T5 Eco, FDH

Marking of product sheet

Document added to your cart

Text som beskriver tabellen
W Socket lm lm/W Art.No.
13 G5 1070 104 81625
13 G5 1070 104 81626
20 G5 1650 99 81627
20 G5 1650 99 81628
25 G5 2450 114 81629
25 G5 2450 114 81630
32 G5 3100 114 81631
32 G5 3100 114 81632
45 G5 4100 109 81633
45 G5 4100 109 81634
50 G5 4400 102 81635
50 G5 4400 102 81636
73 G5 6150 99 81637
73 G5 6150 99 81638

Freedom

Installation
Designed for single or continuous installation via a wire pendant, or alternatively surface mounted to a wall or ceiling via two securing holes in profile. (Wire pendant, end-caps and coupler brackets are ordered separately.)

Connection
Connection cable, see Accessories, connects between luminaire and LED driver. Connect together for longer lengths, max. 7 metres.

Design
Luminaire body in black anodised aluminium. Diffusers made from opal polyester, reflectors made from highly reflective polyester, end-caps made from black ABS plastic. Transparent power cable. Installation box in white enamelled sheet-metal.

Dimming
Up to 6 luminaires can be connected to a PWM dimmer, see Accessories.
For maximum numbers of drivers per luminaire, see technical information under documents.

Designed by
Weikko Kotila and Julle Oksanen.

LED-information
4000 K: Ra (CRI) min. 80, MacAdam 2 SDCM.
Driver life-time: up to 50.000 h/10 % (max failure).

Efficiency, lm/W = a system consisting of 6 luminaires connected to driver 99009.

Miscellaneous
Also available with coloured lights upon request (via coloured filters in the luminaire).

Art.No.
13, 1.6, 4000, Direct, 810, 45, L<sub>90</sub>B<sub>50</sub> 50.000&nbsp;h 16932
