Touch Maxi

Touch is a stylish and timeless luminaire that will fit smoothly into any retail environment. The integrated driver gives clean feeling and the shop ceiling will not be cluttered with drivers aimed in different directions. The Maxi version is suitable for illuminating at places where there is high ceiling heights.

Installation

Track mounted 3-phase track or fixpoint bracket.

Design

Housing in powder coated aluminium, white (RAL 9016), black (RAL 9017) or grey (RAL 7038). Integrated driver.

Accessories

See accessories.

LED-information

CRI 90 3000 K BBBL. 4500 lm: L B50 100.000 h, MacAdam 3 SDCM. Driver 50 000 h/10 %.

Touch

Touch is a stylish and timeless luminaire that will fit smoothly into any retail environment. As versatile as a “little black dress” or a fitted suit, always ready to put on a great performance no matter the application. The...

More about the family Touch

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Installation
Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Installation
51746 42 4514 3000 90 White 15° 3-phase track/FixPoint
51747 42 4514 3000 90 Black 15° 3-phase track/FixPoint
51748 42 4514 3000 90 Grey 15° 3-phase track/FixPoint
51749 42 4391 3000 90 White 24° 3-phase track/FixPoint
51750 42 4391 3000 90 Black 24° 3-phase track/FixPoint
51751 42 4391 3000 90 Grey 24° 3-phase track/FixPoint
51752 42 4361 3000 90 White 39° 3-phase track/FixPoint
51753 42 4361 3000 90 Black 39° 3-phase track/FixPoint
51754 42 4361 3000 90 Grey 39° 3-phase track/FixPoint

Filter

Name Description Art.no.
Name Description Art.No.
BarndoorsBarndoors51783
BarndoorsBarndoors51784
BarndoorsBarndoors51785
Cap coneCap cone51780
Cap coneCap cone51781
Cap coneCap cone51782
Honeycomb louvreHoneycomb louvre51786
Honeycomb louvreHoneycomb louvre51787
Honeycomb louvreHoneycomb louvre51788
