Skytor

Installation
Luminaire for floor standing, suspended or wall installation. A flange for installation on posts (60 mm in diameter) is also available as an accessory.

Connection
M20x1,5 cable gland.

Design
Cast aluminium housing with toughened glass. Bracket in zinc coated and powder coated steel. Rust-free screws. Driver integrated in the luminaire.

Light distribution
Symmetrical or asymmetrical light distribution.

Optics
Lenses or chip on board (COB).

Dimming
DALI version is available on request.

Accessories
See accessories.

Designed by
LEG illumination.

Standard Colour
Graphite grey (RAL 7021).

Miscellaneous
Projected wind area Skytor 1 0.07 m². Weight: 4.2 kg. Skytor 2 0.12 m². Weight: 7.3 kg.

Environment images


Marking of product sheet

Document added to your cart

Text som beskriver tabellen
W SDCM CCT (K) Beam angle, ° CRI lm lm/W Useful life Art.No.
LED
Skytor 1, asymmetrical
52 5 4000 53°(-23°;+7°)/2x32° 70 5080 98 L80B50 60.000 h 582021
52 3 3000 53°(-23°;+7°)/2x32° 80 4013 77 L80B50 60.000 h 582026
67 5 4000 53°(-23°;+7°)/2x32° 70 6770 101 L80B50 60.000 h 582022
67 3 3000 53°(-23°;+7°)/2x32° 80 5348 80 L80B50 60.000 h 582027
Skytor 1, symmetrical (COB)
27 3 4000 120 80 3420 127 L80B50 60.000 h 582058
27 3 3000 120 80 3315 123 L80B50 60.000 h 582064
41 3 4000 120 80 5210 127 L80B50 60.000 h 582059
41 3 3000 120 80 5055 123 L80B50 60.000 h 582065
57 3 4000 120 80 7715 135 L80B50 60.000 h 582060
57 3 3000 120 80 7485 131 L80B50 60.000 h 582066
78 3 4000 120 80 10085 129 L80B50 60.000 h 582061
78 3 3000 120 80 9785 125 L80B50 60.000 h 582067
Skytor 2, asymmetrical
104 5 4000 53°(-23°;+7°)/2x32° 70 10740 103 L80B50 60.000 h 582023
104 3 3000 53°(-23°;+7°)/2x32° 80 8484 82 L80B50 60.000 h 582028
133 5 4000 53°(-23°;+7°)/2x32° 70 14320 107 L80B50 60.000 h 582024
133 3 3000 53°(-23°;+7°)/2x32° 80 11312 85 L80B50 60.000 h 582029
Skytor 2, symmetrical (COB)
115 3 4000 120 80 16210 141 L80B50 60.000 h 582062
115 3 3000 120 80 15725 137 L80B50 60.000 h 582068

Cover for single or double bracket, Skytor.

Art.No.
582019

Double bracket, Skytor

Art.No.
Post bracket for 2 luminaire. For assembly on Ø 60 mm post or post top. Supplement with cover when installing on post top. Graphite grey (RAL 7021). 582018

Flange for installation on posts, Skytor

Art.No.
Flange for installation on posts, 1-4 luminaires. For assembly on Ø 60 mm posts. 582020

Single bracket, Skytor

Art.No.
Post bracket for 1 luminaire. For assembly on Ø 60 mm post or post top. Supplement with cover when installing on post top. Graphite grey (RAL 7021). 582017
Dimensions picture
Dimensions picture 02
Asymmetrical

Asymmetrical

Symmetrical Skytor 1 COB 27–57W

Symmetrical Skytor 1 COB 27–57W

Symmetrical Skytor 1 COB 78W

Symmetrical Skytor 1 COB 78W

Symmetrical Skytor 2 COB 115W

Symmetrical Skytor 2 COB 115W
