Clarico Down

Installation
Recessed mounting in ventilated or unventilated suspended ceilings. Two optional designs.
VTB – for suspended ceilings with visible T-bars 25 mm.
HB – for suspended ceiling with concealed T-bars. Supplement with fixing brackets for fixed suspended ceiling, see Accessories.
The luminaire must not be covered with insulation. For further details please refer to the assembly instructions on our website

Connection
Connection in driver box. The driver box can be positioned next to the luminaire. Snap-in terminal block 3x1,5 mm² (5x1,5 mm² where dimming is required).

Design
Luminaire body in white enamelled sheet steel (RAL 9016).

Louvre
A combination of microprismatic and frosted opal surfaces in acrylic (PMMA) with a thin opal diffuser (PMMA) on the inside.

LED-information
3000 K/4000 K: Ra (CRI) min. 80, LMacAdam 3 SDCM.
Driver life-time: up to 100.000 h/10 % (max failure).

Miscellaneous
Enclosure class IP 40 under suspended ceilings and IP 20 above suspended ceilings.

Environment images


Marking of product sheet

Document added to your cart

Text som beskriver tabellen
W Module Weight, kg CCT (K) lm lm/W Useful life Art.No.
LED (system)
Concealed T-bars (HB)/D-edge, symmetrical attachment of ceiling boards
24 600x600 5.0 3000 2808 117 L90B10 50.000 h 23798
24 600x600 5.0 4000 2956 123 L90B10 50.000 h 23800
31 600x600 5.0 3000 3744 121 L90B10 50.000 h 23880
31 600x600 5.0 4000 3941 127 L90B10 50.000 h 23882
36 600x600 5.0 3000 4306 120 L90B10 50.000 h 23818
36 600x600 5.0 4000 4533 126 L90B10 50.000 h 23820
Visible T-bars (VTB)
24 600x600 5.0 3000 2808 117 L90B10 50.000 h 23797
24 600x600 5.0 4000 2956 123 L90B10 50.000 h 23799
31 600x600 5.0 3000 3744 121 L90B10 50.000 h 23879
31 600x600 5.0 4000 3941 127 L90B10 50.000 h 23881
36 600x600 5.0 3000 4306 120 L90B10 50.000 h 23817
36 600x600 5.0 4000 4533 126 L90B10 50.000 h 23819
Text som beskriver tabellen
W Module Weight, kg CCT (K) lm lm/W Useful life Art.No.
LED (system)
Concealed T-bars (HB)/D-edge, symmetrical attachment of ceiling boards
24 600x600 5.0 3000 2808 117 L90B10 50.000 h 23798-402
24 600x600 5.0 4000 2956 123 L90B10 50.000 h 23800-402
31 600x600 5.0 3000 3744 121 L90B10 50.000 h 23880-402
31 600x600 5.0 4000 3941 127 L90B10 50.000 h 23882-402
36 600x600 5.0 3000 4306 120 L90B10 50.000 h 23818-402
36 600x600 5.0 4000 4533 126 L90B10 50.000 h 23820-402
Visible T-bars (VTB)
24 600x600 5.0 3000 2808 117 L90B10 50.000 h 23797-402
24 600x600 5.0 4000 2956 123 L90B10 50.000 h 23799-402
31 600x600 5.0 3000 3744 121 L90B10 50.000 h 23879-402
31 600x600 5.0 4000 3941 127 L90B10 50.000 h 23881-402
36 600x600 5.0 3000 4306 120 L90B10 50.000 h 23817-402
36 600x600 5.0 4000 4533 126 L90B10 50.000 h 23819-402
Text som beskriver tabellen
W Module Weight, kg CCT (K) lm lm/W Useful life Art.No.
LED (system)
Concealed T-bars (HB)/D-edge, symmetrical attachment of ceiling boards
24 600x600 5.0 3000 2808 117 L90B10 50.000 h 23798-3
24 600x600 5.0 4000 2956 123 L90B10 50.000 h 23800-3
31 600x600 5.0 3000 3744 121 L90B10 50.000 h 23880-3
31 600x600 5.0 4000 3941 127 L90B10 50.000 h 23882-3
36 600x600 5.0 3000 4306 120 L90B10 50.000 h 23818-3
36 600x600 5.0 4000 4533 126 L90B10 50.000 h 23820-3
Visible T-bars (VTB)
24 600x600 5.0 3000 2808 117 L90B10 50.000 h 23797-3
24 600x600 5.0 4000 2956 123 L90B10 50.000 h 23799-3
31 600x600 5.0 3000 3744 121 L90B10 50.000 h 23879-3
31 600x600 5.0 4000 3941 127 L90B10 50.000 h 23881-3
36 600x600 5.0 3000 4306 120 L90B10 50.000 h 23817-3
36 600x600 5.0 4000 4533 126 L90B10 50.000 h 23819-3

Fixing brackets

Art.No.
Fixing brackets/4 pcs. For fixed ceiling. Only for concealed T-bars (HB-body). 91279
Dimensions picture
Light distribution
Polar diagram

Polar diagram

Contact us

Contact us


Designer


Clarico Down is designed by Henning Larsen Architects
