Multilume Slim Ceiling

See items

Ceiling mounted luminaire available with Opal or Delta louvres.

Installation

Surface mounted.

Connection

Connection in separate ballast box. Snap-in terminal block 5 x 1,5 mm², through-wiring possible. Knockouts for surface mounted mains cable. The luminaire housing and driver are connected via a Quick Connection System.

Design

Luminaire body of white enamelled sheet steel (RAL 9016). Louvre frame of white enamelled steel (RAL 9016) structure.

Louvre

Delta – microprism louvre in UV stabil polystyrene.
Opal – plate in frosted UV stabil polystyrene.

Light distribution

Direct 100 %.

Dimming

DALI/phase-pulse control as standard. CLO (Constant Light Output) as standard.

Accessories

Fittings and additional components sold separately.

Miscellaneous

Class III applies to the luminaire body only. The supplied driver should be connected to protective earth. CLO (Constant Light Output) means that the luminaire provides the same amount of light for the duration of its specified burn-time.

Media

Dwide Ceiling Direct 600x600 – Installation

Multilume

Multilume is Fagerhult’s extensive family of LED luminaires for recessed mounting. Multilume’s balanced work and general lighting delivers excellent light ergonomics, constantly updated with the latest in LED technology....

More about the family Multilume

Other products

Document

Instruction for use

Max

FBX

DWG

3Ds

Revit

Specification

Loading...

Filter

Name Description Art.no.
Name Description Art.no.
Recessed frame solid ceiling Recessed frame for VTB frame 600x600 in solid ceiling (ceiling thickness 5 – 50 mm) Max. weight 4,5kg 41051
