Rondo G2 Power recessed

A robust downlighter with medium or wide beam that provides a comfortable light. CLO for output consistency as standard.

Installation

Luminaire for recessed mounting in the ceiling, thickness 1–50 mm.

Connection

Terminal block 4x2,5 mm². With external box for driver. Supplied with cable length (0.5 m). Through wiring possible.

Design

Body of extruded cast aluminium in black for better cooling. Glass of PMMA.

Reflector

Reflector of anodised aluminium.

Light distribution

Wide and medium beam angle.

Dimming

CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its service life.

Designed by

Wilma Daemen.

Standard colour

Anthracite grey (Gris 900 Sablé). Alu-grey (RAL 9006) or black (RAL 9005) on request.

Media

Remote driver for easy and flexible installation and enhanced thermal management.

Rondo G2

A timeless design make Rondo a perfect choice for lighting around commercial buildings, school playgrounds, along park roads and adjacent to parks. Rondo G2 has been developed exclusively for LED, with a focus on energy and...

More about the family Rondo G2

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K Colour Light distribution Light control
Art.no. Effect, W Lumen output CCT, K Colour Light distribution Light control
302114 17 1340 3000 Anthracite grey Medium Beam CLO
302114-461 17 1340 3000 Anthracite grey Medium Beam DALI/CLO
302115 23 2000 3000 Anthracite grey Wide Beam CLO
302115-461 23 2000 3000 Anthracite grey Wide Beam DALI/CLO
302116 23 2000 3000 Anthracite grey Medium Beam CLO
302116-461 23 2000 3000 Anthracite grey Medium Beam DALI/CLO
302120 17 1340 4000 Anthracite grey Medium Beam CLO
302120-461 17 1340 4000 Anthracite grey Medium Beam DALI/CLO
302121 23 2000 4000 Anthracite grey Wide Beam CLO
302121-461 23 2000 4000 Anthracite grey Wide Beam DALI/CLO
302122 23 2000 4000 Anthracite grey Medium Beam CLO
302122-461 23 2000 4000 Anthracite grey Medium Beam DALI/CLO
