D63 Pendant

The ballast in the ceiling cup makes the luminaire incredibly elegant. With a diameter of 63 mm, D63 is the perfect choice for conference/entertainment environments with the focus on furnishing and interior design.

Installation

Two point suspension.

Connection

Connects with 230 V, built-in LED driver in ceiling cup. Snap-in terminal block 4x2.5 mm². Through-wiring possible. Surface mounted cable possible.

Design

Luminaire body in cast aluminium, structured grey (RAL 9006) finish. Diffuser in opal acrylic. Grey finish ceiling cup. Supplied with a 3 m white cable.

Dimming

Dimming possible using phase-pulse control or DALI. Dimmable LED driver for phase-pulse control as standard.

Miscellaneous

A cut-out in the ceiling cup is made using cutters 94248 for a surface mounted mains cable.

Media

Colour-coordinated ceiling cup with integrated LED driver.

Luminaire body in cast aluminium.

D63

Can a luminaire really be this small? With a diameter of just 63 mm, D63 is the perfect choice for conference rooms, corridors, cafes, restaurants and other applications which focus on furnishing and interior design.
D63 is a...

More about the family D63

Document

Specification

Filter

Art.no. Lumen output CCT, K Colour Light control
Art.no. Lumen output CCT, K Colour Light control
54801 506 3000 Grey DALI/Phase-pulse
54801-471 506 3000 Grey DALI/Phase-pulse

Filter

Name Description Art.No.
Name Description Art.No.
CuttersCutters, each94248
