Dino Silo

Classic textile shade in white, black, grey or green in two sizes. The white LED driver is fitted with a diffuser to avoid glare from below.

Installation

Two point suspension c/c 150 mm.

Connection

233 V integrated LED ballast. Snap-in terminal block 5x2.5 mm². 1-phase through-wiring possible. Surface mounted mains cable possible 180°.

Design

Luminaire body of aluminium in white (RAL 9016) textured enamel. Textile shade; white, black, grey or green.
Ø 500 – supplied with 3,0 m white fabric cord 2x0,75 mm² and white, plastic ceiling cup.
Ø 1000 – supplied with 4,0 m white fabric cord 5x0,75 mm², 4,0 m wire suspension with friction locks for height adjustment and white, plastic ceiling cup.

Dimming

DALI/phase-pulse control as standard.

Designed by

PetterssonRudberg.

Miscellaneous

Luminaire 500 mm has a switch for high/low flow. Always delivered set at high flow and need to be adjusted for low flow.

Media

Silo Ø500

Silo Ø500

Dino

Atmospheric or functional?

You don’t have to choose between atmospheric or functional! From a cosy hotel room to a car sales area to the exclusive store to an office. Dino offers the possibility to fulfil various lighting tasks...

More about the family Dino

Document

Specification

Luminaire Ø 500 mm is always delivered set at high flow and need to be adjusted to get low flow (approx. 50 % lower system wattage and lluminous flux).

Filter

Art.no. Effect, W Lumen output CCT, K Colour Diameter, mm Light control
Art.no. Effect, W Lumen output CCT, K Colour Diameter, mm Light control
54021-402 16 1225 3000 White 500 DALI/Phase-pulse
54022-402 16 1303 4000 White 500 DALI/Phase-pulse
54023-402 16 1225 3000 Black 500 DALI/Phase-pulse
54024-402 16 1303 4000 Black 500 DALI/Phase-pulse
54025-402 16 1225 3000 Grey 500 DALI/Phase-pulse
54026-402 16 1303 4000 Grey 500 DALI/Phase-pulse
54027-402 16 1225 3000 Green 500 DALI/Phase-pulse
54028-402 16 1303 4000 Green 500 DALI/Phase-pulse
54029-402 24 2613 3000 White 1000 DALI/Phase-pulse
54030-402 24 2780 4000 White 1000 DALI/Phase-pulse
54031-402 24 2613 3000 Black 1000 DALI/Phase-pulse
54032-402 24 2780 4000 Black 1000 DALI/Phase-pulse
54033-402 24 2613 3000 Grey 1000 DALI/Phase-pulse
54034-402 24 2780 4000 Grey 1000 DALI/Phase-pulse
54035-402 24 2613 3000 Green 1000 DALI/Phase-pulse
54036-402 24 2780 4000 Green 1000 DALI/Phase-pulse
54037-402 57 5696 3000 White 1000 DALI/Phase-pulse
54038-402 57 6060 4000 White 1000 DALI/Phase-pulse
54039-402 57 5696 3000 Black 1000 DALI/Phase-pulse
54040-402 57 6060 4000 Black 1000 DALI/Phase-pulse
54041-402 57 5696 3000 Grey 1000 DALI/Phase-pulse
54042-402 57 6060 4000 Grey 1000 DALI/Phase-pulse
54043-402 57 5696 3000 Green 1000 DALI/Phase-pulse
54044-402 57 6060 4000 Green 1000 DALI/Phase-pulse
