Zone Evo I Recessed G2

Asennus

Upotetaan ilmastoimattomaan tai ilmastoituun alakattorakenteeseen. Valaisimessa helppokäyttöiset asennusjouset, kiinnitys ilman työkaluja. Pehmeiden alakattomateriaalien kanssa on käytettävä tukilevyä. Ei saa peittää eristävällä materiaalilla. Lisätietoja asennusohjeessa kotisivuillamme.

Kytkentä

Valaisin toimitetaan valmiiksi kytkettynä erilliseen liitäntälaitteeseen.

Rakenne

Valaisinrunko ja kehys alumiinia. Pulverimaalattu väriin valkoinen (RAL 9016) tai musta (RAL 9017). Muovinen häikäisysuojarengas. Valaisinta voidaan kääntää 355° ja kallistaa 0–90°

Heijastin

Segmentoitu heijastin kiiltoeloksoitua alumiinia. Kapea, keskileveä tai leveä valonjako.

Valonsäätö

Valaisin sisältää liitäntälaitteen, jossa mahdollisuus himmennykseen (DALI/painonappiohjaus).

Tietoa LED

3000 K: CRI 80/90, L80 B50 75 000 h, MacAdam 3 SDCM.
4000 K: CRI 80, L80 B50 75 000 h, MacAdam 3 SDCM.
Liitäntälaitteen elinikä: jopa 50 000 h/10 % (maks. vikaantuminen).

Lisätiedot

Kaikissa malleissa passiivinen jäähdytys.

Zone Evo G2

Fagerhultin Zone Evo -kohdevalaisinsarja on uudistunut. Uudessa Zone Evo G2:ssa käytetään uusinta led-tekniikkaa. Valaisimen uusi led-moduuli on jopa 50 % tehokkaampi kuin edeltävä sukupolvi. Tämä mahdollistaa merkittäviä...

