Marathon Midi Recessed G3

Marathon is a cylindrical, discrete and energy efficient spotlight and the recessed version is produced in a dramatic black, grey or subtle white finish.

Installation

Recessed. On some luminaires the box space can be covered with isolation. Se mounting instruction for more information.

Connection

Luminaire connects to quick connector between driver and luminaire.

Design

Housing in aluminium, powder coated white (RAL 9016), black (RAL 9017) or grey (RAL 7038). Front ring in thermo plastic.

Dimming

DALI

Accessories

See accessories.

LED-information

L90 B50 100.000h Driver: 50 000h/10 %.

Miscellaneous

Passive cooling in all version except 4500 lm.

Marathon

Marathon is a stylish spotlight designed for track systems equipped with a highly efficient LED module that is up to 50 % as efficient as the previous one. This can lead to significant cost savings on an entire shop.

To avoid ...

More about the family Marathon

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Light control Installation
Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Light control Installation
68460 16 1378 3000 90 White Spot, 11° Recessed
68460-3 16 1378 3000 90 White Spot, 11° Recessed
68460-303 16 1378 3000 90 White Spot, 11° Recessed
68461 16 1378 3000 90 Black Spot, 11° Recessed
68461-3 16 1378 3000 90 Black Spot, 11° Recessed
68461-303 16 1378 3000 90 Black Spot, 11° Recessed
68462 16 1378 3000 90 Grey Spot, 11° Recessed
68462-3 16 1378 3000 90 Grey Spot, 11° Recessed
68462-303 16 1378 3000 90 Grey Spot, 11° Recessed
68465 36 3224 3000 90 White Spot, 19° Recessed
68465-3 36 3224 3000 90 White Spot, 19° Recessed
68465-303 36 3224 3000 930 White Spot, 19° Recessed
68465-402 36 3224 3000 930 White Spot, 19° DALI/Phase-pulse Recessed
68466 36 3224 3000 90 Black Spot, 19° Recessed
68466-3 36 3224 3000 90 Black Spot, 19° Recessed
68466-303 36 3224 3000 90 Black Spot, 19° Recessed
68466-402 36 3224 3000 90 Black Spot, 19° DALI/Phase-pulse Recessed
68467 36 3224 3000 90 Grey Spot, 19° Recessed
68467-3 36 3224 3000 90 Grey Spot, 19° Recessed
68467-303 36 3224 3000 90 Grey Spot, 19° Recessed
68467-402 36 3224 3000 90 Grey Spot, 19° DALI/Phase-pulse Recessed
68468 36 3270 3000 90 White Flood, 50° Recessed
68468-3 36 3270 3000 90 White Flood, 50° Recessed
68468-303 36 3270 3000 90 White Flood, 50° Recessed
68468-402 36 3270 3000 90 White Flood, 50° DALI/Phase-pulse Recessed
68469 36 3270 3000 90 Black Flood, 50° Recessed
68469-3 36 3270 3000 90 Black Flood, 50° Recessed
68469-303 36 3270 3000 90 Black Flood, 50° Recessed
68469-402 36 3270 3000 90 Black Flood, 50° DALI/Phase-pulse Recessed
68470 36 3270 3000 90 Grey Flood, 50° Recessed
68470-3 36 3270 3000 90 Grey Flood, 50° Recessed
68470-303 36 3270 3000 90 Grey Flood, 50° Recessed
68470-402 36 3270 3000 90 Grey Flood, 50° DALI/Phase-pulse Recessed
68471 35 3653 3000 90 White Medium, 25° Recessed
68471-3 35 3653 3000 90 White Medium, 25° Recessed
68471-303 35 3653 3000 90 White Medium, 25° Recessed
68472 35 3653 3000 90 Black Medium, 25° Recessed
68472-3 35 3653 3000 90 Black Medium, 25° Recessed
68472-303 35 3653 3000 90 Black Medium, 25° Recessed
68473 35 3653 3000 90 Grey Medium, 25° Recessed
68473-3 35 3653 3000 90 Grey Medium, 25° Recessed
68473-303 35 3653 3000 90 Grey Medium, 25° Recessed
68474 35 3679 3000 90 White Flood, 50° Recessed
68474-3 35 3679 3000 90 White Flood, 50° Recessed
68474-303 35 3679 3000 90 White Flood, 50° Recessed
68475 35 3679 3000 90 Black Flood, 50° Recessed
68475-3 35 3679 3000 90 Black Flood, 50° Recessed
68475-303 35 3679 3000 90 Black Flood, 50° Recessed
68476 35 3679 3000 90 Grey Flood, 50° Recessed
68476-3 35 3679 3000 90 Grey Flood, 50° Recessed
68476-303 35 3679 3000 90 Grey Flood, 50° Recessed
68477 36 3166 3000 90 White Medium, 23° Recessed
68477-3 36 3166 3000 90 White Medium, 23° Recessed
68477-303 36 3166 3000 90 White Medium, 23° Recessed
68477-402 36 3166 3000 90 White Medium, 23° DALI/Phase-pulse Recessed
68478 3166 3000 90 Black Medium, 23° Recessed
68478-3 3166 3000 90 Black Medium, 23° Recessed
68478-303 3166 3000 90 Black Medium, 23° Recessed
68478-402 3166 3000 90 Black Medium, 23° DALI/Phase-pulse Recessed
68479 36 3166 3000 90 Grey Medium, 23° Recessed
68479-3 36 3166 3000 90 Grey Medium, 23° Recessed
68479-303 3166 3000 90 Grey Medium, 23° Recessed
68479-402 36 3166 3000 90 Grey Medium, 23° DALI/Phase-pulse Recessed

Filter

Name Description Art.no.
Name Description Art.No.
BaffleBaffle ring 82704
BaffleBaffle ring 82705
BarndoorsBarndoors83543
BarndoorsBarndoors83544
Cap coneCap cone83546
Cap coneCap cone, white with inside in black83576
Decor plateDecor plate square 1 unit59934
Decor plateDecor plate rectangular 2 units59936
Elliptic lensElliptic lens, black96690
Elliptic lensElliptic lens, white96690-1000
Honeycomb louvreHoneycomb louvre83545
Honeycomb louvreHoneycomb, white ring, black grid83553
Mounting plateMounting plate Ø 163, Ø 180, Ø 222 mm96700
Mounting plateMounting plate, double97135
