Bolt Recessed

Bolt Recessed is the latest addition to our Bolt family. The luminaire housing can be turned and aimed towards the displayed objects, which provides a workable lighting. An efficient and discreet spotlight for commercial lighting.

Installation

Recessed in ceiling.

Design

Housing in powder coated aluminium, white (RAL9016), black (RAL9005)

LED-information

CRI 90 BBBL, 3000 K 1300 lm: L70 B50 50.000 h 3000 lm: L90 B50 80 000 h Driver 50 000 h/10 % MacAdam 3 SDCM.

Bolt

Bolt family stands for simplicity and comes in two different designs, a spotlight and a recessed version. They are efficient and discreet luminaires for shops and other environments. The luminaire housing can be turned and aimed...

More about the family Bolt

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Light control
Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Light control
68228 16 1212 3000 90 White Spot, 13°
68228-3 16 1212 3000 90 White Spot, 13°
68228-303 16 1212 3000 90 White Spot, 13°
68229 16 1219 3000 90 White Medium, 23°
68229-3 16 1219 3000 90 White Medium, 23°
68229-303 16 1219 3000 90 White Medium, 23°
68230 16 1212 3000 90 Black Spot, 13°
68230-3 16 1212 3000 90 Black Spot, 13°
68230-303 16 1212 3000 90 Black Spot, 13°
68231 16 1219 3000 90 Black Medium, 23°
68231-3 16 1219 3000 90 Black Medium, 23°
68231-303 16 1219 3000 90 Black Medium, 23°
68232 31 2759 3000 90 White Spot, 13°
68232-3 31 2759 3000 90 White Spot, 13°
68232-303 31 2759 3000 90 White Spot, 13°
68232-402 31 2759 3000 90 White Spot, 13° DALI/Phase-pulse
68233 31 2839 3000 90 White Medium, 23°
68233-3 31 2839 3000 90 White Medium, 23°
68233-303 31 2839 3000 90 White Medium, 23°
68233-402 31 2389 3000 90 White Medium, 23° DALI/Phase-pulse
68234 31 2856 3000 90 White Flood, 36°
68234-3 31 2856 3000 90 White Flood, 36°
68234-303 31 2856 3000 90 White Flood, 36°
68234-402 31 2856 3000 90 White Flood, 36° DALI/Phase-pulse
68235 31 2759 3000 90 Black Spot, 13°
68235-3 31 2759 3000 90 Black Spot, 13°
68235-303 31 2759 3000 90 Black Spot, 13°
68235-402 31 2759 3000 90 Black Spot, 13° DALI/Phase-pulse
68236 31 2839 3000 90 Black Medium, 23°
68236-3 31 2839 3000 90 Black Medium, 23°
68236-303 31 2839 3000 90 Black Medium, 23°
68236-402 31 2839 3000 90 Black Medium, 23° DALI/Phase-pulse
68237 31 2856 3000 90 Black Flood, 36°
68237-3 31 2856 3000 90 Black Flood, 36°
68237-303 31 2856 3000 90 Black Flood, 36°
68237-402 31 2856 3000 90 Black Flood, 36° DALI/Phase-pulse

Filter

Name Description Art.no.
Name Description Art.No.
Decor plateDecor plate 230x180mm97779
Mounting plateMounting plate for soft tile ceilings96805
Mounting plateMounting plate double, for soft tile ceilings96853