Lisätietoja tuotesarjasta Zone Evo G2

Asiakirjat

Tuotetiedot

Haku

Tuotenr. Valovirta, lm CCT, K CRI Asennus Valonjako Väri Valonohjaus Lisätiedot
Tuotenr. Valovirta, lm CCT, K CRI Asennus Valonjako Väri Valonohjaus Lisätiedot
58120 1126 3000 80 Upotettava Spot, 14° Valkoinen DALI Including mounted standard/DALI driver
58120-3 1126 3000 80 Upotettava Spot, 14° Valkoinen DALI Including mounted standard/DALi driver
58121 1457 3000 80 Upotettava Medium, 18° Valkoinen DALI Including mounted standard/DALi driver
58122 1347 3000 80 Upotettava Flood, 31° Valkoinen DALI Including mounted standard/DALi driver
58123 1126 3000 80 Upotettava Spot, 14° Musta DALI Including mounted standard/DALi driver
58123-3 1126 3000 80 Upotettava Spot, 14° Musta DALI including mounted standard/DALi driver
58124 1457 3000 80 Upotettava Medium, 18° Musta DALI including mounted standard/DALi driver
58125 1347 3000 80 Upotettava Flood, 31° Musta DALI including mounted standard/DALi driver
58126-3 1147 3000 90 Upotettava Spot, 13° Valkoinen DALI including mounted standard/DALi driver
58127 1109 3000 90 Upotettava Medium, 16° Valkoinen DALI including mounted standard/DALi driver
58127-3 1109 3000 90 Upotettava Medium, 16° Valkoinen DALI including mounted standard/DALi driver
58128 1067 3000 90 Upotettava Flood, 31° Valkoinen DALI including mounted standard/DALi driver
58128-3 1067 3000 90 Upotettava Flood, 31° Valkoinen DALI including mounted standard/DALi driver
58129 1147 3000 90 Upotettava Spot, 13° Musta DALI including mounted standard/DALi driver
58129-3 1147 3000 90 Upotettava Spot, 13° Musta DALI including mounted standard/DALi driver
58130 1109 3000 90 Upotettava Medium, 16° Musta DALI including mounted standard/DALi driver
58130-3 1109 3000 90 Upotettava Medium, 16° Musta DALI including mounted standard/DALi driver
58131 1067 3000 90 Upotettava Flood, 31° Musta DALI including mounted standard/DALi driver
58131-3 1067 3000 90 Upotettava Flood, 31° Musta DALI including mounted standard/DALi driver
58132 1219 4000 80 Upotettava Spot, 14° Valkoinen DALI including mounted standard/DALi driver
58132-3 1219 4000 80 Upotettava Spot, 14° Valkoinen DALI including mounted standard/DALi driver
58133 1274 4000 80 Upotettava Medium, 16° Valkoinen DALI including mounted standard/DALi driver
58133-3 1274 4000 80 Upotettava Medium, 16° Valkoinen DALI including mounted standard/DALi driver
58134 1217 4000 80 Upotettava Flood, 30° Valkoinen DALI including mounted standard/DALi driver
58134-3 1217 4000 80 Upotettava Flood, 30° Valkoinen DALI including mounted standard/DALi driver
58135 1219 4000 80 Upotettava Spot, 14° Musta DALI including mounted standard/DALi driver
58135-3 1219 4000 80 Upotettava Spot, 14° Musta DALI including mounted standard/DALi driver
58136 1274 4000 80 Upotettava Medium, 16° Musta DALI including mounted standard/DALi driver
58136-3 1274 4000 80 Upotettava Medium, 16° Musta DALI including mounted standard/DALi driver
58137 1217 4000 80 Upotettava Flood, 30° Musta DALI including mounted standard/DALi driver
58137-3 1217 4000 80 Upotettava Flood, 30° Musta DALI including mounted standard/DALi driver
58138 1900 3000 80 Upotettava Spot, 14° Valkoinen DALI including mounted DALI driver
58138-3 1900 3000 80 Upotettava Spot, 14° Valkoinen DALI including mounted DALI driver
58139 2324 3000 80 Upotettava Medium, 29° Valkoinen DALI including mounted DALI driver
58139-3 2324 3000 80 Upotettava Medium, 29° Valkoinen DALI including mounted DALI driver
58140 2269 3000 80 Upotettava Flood, 55° Valkoinen DALI including mounted DALI driver
58140-3 2269 3000 80 Upotettava Flood, 55° Valkoinen DALI including mounted DALI driver
58141 1900 3000 80 Upotettava Spot, 14° Musta DALI including mounted DALI driver
58141-3 1900 3000 80 Upotettava Spot, 14° Musta DALI including mounted DALI driver
58142 2324 3000 90 Upotettava Medium, 29° Musta DALI including mounted DALI driver
58142-3 2324 3000 90 Upotettava Medium, 29° Musta DALI including mounted DALI driver
58143 2269 3000 90 Upotettava Flood, 55° Musta DALI including mounted DALI driver
58143-3 2269 3000 90 Upotettava Flood, 55° Musta DALI including mounted DALI driver
58144 1834 3000 90 Upotettava Spot, 18° Valkoinen DALI including mounted DALI driver
58145 1820 3000 90 Upotettava Medium, 28° Valkoinen DALI including mounted DALI driver
58145-3 1820 3000 90 Upotettava Medium, 28° Valkoinen DALI including mounted DALI driver
58146 1755 3000 90 Upotettava Flood, 55° Valkoinen DALI including mounted DALI driver
58146-3 1755 3000 90 Upotettava Flood, 55° Valkoinen DALI including mounted DALI driver
58147 1834 3000 90 Upotettava Spot, 18° Musta DALI including mounted DALI driver
