounted standard driver
58200 2269 3000 80 Recessed Flood, 55° White
58200-3 2269 3000 80 Flood, 55° White
58201 1900 3000 90 Recessed Spot, 14° Black DALI including mounted standard driver
58201-3 1900 3000 90 Recessed Spot, 14° Black DALI including mounted standard driver
58202 2324 3000 90 Recessed Medium, 29° Black DALI including mounted standard driver
58202-3 2324 3000 90 Recessed Medium, 29° Black DALI including mounted standard driver
58203 2269 3000 90 Recessed Flood, 55° Black DALI including mounted standard driver
58203-3 1741 3000 90 Recessed Flood, 55° Black DALI including mounted standard driver
58204 1834 3000 90 Recessed Spot, 18° White DALI including mounted standard driver
58205 1820 3000 90 Recessed Medium, 28° White DALI including mounted standard driver
58205-3 1820 3000 90 Recessed Medium, 28° White DALI including mounted standard driver
58206 1755 3000 90 Recessed Flood, 55° White DALI including mounted standard driver
58207 1834 3000 90 Recessed Spot, 18° Black DALI including mounted standard driver
58208 1820 3000 90 Recessed Medium, 28° Black DALI including mounted standard driver
58208-3 1820 3000 90 Recessed Medium, 28° Black DALI including mounted standard driver
58209 1755 3000 90 Recessed Flood, 55° Black DALI including mounted standard driver
58209-3 1755 3000 90 Recessed Flood, 55° Black DALI including mounted standard driver
58210-3 2041 4000 80 Recessed Spot, 14° White DALI including mounted standard driver
58211 1803 4000 80 Recessed Medium, 29° White DALI including mounted standard driver
58211-3 1803 4000 80 Recessed Medium, 29° White DALI including mounted standard driver
58212 1722 4000 80 Recessed Flood, 55° White DALI including mounted standard driver
58212-3 1722 4000 80 Recessed Flood, 55° White DALI including mounted standard driver
58213 2041 4000 80 Recessed Spot, 14° Black DALI including mounted standard driver
58213-3 2041 4000 80 Recessed Spot, 14° Black DALI including mounted standard driver
58214 1803 4000 80 Recessed Medium, 29° Black DALI including mounted standard driver
58214-3 1803 4000 80 Recessed Medium, 29° Black DALI including mounted standard driver
58215 1722 4000 80 Recessed Flood, 55° Black DALI including mounted standard driver
58215-3 1722 4000 80 Recessed Flood, 55° Black DALI including mounted standard driver

Filter

Name Description Art.No.
Name Description Art.No.
Mounting plateMounting plate, double97135

Spot.

Medium.

Spot.

Flood.
