Marathon Midi G3

Marathon is a cylindrical, discrete and energy efficient spotlight. The luminaire is designed for track system and is produced in a dramatic black, grey or subtle white finish.

Installation

Track mounted 3-phase, Control Track or iTrack.

Connection

3-phase, Control Track or iTrack adaptor.

Design

Housing in extruded aluminium, ends in die casted aluminium, powder coated black (RAL 9017) grey (7038) or white (RAL 9016) structured. Front ring in thermo plastic.

Reflector

Segmented miro reflector. Spot, flood.

Dimming

DALI via Control Track or iTrack. 100-1%

LED-information

3000 K: CRI 90 BBBL, L90 B50 100 000 h. Driver 50 000 h/10 %, MacAdam 3 SDCM.

Miscellaneous

Passived cooled in all versions.

Marathon

Marathon is a stylish spotlight designed for track systems equipped with a highly efficient LED module that is up to 50 % as efficient as the previous one. This can lead to significant cost savings on an entire shop.

To avoid ...

More about the family Marathon

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Light control Installation
Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Light control Installation
68370 16 1378 3000 90 White Spot, 11° 3-phase track
68371 16 1378 3000 90 Black Spot, 11° 3-phase track
68372 16 1378 3000 90 Grey Spot, 11° 3-phase track
68373 36 3224 3000 90 White Spot, 19° 3-phase track
68373-472 36 3224 3000 90 White Spot, 19° DALI iTrack
68373-504 36 3224 3000 90 White Spot, 19° DALI Control Track
68374 36 3224 3000 90 Black Spot, 19° 3-phase track
68374-472 36 3224 3000 90 Black Spot, 19° DALI iTrack
68374-504 36 3224 3000 90 Black Spot, 19° DALI Control Track
68375 36 3224 3000 90 Grey Spot, 19° 3-phase track
68375-472 36 3224 3000 90 Grey Spot, 19° DALI iTrack
68375-504 36 3224 3000 90 Grey Spot, 19° DALI Control Track
68376 36 3270 3000 90 White Flood, 50° 3-phase track
68376-472 36 3270 3000 90 White Flood, 50° DALI iTrack
68376-504 36 3270 3000 90 White Flood, 50° DALI Control Track
68377 36 3270 3000 90 Black Flood, 50° 3-phase track
68377-472 36 3270 3000 90 Black Flood, 50° DALI iTrack
68377-504 36 3270 3000 90 Black Flood, 50° DALI Control Track
68378 36 3270 3000 90 Grey Flood, 50° 3-phase track
68378-472 36 3270 3000 90 Grey Flood, 50° DALI iTrack
68378-504 36 3270 3000 90 Grey Flood, 50° DALI Control Track
68379 49 4379 3000 90 White Spot, 25° 3-phase track
68380 49 4379 3000 90 Black Spot, 25° 3-phase track
68381 49 4379 3000 90 Grey Spot, 25° 3-phase track
68382 49 4410 3000 90 White Flood, 50° 3-phase track
68383 49 4410 3000 90 Black Flood, 50° 3-phase track
68384 49 4410 3000 90 Grey Flood, 50° 3-phase track
68385 36 3166 3000 90 White Medium, 23° 3-phase track
68385-472 36 3166 3000 90 White Medium, 23° DALI iTrack
68385-504 36 3166 3000 90 White Medium, 23° DALI Control Track
68386 36 3166 3000 90 Black Medium, 23° 3-phase track
68386-472 36 3166 3000 90 Black Medium, 23° DALI iTrack
68386-504 36 3166 3000 90 Black Medium, 23° DALI Control Track
68387 36 3166 3000 90 Grey Medium, 23° 3-phase track
68387-472 3166 3000 90 Grey Medium, 23° DALI iTrack
68387-504 3166 3000 90 Grey Medium, 23° DALI Control Track

Filter

Name Description Art.no.
Name Description Art.No.
BaffleBaffle ring 82704
BaffleBaffle ring 82705
BarndoorsBarndoors83543
BarndoorsBarndoors83544
Cap coneCap cone83546
Cap coneCap cone, white with inside in black83576
Elliptic lensElliptic lens, black96690
Elliptic lensElliptic lens, white96690-1000
Honeycomb louvreHoneycomb louvre83545
Honeycomb louvreHoneycomb, white ring, black grid83553