58148 1820 3000 90 Upotettava Medium, 28° Musta DALI including mounted DALI driver
58148-3 1820 3000 90 Upotettava Medium, 28° Musta DALI including mounted DALI driver
58149 1755 3000 90 Upotettava Flood, 55° Musta DALI including mounted DALI driver
58149-3 1755 3000 90 Upotettava Flood, 55° Musta DALI including mounted DALI driver
58150 2041 4000 80 Upotettava Spot, 14° Valkoinen DALI including mounted DALI driver
58150-3 2041 4000 80 Upotettava Spot, 14° Valkoinen DALI including mounted DALI driver
58151 1803 4000 80 Upotettava Medium, 29° Valkoinen DALI including mounted DALI driver
58151-3 1803 4000 80 Upotettava Medium, 29° Valkoinen DALI including mounted DALI driver
58152 1722 4000 80 Upotettava Flood, 55° Valkoinen DALI including mounted DALI driver
58152-3 1722 4000 80 Upotettava Flood, 55° Valkoinen DALI including mounted DALI driver
58153 2041 4000 80 Upotettava Spot, 14° Musta DALI including mounted DALI driver
58153-3 2041 4000 80 Upotettava Spot, 14° Musta DALI including mounted DALI driver
58154 1803 4000 80 Upotettava Medium, 29° Musta DALI including mounted DALI driver
58154-3 1803 4000 80 Upotettava Medium, 29° Musta DALI including mounted DALI driver
58155 1722 4000 80 Upotettava Flood, 55° Musta DALI including mounted DALI driver
58155-3 1722 4000 80 Upotettava Flood, 55° Musta DALI including mounted DALI driver
58198 1900 3000 90 Upotettava Spot, 14° Valkoinen DALI including mounted standard driver
58198-3 1900 3000 90 Upotettava Spot, 14° Valkoinen DALI including mounted standard driver
58199 2324 3000 90 Upotettava Medium, 29° Valkoinen DALI including mounted standard driver
58199-3 2324 3000 90 Upotettava Medium, 29° Valkoinen DALI including mounted standard driver
58200 2269 3000 80 Upotettava Flood, 55° Valkoinen
58200-3 2269 3000 80 Flood, 55° Valkoinen
58201 1900 3000 90 Upotettava Spot, 14° Musta DALI including mounted standard driver
58201-3 1900 3000 90 Upotettava Spot, 14° Musta DALI including mounted standard driver
58202 2324 3000 90 Upotettava Medium, 29° Musta DALI including mounted standard driver
58202-3 2324 3000 90 Upotettava Medium, 29° Musta DALI including mounted standard driver
58203 2269 3000 90 Upotettava Flood, 55° Musta DALI including mounted standard driver
58203-3 1741 3000 90 Upotettava Flood, 55° Musta DALI including mounted standard driver
58204 1834 3000 90 Upotettava Spot, 18° Valkoinen DALI including mounted standard driver
58205 1820 3000 90 Upotettava Medium, 28° Valkoinen DALI including mounted standard driver
58205-3 1820 3000 90 Upotettava Medium, 28° Valkoinen DALI including mounted standard driver
58206 1755 3000 90 Upotettava Flood, 55° Valkoinen DALI including mounted standard driver
58207 1834 3000 90 Upotettava Spot, 18° Musta DALI including mounted standard driver
58208 1820 3000 90 Upotettava Medium, 28° Musta DALI including mounted standard driver
58208-3 1820 3000 90 Upotettava Medium, 28° Musta DALI including mounted standard driver
58209 1755 3000 90 Upotettava Flood, 55° Musta DALI including mounted standard driver
58209-3 1755 3000 90 Upotettava Flood, 55° Musta DALI including mounted standard driver
58210-3 2041 4000 80 Upotettava Spot, 14° Valkoinen DALI including mounted standard driver
58211 1803 4000 80 Upotettava Medium, 29° Valkoinen DALI including mounted standard driver
58211-3 1803 4000 80 Upotettava Medium, 29° Valkoinen DALI including mounted standard driver
58212 1722 4000 80 Upotettava Flood, 55° Valkoinen DALI including mounted standard driver
58212-3 1722 4000 80 Upotettava Flood, 55° Valkoinen DALI including mounted standard driver
58213 2041 4000 80 Upotettava Spot, 14° Musta DALI including mounted standard driver
58213-3 2041 4000 80 Upotettava Spot, 14° Musta DALI including mounted standard driver
58214 1803 4000 80 Upotettava Medium, 29° Musta DALI including mounted standard driver
58214-3 1803 4000 80 Upotettava Medium, 29° Musta DALI including mounted standard driver
58215 1722 4000 80 Upotettava Flood, 55° Musta DALI including mounted standard driver
58215-3 1722 4000 80 Upotettava Flood, 55° Musta DALI including mounted standard driver

Haku

Name Description Art.No.
Name Description Art.No.
AsennuslevyAsennuslevy, (double)97135
HunajakennohäikäisysuojaHoneycomb, white ring, black grid96699
HäikäisysuojakartioHäikäisysuojakartio83546
HäikäisysuojakartioCap cone, white with inside in black96866-1000
HäikäisysuojarengasHäikäisysuojarengas59937
HäikäisysuojarengasHäikäisysuojarengas59938
KoristelevyKoristelevy 1-osainen59933
KoristelevyKoristelevy 1-osainen59934
KoristelevyKoristelevy 2-osainen59935
KoristelevyKoristelevy 2-osainen59936
ValonrajaimetValonrajaimet96864
ValonrajaimetValonrajaimet97225

Spot.

Medium.

Spot.

Flood.
