Zone Evo II G2

Zone Evo has a clean conical design and an efficient segmented reflector ensuring excellent visual performance.

Installation

Track mounted 3-phase track or iTrack.

Connection

3-phase or iTrack adaptor.

Design

Housing in die casted aluminium, powder coated black (RAL 9017) or white (RAL 9016) structured. Front ring in thermo plastic.

Reflector

Segmented reflector. Spot, medium or flood light distributions.

Dimming

DALI, phase pulse control.

LED-information

3000 K: CRI 80 or 90, L80 B50 75 000 h, MacAdam 3 SDCM.
4000 K: CRI 80, L80 B50 75 000 h, MacAdam 3 SDCM.
Driver life-time up to 50 000 h/10 % (max failure).

Miscellaneous

Passived cooled in all versions.

Zone Evo G2

Evolution changes the way things look, and the Zone family has evolved into new models. Yet an evolution of the Zone Family has been made. The new G2 family is equipped with a highly efficient LED module that is up to 50 % as...

More about the family Zone Evo G2

Document

Specification

Filter

Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Light control Installation
Art.no. Effect, W Lumen output CCT, K CRI Colour Light distribution Light control Installation
67860 24 2961 3000 80 White Spot, 16°
67860-472 24 2961 3000 80 White Spot, 16° DALI iTrack
67861 24 2826 3000 80 White Medium, 26°
67861-472 24 2826 830 White Medium, 26° DALI iTrack
67862 24 2837 3000 80 White Flood, 42°
67862-472 24 2837 3000 80 White Flood, 42° DALI iTrack
67863 24 2961 3000 80 Black Spot, 16°
67863-472 24 2961 3000 80 Black Spot, 16° DALI iTrack
67864 24 2826 830 Black Medium, 26°
67864-472 24 2826 830 Black Medium, 26°
67865 24 2837 3000 80 Black Flood, 42°
67865-472 24 2837 3000 80 Black Flood, 42° DALI iTrack
67866 29 2833 3000 90 White Spot, 16°
67866-472 29 2833 3000 90 White Spot, 16° DALI iTrack
67867 29 2705 3000 90 White Medium, 26°
67867-472 29 2705 3000 90 White Medium, 26° DALI iTrack
67868 29 2722 3000 90 White Flood, 42°
67868-472 29 2722 3000 90 White Flood, 42° DALI iTrack
67869 29 2833 3000 90 Black Spot, 16°
67869-472 29 2833 3000 90 Black Spot, 16° DALI iTrack
67870 29 2705 3000 90 Black Medium, 26°
67870-472 29 2705 3000 90 Black Medium, 26° DALI iTrack
67871 29 2722 3000 90 Black Flood, 42°
67871-472 29 2722 3000 90 Black Flood, 42° DALI iTrack
67872 25 2865 4000 80 White Spot, 16°
67872-472 25 2865 4000 80 White Spot, 16° DALI iTrack
67873 25 2740 4000 80 White Medium, 27°
67873-472 25 2740 4000 80 White Medium, 27° DALI iTrack
67874 25 2701 4000 80 White Flood, 42°
67874-472 25 2701 4000 80 White Flood, 42° DALI iTrack
67875 25 2865 4000 80 Black Spot, 16°
67875-472 25 2865 4000 80 Black Spot, 16° DALI iTrack
67876 25 2740 4000 80 Black Medium, 27°
67876-472 25 2740 4000 80 Black Medium, 27° DALI iTrack
67877 25 2701 4000 80 Black Flood, 42°
67877-472 25 2701 4000 80 Black Flood, 42° DALI iTrack
67878 37 4396 3000 80 White Spot, 20°
67879 37 4223 3000 80 White Medium, 31°
67880 37 4463 3000 80 White Flood, 47°
67881 37 4396 3000 80 Black Spot, 20°
67882 37 4223 3000 80 Black Medium, 31°
67883 37 4463 3000 80 Black Flood, 47°
67884 42 3619 3000 90 White Spot, 20°
67885 42 3325 930 White Medium, 30°
67886 42 3325 3000 90 White Flood, 46°
67887 42 3619 930 Black Spot, 20°
67888 42 3325 930 Black Medium, 30°
67889 42 3325 3000 90 Black Flood, 46°
67890 33 4266 4000 80 White Spot, 20°
67891 33 4049 4000 80 White Medium, 31°
67892 33 3998 840 White Flood, 46°
67893 33 4266 4000 80 Black Spot, 20°
67894 33 4049 4000 80 Black Medium, 31°
67895 33 3998 4000 80 Black Flood, 46°

Filter

Name Description Art.no.
Name Description Art.No.
BaffleBaffle ring97223
BaffleBaffle ring97224
BarndoorsBarndoors96863
BarndoorsBarndoors97226
Cap coneCap cone96865
Cap coneCap cone, white with inside in black96865-1000
Honeycomb louvreHoneycomb, white ring, black grid96698
Honeycomb louvreHoneycomb louvre96914
